OWNER'S MANUAL
WASHING
MACHINE
Before beginning installation, read these instructions carefully. This will simplify
installation and ensure that the product is installed correctly and safely. Leave
these instructions near the product after installation for future reference.
EN
ENGLISH
F2V5PYP**
FV1285S4W
MFL71670355
Rev.02_022621
FV1207S4W
Copyright © 2020-2021 LG Electronics Inc. All Rights Reserved
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG FV1207S4W
Summary of Contents for LG FV1207S4W
- Page 1 Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH F2V5PYP** FV1285S4W FV1207S4W www.lg.com MFL71670355 Rev.02_022621 Copyright © 2020-2021 LG Electronics Inc. All Rights Reserved...
-
Page 2: Table Of Contents
Adding Detergents and Softeners ..............20 Control Panel ....................22 Programme Table ....................24 Extra Options and Functions ................28 SMART FUNCTIONS ..............30 Using LG ThinQ Application ................30 Smart Diagnosis ....................32 MAINTENANCE ................33 Cleaning After Every Wash ................33 Cleaning the Appliance Periodically ..............33 TROUBLESHOOTING ..............36... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk. - Page 4 • The water pressure must be between 50 kPa and 800 kPa. • The maximum capacity in some cycles for dry clothes to be washed FV1207S4W FV1285S4W F2V5PYP** 7 kg...
- Page 5 Installation • Never attempt to operate the appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug. • This appliance should only be transported by two or more people holding the appliance securely. •...
- Page 6 • Never reach into the appliance while it is operating. Wait until the drum has completely stopped. • In case of flood, disconnect the power plug and contact the LG Electronics customer information centre. • Do not push down the door excessively, when the appliance door is open.
- Page 7 • Keep all washing detergents, softener and bleach away from children. • Do not touch the power plug or the appliance controls with wet hands. • Do not bend the power cable excessively or place a heavy object on • Do not wash rugs, mats, shoes or pet blankets, or any other items other than clothes or sheets, in this machine.
-
Page 8: Caring For The Environment
• You can take your appliance either to the shop where you purchased the product, or contact your local government waste office for details of your nearest authorised WEEE collection point. For the most up to date information for your country, please see www.lg.com/global/recycling. -
Page 9: Installation
INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View Rear View a Control Panel Control Panel a Power plug Power plug b b Detergent dispenser drawer Detergent dispenser drawer b b Transit bolts Transit bolts c c Drum... - Page 10 Accessories * This feature may vary depending on the model purchased. a Cold water inlet hose* Cold water inlet hose* b b Spanner Spanner c c Caps for covering transit bolt holes* Caps for covering transit bolt holes* d d Anti-slip sheets* Anti-slip sheets* e e Elbow bracket for securing drain hose* Elbow bracket for securing drain hose*...
-
Page 11: Installation Place Requirements
Installation Place Requirements 5 mm Before installing the appliance, check the following information to make sure that the appliance should be installed in a correct place. Installation Location • Install the appliance on a flat hard floor. (Allowable slope under the appliance: 1°) •... -
Page 12: Unpacking The Appliance
• Repairs to the appliance must only be carried out by the qualified personnel. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact your LG Electronics service centre. • Power outlet must be at least 1 meter of either side of the location of the appliance. -
Page 13: Leveling The Appliance
Removing the Bolt Assemblies Adjusting and Leveling the Feet When installing the appliance, the appliance should Starting with the bottom two transit bolts a, use be aligned and perfectly level. If the appliance is not the spanner (included) to fully loosen all transit aligned and level properly, the appliance may be bolts by turning them counterclockwise. -
Page 14: Connecting The Water Inlet Hose
• It must not ‘Seesaw’ across corners under the NOTE load. • Additional anti-slip sheets are available at LG • Do not let the feet of the appliance get wet. Electronics service centre. Failure to do so may cause vibration or noise. - Page 15 Checking the Rubber Seal on the NOTE Water Inlet Hose • Before connecting the inlet hose to the water tap, turn on the water tap to flush out foreign Two rubber seals a are supplied with the water substances (dirt, sand, sawdust, and etc.) in the inlet hoses.
- Page 16 Push the supply hose vertically upwards so Pull the connector latch plate down, push the that the rubber seal within the hose can adhere supply hose onto the adapter, and release the completely to the tap and then tighten it by connector latch plate.
-
Page 17: Installing The Drain Hose
Installing the Drain Hose For Model with Drain Pump The drain hose should not be placed higher than 100 cm above the floor. Water in the appliance may not drain or may drain slowly. • Securing the drain hose correctly will protect the floor from damage due to water leakage. -
Page 18: Operation
OPERATION Operation Overview End of cycle. • When the cycle is finished, a melody will sound. Immediately remove your clothing Using the Appliance from the appliance to reduce wrinkling. Before the first wash, select the Cotton wash Check around the door seal when removing the load for small items that may be caught programme and add a half amount of the detergent. - Page 19 Checking the Clothes Care Label • Close zippers, hooks and strings to make sure that these items do not snag on other clothes. • Pre-treat dirt and stains by brushing a small Symbols on the care labels amount of detergent dissolved water onto stains to help lift dirt.
-
Page 20: Adding Detergents And Softeners
Adding Detergents and NOTE Softeners • Do not let the detergent harden. Doing so may lead to blockages, poor rinse performance or odour. Detergent Dosage • Full load: According to manufacturer’s recommendation. • Detergent should be used according to the •... - Page 21 Adding Detergent Tablet • Do not leave the fabric softener in the detergent drawer for more than 2 days (Fabric softener Detergent tablet is also available when washing may harden). laundry. • Softener will automatically be added during the last rinse cycle. Open the door and put detergent tablets into •...
-
Page 22: Control Panel
Control Panel Control Panel Features a Power Power Button Button • Press the Power button to turn on or off the appliance. b b Programme Knob Programme Knob • Programmes are available according to the laundry type. • The lamp will light up to indicate the selected programme. c c Start/Pause Start/Pause Button Button... - Page 23 e e Display Display • The display shows the settings, estimated remaining time, options, and status messages. When the appliance is turned on, the default settings in the display will illuminate. − 18:88: When a programme is selected, the default time for that programme is displayed. The default time can be changed according to the selected option.
-
Page 24: Programme Table
Programme Table Washing Programme Cotton Programme Description Provides better performance by combining various drum motions. Use for coloured fast garments (shirts, nightdresses, pajamas, etc.) and normally soiled cotton load (underwear). Proper Temperature 40 °C (Cold to 95 °C) Max. Load Rating Max. - Page 25 Silent Wash Programme Description Provides less noise and vibration and saves money by using overnight electricity. Use for coloured fast garments (shirts, nightdresses, pajamas, etc.) and lightly soiled white cotton (underwear). Proper Temperature 40 °C (Cold to 60 °C) Max. Load 4 kg Max.
- Page 26 Sportswear Programme Description Suitable for special garments like sports and outdoor wear. Use for Coolmax, gore-tex, fleece and sympatex. Proper Temperature 40 °C (Cold to 40 °C) Max. Load 2 kg Max. Spin Speed 800 rpm Quick 30 Programme Description Provides fast washing time for small loads and lightly soiled clothes.
- Page 27 Extra Options Intensive Rinse+ Pre Wash Delay End Add Item Programme Cotton Cotton+ Mixed Fabric Easy Care Silent Wash Allergy Care Baby Steam Care Delicates Hand/Wool Sportswear Quick 30 Duvet Tub Clean Download Cycle...
-
Page 28: Extra Options And Functions
Delay End Extra Options and Functions You can set this function so that the appliance starts automatically and finishes after a specified time You can use the extra options and functions to interval. customize the programmes. Press the Power button. Intensive Select a washing programme. - Page 29 Beep On/Off q NOTE • For safety reasons, the door remains locked This function operates only when the appliance is when the water level or temperature inside of in operation. the drum is high. It is not possible to add laundry •...
-
Page 30: Smart Functions
(WLAN network). your wireless router manual. • LG ThinQ is not responsible for any network • If the distance between the appliance and the wireless router is too far, the signal connection problems or any faults, malfunctions, strength becomes weak. - Page 31 Press and hold Remote Start button for 3 Energy Monitoring seconds to enable this function. Check the energy consumption of the recently used Start a cycle from the LG ThinQ application on cycles and monthly average. Smart Diagnosis your smartphone.
-
Page 32: Smart Diagnosis
Follow the instructions below to use the audible Open Source Software Notice diagnosis method. • Launch the LG ThinQ application and select the Information Smart Diagnosis feature in the menu. Follow To obtain the source code under GPL, LGPL, MPL, the instructions for audible diagnosis provided in the LG ThinQ application. -
Page 33: Maintenance
MAINTENANCE WARNING • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, electric shock, or death. • Never use harsh chemicals, abrasive cleaners, or solvents to clean the appliance. They may damage the finish. - Page 34 NOTE Close the dispenser drawer slowly. • Turn off the supply tap to the appliance if the Turn on the power, and then select the appliance is to be left for a certain period of time Tub Clean. (e.g. holiday), especially if there is no floor drain (gully) in the immediate vicinity.
- Page 35 After cleaning the drain pump filter, take the Remove the build-up of detergent and softener. drain pump filter out and insert the drain plug. • Rinse the drawer and the components of the drawer with warm water to remove the build- up from detergent and softener.
-
Page 36: Troubleshooting
Operation of your appliance can lead to errors and malfunctions. The following tables contain possible causes and notes for resolving an error message or malfunction. It is recommended to read the tables carefully below in order to save your time and money that may cost for calling to LG Electronics service centre. - Page 37 Symptoms Possible Cause & Solution This is a control error. CONTROL ERROR • Unplug the power plug and call for service. Over load in motor MOTOR LOCKED • Let the appliance wait for 30 minutes until the motor is cooled down and ERROR then, restart the cycle.
- Page 38 Noises You Might Hear Symptoms Possible Cause & Solution Rattling and clanking Foreign objects, such as keys, coins, or safety pins may be in the drum. noise • Stop the appliance, check the drum for foreign objects. If the noise continues after the appliance is restarted, call for service.
- Page 39 Symptoms Possible Cause & Solution Appliance does not Controls are not set properly. operate. • Make sure that the cycle should be correctly set. Close the door and press the Start/Pause button. Door is open. • Close the door and make sure that nothing should be caught under the door preventing it from closing completely.
- Page 40 Symptoms Possible Cause & Solution Appliance does not Kinked drain hose. drain water. • Ensure that the drain hose is not kinked. Drain located higher than 1.2 m above the floor. • Make sure that the drain hose should not be higher than 1.2 m above the bottom of the appliance.
- Page 41 Symptoms Possible Cause & Solution Wrinkling Appliance is not unloaded promptly. • Always remove items from the appliance as soon as the cycle is complete. Appliance is overloaded. • The appliance can be fully loaded, but the drum should not be tightly packed with items.
- Page 42 The password for the Wi-Fi that you are trying to connect to is incorrect. and smart phone is • Find the Wi-Fi network connected to your smartphone and remove it, then register your appliance on LG ThinQ. not connected to the Wi-Fi network.
- Page 43 Memo...
