ANSI
Z359.18-2017 (Type T), Z359.4-2013, Z117.1-2022
OSHA
This manual is intended to meet the manufacturer's instructions as required by ANSI and should be used as part of an
220-00091
1910.140, 1926.502
10' Tech Tripod Basic
022-11029
022-11033
10' Tech Tripod Complete
022-11034
10' Tech Tripod Kit: 65' Personnel Winch, 65' 3-Way
022-11035
10' Tech Tripod Kit: 65' Material Winch, 65' 3-Way
022-11036
10' Tech Tripod Kit: 65' 3-Way
022-11037
10' Tech Tripod Kit: 65' Material Winch
employee training program as required by OSHA.
Read and understand instructions before using equipment!
Do not throw away instructions!
V1.0 2023 Copyright Safewaze
10' Tech Tripod
Manual
Advertisement
Table of Contents
Related Manuals for SafeWaze 022-11029
Summary of Contents for SafeWaze 022-11029
- Page 1 This manual is intended to meet the manufacturer’s instructions as required by ANSI and should be used as part of an employee training program as required by OSHA. Read and understand instructions before using equipment! Do not throw away instructions! V1.0 2023 Copyright Safewaze 220-00091...
-
Page 2: Table Of Contents
IMPORTANT: Record initial usage of product on the Table of Contents page. Competent Person inspections are required to be documented in the Inspection Log Table. Always verify the latest revision of the Safewaze Manual is being utilized. Visit the Safewaze website, or contact Customer Service, for updated manuals. - Page 3 Equipment must never be altered or modified. Only Safewaze, or entities authorized in writing by Safewaze, may make repairs to Safewaze fall protection equipment. • User(s) of Safewaze fall protection equipment must ensure that their health and physical condition allows them to withstand the potential forces and risks associated with working at heights. •...
-
Page 4: Introduction
The Safewaze 10’ Tech Tripod is designed to be used as an adjustable anchorage point for fall protection, fall restraint, rescue, and material hauling. The 10’ Tech Tripod is suitable for most transition applications. These include Construction, Transportation, General Industry, Oil, Utilities, Trench, Mining, Cliff, and Rescue. - Page 5 022-11032 Tripod Bag and Adjusters 019-11010 Universal Tripod Bracket Galvanized Steel 019-11017 Tripod Replacement Chain Zinc Plated Steel Dimension Diagrams: 119” 74.5” (302.2cm) (189.2cm) 97” (246.3cm) 86.5” Ø 127.1” Ø (219.9cm Ø) (323cm Ø) Page 2 V1.0 2023 Copyright Safewaze...
-
Page 6: Worker Classifications
Z359.4-2013 for specific rescue information. NOTE: Special rescue measures may be required for a fall over an edge. 9.0 HARNESS CONNECTIONS/FALL CLEARANCE Use of this equipment requires an ANSI Z359.11-2021 Full Body Harness (FBH). Page 3 V1.0 2023 Copyright Safewaze... -
Page 7: Compatibility Of Components
Do not use equipment that is not compatible (Figure 3). Ensure all connectors are fully closed and locked. Safewaze connectors (hooks, carabiners, and D-rings) are designed to be used only as specified in each product’s user instructions. See Figure 3 for examples of inappropriate connections. -
Page 8: Applications
ANSI Z359 Fall Protection Code. Contact Safewaze if you have questions regarding compatibility of this equipment. Do not alter or misuse this equipment. Some subsystem components could affect the performance and the operation of this equipment. Do not WARNING: connect this product to moving machinery, or hazards that include chemical, electrical, or gaseous characteristics. - Page 9 Step 5: Connect the tripod legs together using the provided safety chain. Ensure all feet of tripod are secured with the chain to resist moving, splaying, or shifting from the tripod set location. NOTE: Safety Chain MUST be installed to complete installation. Remove all slack from chain. Do not use tripod without safety chain installed. Page 6 V1.0 2023 Copyright Safewaze...
- Page 10 It may be necessary to configure the two tripod feet towards the nearest edge in a vertical position for best grip. NOTE: Safety Chain MUST be installed to complete installation. Remove all slack from chain. Do not use tripod without safety chain installed. Page 7 V1.0 2023 Copyright Safewaze...
- Page 11 WARNING etc. Refer to standards and regulations specific to the type of work being performed. Prepare and establish a rescue plan prior to work operations. Page 8 V1.0 2023 Copyright Safewaze...
-
Page 12: Compatible Devices/Connection Points
3-Way System, Personnel Winch, Material Winch: Step 1: The Universal Tripod Bracket is designed to allow quick connection and disconnection of up to 3 Safewaze Devices to the 10’ Tech Tripod. One section of the bracket (fixture plate) comes pre-installed onto the tripod leg, with the second component (device bracket) pre-attached to the device. - Page 13 FIGURE 11 - EXAMPLE SYSTEM CONNECTIONS 30kN 15kN 15kN ANSI Z359.14, ANSI A10.32 OSHA 1910.66, OSHA 1926.502 ANSI Z359.14-2021 Compliant SRL ANSI Z359.11-2021 Compliant FBH DANGER WORK ZONE DANGER WORK ZONE DANGER WORK ZONE Personnel Winch Page 10 V1.0 2023 Copyright Safewaze...
- Page 14 Step 2: Thread the end of the Perimeter Warning Line through each of the 3 brackets. Step 3: Pull the free end of the warning line through the cam buckle until line is snug and secure any excess webbing to prevent a trip hazard. Page 11 V1.0 2023 Copyright Safewaze...
-
Page 15: After A Fall
Never store any component when wet. Store Safewaze Confined Space system components in a cool, dry, and clean environment out of direct sunlight. Utilize the storage bag and component pockets to neatly store the tripod and components. Avoid areas where chemical vapors may exist. Thoroughly inspect the system after any period of extended storage. -
Page 16: Product Life
The working life of the 10’ Tech Tripod System is determined by work conditions, care, and inspection provided. So long as the system and all components passes inspection, it may remain in service. If any component of the system is exposed to the forces of a fall, it must be removed from service and tagged “Unusable.” Page 13 V1.0 2023 Copyright Safewaze... -
Page 17: Disposal
86.5” Ø (219.9cm Ø) 6x user weight capacity 119” (302.2cm) Use foot spikes for over edge configurations *Sold Separately 97” (#022-11031) (246.3cm) Place warning line when desired 127.1” Ø configuration is reached. (323cm Ø) Page 14 V1.0 2023 Copyright Safewaze... -
Page 18: Inspection Log
The Competent Person must place their initials in the block which IMPORTANT: corresponds with the month and year that the inspection is performed. All individual labels on equipment will be initialed in the same manner. If equipment fails inspection IMMEDIATELY REMOVE FROM SERVICE Page 15 V1.0 2023 Copyright Safewaze... - Page 19 V1.0 2023 Copyright Safewaze...
- Page 20 Safewaze 225 Wilshire Ave SW Concord, NC 28025 PHONE: 1-800-230-0319 FAX: 1-704-262-9051 EMAIL: info@safewaze.com Web: safewaze.com V1.0 2023 Copyright Safewaze...
