Summary of Contents for Esatto ECC905T
- Page 1 Model/s Version ECC905T V 1.0 | 0822 Everything you need for your 90cm Ceramic Cooktop is in this User Manual...
- Page 2 — requirements of your appliance to ensure optimum performance. Telephone 1300 11 4357 Again, thank you for choosing an Esatto appliance and we look forward to being of service to you. Kind Regards, The Residentia Team www.esatto.house...
- Page 3 Contents Page 2 Page 4 Welcome Safety Instructions Page 7 Page 7 You Esatto Technical Cooktop Specifications Page 8 Page 9 Before First Use Operation Instructions Page 12 Page 17 Installation Cleaning & Instructions Maintenance Page 18 Page 19 Troubleshooting...
- Page 4 User Manual Safety Instructions IMPORTANT INFORMATION INSTALLATION The following statements you will see in this booklet have Electrical Shock Hazard these meanings: • Disconnect the appliance from the mains electricity supply before carrying out any work or WARNING! maintenance on it. Indicating information concerning your personal safety.
- Page 5 • Metallic objects such as knives, forks, spoons and lids Hot Surface Hazard should not be placed on the cooktop surface since • During use, accessible parts of this appliance will they can get hot. become hot enough to cause burns.
- Page 6 User Manual Safety Instructions (Continued) • Do not use pans with jagged edges or drag pans CAUTION: across the ceramic glass surface as this can scratch Read the following carefully to avoid an electric shock the glass. or fire. • Do not use scourers or any other harsh abrasive cleaning agents to clean your cooktop, as these can It is important to use your cooktop safely.
- Page 7 Your Esatto Cooktop PRODUCT LEGEND A. Toughened Black Glass B. Max. 1800W zone C. Max. 1200W zone D. Max. 1100/2000W zone E. Max. 1000/2200W zone Max. 1200W zone G. Touch Control Panel CONTROL PANEL LEGEND Timer control 2. Power & Timer slider touch control 3.
- Page 8 User Manual Before First Use BEFORE FIRST USE SERVICING • Before using this appliance read this manual, taking • Servicing MUST only be carried out by authorised special note of the ‘Safety Instructions’ section. personnel. • To maintain safe operation, it is recommended that IMPORTANT! You should clean the ceramic cooktop the product be inspected every five years by an...
- Page 9 Operation Instructions GENERAL USE INSTRUCTIONS TOUCH CONTROLS All operations are performed by means of the touch • Do not use cookware with jagged edges or a curved controls that can be found on the control panel. base. USING THE TOUCH CONTROLS •...
- Page 10 User Manual Operation Instructions (Continued) WHEN YOU HAVE FINISHED COOKING OVER TEMPERATURE PROTECTION Touching the heating zone selection control that you A temperature sensor equipped can monitor the wish to switch off. temperature inside the ceramic hob. When an excessive 2.
- Page 11 USING THE TIMER Setting a timer for more than one zone You can use the timer in two different ways: • Use the same steps above to set timers against • You can use it as a minute minder. In this case, the multiple zones.
- Page 12 User Manual Installation Instructions WARNING WARNING! This user manual must be read! The laws, The surface temperature exceeds 90° C. ordinances, directives and standards in force in the To avoid a hazard, under bench access must be restricted. country of use are to be followed (safety regulations, •...
- Page 13 INSTALLATION Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 5cm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant and insulated work surface material (wood and similar fibrous or hygroscopic material shall not be used as work surface material unless impregnated) to avoid the electrical shock and larger deformation caused by the heat radiation from the hotplate.
- Page 14 User Manual Installation Instructions (Continued) CLEARANCES Under any circumstances, make sure the ceramic cooktop is well ventilated and the air inlet and outlet are not blocked. Ensure the ceramic cooktop is in good working state as shown below. Wall Min. 30mm A (mm) B (mm) C (mm)
- Page 15 LOCATING THE FIXING BRACKETS The unit should be placed on a stable, smooth surface (use the packaging or a towel). Do not apply force onto the controls protruding from the cooktop. Fix the cooktop on the work surface by screw four brackets on the bottom of cooktop(see picture) after installation.
- Page 16 User Manual Installation Instructions (Continued) ELECTRICAL CONNECTION IMPORTANT The cooktop must NOT be connected to the mains supply by means of a 10A or 15A plug and socket. The power supply should be connected in compliance with the relevant standard, or a single-pole circuit breaker.
- Page 17 By ensuring proper cleaning and maintenance of your • Boil overs, melts, and hot sugary spills on the glass Esatto cooktop, you can ensure that it will have a long Remove these immediately with a fish slice, palette and fault free operation.
- Page 18 User Manual Troubleshooting Some minor faults can be fixed by referring to the instructions given below. Please do not disassemble the unit by yourself to avoid any dangers and damages to the ceramic cooktop. Instead contact our customer care team on 1300 11 4357 or visit our self help portal online www.support.residentiagroup.com.au.
- Page 19 Attach your receipt to this page Purchase Details For future reference, please record the following information in the form below. The product details can be found on the rating plate, and purchase details which can be found on your sales invoice.
- Page 20 User Manual Warranty Information (AU) AUSTRALIAN WARRANTY TERMS & CONDITIONS (h) ‘you’ means the purchaser of the Appliance not COOKING APPLIANCES having purchased the Appliance for re-sale, and ‘your’ has a corresponding meaning. This document sets out the terms and conditions of the 2.
- Page 21 (a) the Appliance is damaged by: to you given by this warranty are in addition to your other rights and remedies under a law in relation to the accident (ii) misuse or abuse, including failure to properly Appliances or services to which the warranty relates.
- Page 22 – that you can refer to at any time. purchaser; Simply visit the below website, or ask your retailer h) damage caused by power outages or surges for help: www.esatto.house/nz/registration damage caused by pests (eg. rats, cockroaches etc.) WARRANTY That if the product is a freestanding microwave oven...
- Page 23 This page is intentionally blank. But if you want to draw something, make notes or even write a recipe, it’s all yours!
- Page 24 everything you need A RESIDENTIA GROUP INITIATIVE...
