- Page 1 User’s Manual VersaPoint Rechargeable Wireless Media Keyboard Page ...
-
Page 2: Regulatory Compliance
Regulatory Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 3: Declaration Of Conformity
The term “IC” before the certification/registration number only signifies that the Industry Canada technical specifications were met. Declaration of conformity Hereby, SMK-LINK Electronics, Inc. declares that this VersaPoint Rechargeable Wireless Media Keyboard is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. All trademarks and registered trademarks mentioned in this document are the property of their respective owners. -
Page 4: System Requirements
• User’s manual Important Notes before You Start • In the event you need to travel with the keyboard, please remove the batteries to avoid draining battery power. • LED status indicator light: This keyboard is equipped with a status indicator LED... - Page 5 (See Fig. 1) Please familiarize yourself with the various indicators below (See Fig 2.) Pairing of RF When receiver dongle is successfully paired up with the keyboard Battery-Low When battery is low Charging Battery During charging...
-
Page 6: Installing Batteries
Installing Batteries • Remove the battery cover located at the bottom of the keyboard. (See Fig. 3) • Insert the two supplied AAA rechargeable Ni-MH batteries (included in the package) into the battery compartment. Make sure the positive (+) and negative (-) ends of the batteries match the polarity markings inside the battery compartment. -
Page 7: Charging The Batteries
Do not attempt to charge non-rechargeable disposable Alkaline batteries. The batteries may leak and damage your keyboard. Use only the rechargeable Ni-MH batteries supplied. Shall replacing batteries become necessary use only rechargeable Ni-MH batteries. Do not mix new and old batteries or batteries of different brands or capacities in the products. - Page 8 (see next step) anytime during charging. • Connect the mini USB connector of the charging cable (included in the box) to the keyboard’s mini USB port. (See Fig. 4) • Connect the USB connector of the charging cable to your computer’s available USB port.
- Page 9 Make sure the computer’s power management is set to disable hibernation mode while the product is being charged. (Go to Control Panel, Power Options, select “Hibernate” from the tabs and uncheck the box marked “Enable Hibernation.) Pairing the Keyboard to the Receiver Dongle Page ...
- Page 10 The keyboard should be fully functional now. (See Fig. 5) • If, for any reason, the keyboard and receiver dongle are not paired, or interference is encountered, you may set up the connection link by performing the following steps:...
- Page 11 1. Plug the mini USB connector of the USB adapter (included in the box) to the mini USB port on the keyboard. (See Fig. 6-1) 2. Connect the RF USB receiver dongle to the USB adapter while the adapter is plugged into the keyboard. Leave it connected for approximately 3 seconds until the RF indicator light on the keyboard scroller turns red;...
- Page 12 LED light turns red. (See Fig. 6-2) 3. Remove the receiver from the adapter, plug the receiver to the PC’s USB port. You are ready to use the keyboard. First, raise the foot extension of the keyboard for a more comfortable typing position, then remove the USB adapter and secure it with the supplied hook &...
- Page 13 Operating Instructions • This keyboard features the standard QWERTY configuration plus 8 convenient one-touch hot keys for Internet launch and media player controls. (See Fig. 8) 1. Trackball / Wake up Trackball: controls cursor movements similar to mouse functions. The trackball is designed with power-saving sleep mode which turns off the trackball function after approximately 5 minutes of inactivity.
- Page 14 Stop, Play/Pause, Mute, Volume Down, Volume Up. 5. NumLock function: when NumLock is on, the right-hand section of the keyboard doubles as numeric keypad. To return to alphabet-mode, press the NumLock key one more time to turn it off. (See Fig. 9)
-
Page 15: Warranty
(90) days from the date of service or return shipping, whichever is longer. If the Product becomes defective in materials or workmanship during the warranty period, SMK-LINK will, at its option, either repair or replace it with a more current or upgraded model if the originally purchased model is not available. -
Page 16: Product Support
This warranty does not affect your statutory right and you may also have other rights which vary from state to state. Unless modified in writing, signed by both you and SMK-LINK, this warranty is understood to be the complete and exclusive agreement between the parties, superseding all prior agreements, oral or written, and all other communications between the parties relating to the subject matter of this warranty.
