Summary of Contents for Prismatibro Prisma Light Eliott 4 Series
- Page 1 4-XX MANUAL MOUNTING AND INSTALLATION...
- Page 2 Flat glass: 221 mm • Curved glass: 261 mm Height with plug Flat glass: 152 mm • Curved glass: 192 mm Height, plane case Flat glass: 120 mm • Curved glass: 160 mm Plane case, flat glass 0.058 m WIND LOAD Prisma Light | prismatibro.se...
- Page 3 Therefore, there are two item codes for the same item. ±10° ±10° Item code Item code 353-0004 353-0003 Mounting The pole fitting is mounted on the pole, and the 2 bolts are tightened. Tightening torque for the bolts: 8 Nm +/- 2Nm prismatibro.se | Prisma Light...
- Page 4 The luminaire is connected to the wiring inside the pole 1. Secure the luminaire to the pole. 2. Connect the cable to the fuse holder. 3. Ensure proper grounding. Insufficient grounding can result in uncontrolled voltages in the system. 4. Turn on the power. Prisma Light | prismatibro.se...
- Page 5 Prisma Light Eliott should now illuminate with the factory-set, on/off customer-desired power/function. Prisma Light Zhaga COMMISSIONING • Switch on the power to the luminaire. Prisma Light Eliott should now illuminate with the factory-set, on/off customer-desired power/function. MANUAL STYRNING prismatibro.se | Prisma Light...
- Page 6 Press down and rotate the locking ring clockwise until it clicks into place. The click confirms the locking. Mount the gateway on the lighting control panel. Connect the gateway to the power grid, either with a constant power supply or through the lighting circuit. Prisma Light | prismatibro.se...
- Page 7 Press down and twist the locking ring clockwise until it clicks into place. The click confirms the lock. Install the gateway. Connect the gateway to the power supply, either with a constant power source or through the lighting supply. prismatibro.se | Prisma Light...
- Page 8 Opening the optical part risks compromising the IP rating. If there are any issues, the luminaire should be returned in its entirety for repair or replacement by PrismaTibro. Prisma Light Eliott can be rinsed with water under low pressure but not with a high-pressure washer.
