- Page 1 Oven CM724G1.1B User manual and installation instructions Register your product on My Siemens and discover exclusive ser- vices and offers. siemens-home.bsh-group.com/welcome The future moving in. Siemens Home Appliances...
-
Page 2: Table Of Contents
en Safety Futher information and explanations are available online: Table of contents 1 Safety Observe the following safety instructions. INFORMATION FOR USE 1.1 General information Safety .............. 2 ¡ Read this instruction manual carefully. Preventing material damage ...... 6 ¡ Keep the instruction manual and the Environmental protection and saving en- product information safe for future refer- ergy .............. 7... -
Page 3: Safety
Safety en When the cooking compartment is hot, any al- been instructed on how to use the appliance coholic vapours inside may catch fire. The ap- safely and have understood the resulting dangers. pliance door may spring open. Hot steam and jets of flame may escape. - Page 4 en Safety 1.5 Microwave WARNING ‒ Risk of electric shock! Incorrect repairs are dangerous. CAREFULLY READ THE IMPORTANT SAFETY ▶ Repairs to the appliance should only be INSTRUCTIONS AND KEEP THEM SAFE FOR FUTURE USE carried out by trained specialist staff. ▶ Only use genuine spare parts when repair- WARNING ‒ Risk of fire! ing the appliance.
- Page 5 Safety en sausages, may burst. Before heating, prick WARNING ‒ Risk of scalding! the peel or skin. There is a possibility of delayed boiling when Heat is not distributed evenly through baby a liquid is heated. This means that the liquid food. reaches the boiling temperature without the ▶...
-
Page 6: Preventing Material Damage
en Preventing material damage Never operate the appliance if the cooking Microwave energy will escape from appli- compartment door or the door seal is dam- ances that do not have any casing. aged. Microwave energy may escape. ▶ Never remove the casing. ▶... -
Page 7: Environmental Protection And Saving En- Ergy
Environmental protection and saving energy en Operating the appliance without food in the cooking If you prepare microwave popcorn at a microwave compartment may lead to overloading. power level that is too high, the door pane may crack Do not switch on the microwave unless there is food due to overloading. - Page 8 en Familiarising yourself with your appliance 4 Familiarising yourself with your appliance 4.1 Control panel Symbol Meaning Wi-Fi signal strength for Home Connect. You can use the control panel to configure all functions The more lines of the symbol are filled, of your appliance and to obtain information about the the better the signal.
- Page 9 Cooking Functions en Lighting Button Function One or more oven lights illuminate the cooking com- Select the timer. partment. → "Setting the timer", Page 15 When you open the appliance door, the light in the Press and hold for approx. 4 seconds: cooking compartment switches on. If the appliance Activate or deactivate the childproof door remains open for longer than around 18 minutes, lock.
- Page 10 en Cooking Functions 5.1 Types of heating To ensure that you always find the right type of heating When you select a type of heating, the appliance sug- to cook your food, we explain the differences and ap- gests a suitable temperature or setting. You can use plications below.
-
Page 11: Accessories
Accessories en Microwave output in Maximum cooking watts time in hours 600 W 1:30 Heat and cook food. 900 W "Boost" 00:30 Heat liquids. Note: The maximum microwave output setting "Boost" is not designed for heating food. To protect the appli- ance, the microwave output is gradually reduced to 600 watts during the first few minutes. -
Page 12: Before Using For The First Time
You will find a comprehensive range of products for your appliance in our brochures and online: siemens-home.bsh-group.com Baking tray Slide the tray in with the sloping Accessories vary from one appliance to another. When E.g. - Page 13 Basic operation en 8 Basic operation 8.1 Switching on the appliance 8.6 Setting the type of heating and the temperature Press to switch the appliance on. ▶ a The display shows the menu. Press "Types of heating". Press the type of heating that you want to use. Set the temperature using or directly via the 8.2 Switching off the appliance...
-
Page 14: Time-Setting Options
en Time-setting options This will ensure that the light in the cooking com- Place the food in the cooking compartment before partment is always off while the appliance is in oper- the appliance starts to heat. ation and when you open the appliance door. Start the operation. -
Page 15: Microwave
Microwave en When the food is ready, use to switch the ap- To set the timer, press the relevant time value on ‒ pliance off. the display, e.g. hour display "h" or minute display "min". Setting the end time a The selected value is marked in blue. To achieve good cooking results, only change the set Set the timer using or directly via the adjust-... - Page 16 en Microwave ¡ → "Preventing material damage", Page 6 ATTENTION! ¡ → "Microwave output settings", Page 10 Operating the appliance without food in the cooking ¡ → "Cookware and accessories with microwave", compartment may lead to overloading. Page 15 Do not switch on the microwave unless there is food ▶...
-
Page 17: Dishes
Dishes en Requirement: Observe the information about the re- a Once the cooking time has elapsed, a signal tone spective operating mode. sounds. A notification appears on the display con- → "Setting options with the microwave", Page 16 firming that the operation has finished. Once the cooking time has elapsed: Press the operating mode that you require. - Page 18 en Favourites ¡ Pizza, frozen, with thin base, x 1 For information about the accessory and shelf posi- tion, for example, press . ¡ Lasagne, frozen Press to start the operation. ¡ Vegetables, fresh a The appliance starts to heat and the time counts ¡...
-
Page 19: Favourites
Basic settings en 14 Basic settings You can configure the basic settings for your appliance Device Set- Selection to meet your needs. tings Microwave out- ¡ 90 W 14.1 Overview of the basic settings put presetting ¡ 180 W ¡ 360 W Here you can find an overview of the basic settings ¡... -
Page 20: Home Connect
en Home Connect 15 Home Connect This appliance is network-capable. Connecting your ap- 15.1 Setting up Home Connect pliance to a mobile device lets you control its functions Requirements via the Home Connect app, adjust its basic settings ¡ The appliance is connected to the power supply and and monitor its operating status. -
Page 21: Cleaning And Servicing
Cleaning and servicing en stalling it via the Home Connect app if you are in your 15.3 Operating the appliance with the WLAN home network (Wi-Fi). The Home Connect app Home Connect app will inform you once installation is successful. You can use the Home Connect app to set and start Notes the appliance remotely. - Page 22 en Cleaning and servicing Using oven cleaner in a hot cooking compartment If different cleaning agents are mixed together, there damages the enamel. may be a chemical reaction between these. Never use oven cleaner in the cooking compartment Do not mix cleaning agents. ▶...
- Page 23 Cleaning aid "humidClean" en 16.2 Cleaning the appliance WARNING ‒ Risk of fire! Loose food remnants, fat and meat juices may catch In order to avoid damaging the appliance, you must fire. clean your appliance only as specified, and with suit- Before using the appliance, remove the worst of the able cleaning products.
-
Page 24: Drying Function
en Drying function 18 Drying function To prevent residual moisture, dry the cooking compart- To use the "Drying function" function, set "Drying ‒ ment following microwave-only operation. function". → "Setting the drying process", Page 24 ATTENTION! If there is water on the cooking compartment floor Setting the drying process when operating the appliance at temperatures above Requirement: → "Drying the cooking compartment",... -
Page 25: Rails
Rails en 19.2 Attaching the door outer pane WARNING ‒ Risk of serious harm to health! If the screws are undone, the safety of the appliance Attach the front pane downwards into the left- and can no longer be guaranteed. Microwave energy right-hand retainers ... -
Page 26: Troubleshooting
en Troubleshooting Hook the rear retainers with the hook into the top 20.2 Fitting the retainers hole and push them into the bottom hole . The retainers may fall out when you detach the rails. Note: The retainers at the front differ from those at the rear. 20.3 Attaching the rails Set the rear rail at an angle, hooking it into the re- tainers at the top and bottom... - Page 27 Troubleshooting en Fault Cause and troubleshooting The appliance is not Electronics fault working. Disconnect the appliance from the power supply for at least 30 seconds by switching off the fuse. Reset the basic settings to the factory settings. → "Basic settings", Page 19 "Sprache Deutsch"...
-
Page 28: Disposal
Next time, set lower or higher values. ▶ Tip: A lot of other information about the food preparation and corresponding adjustment values can be found in the Home Connect app or on our website siemens-home.bsh- group.com . 22 Disposal 22.1 Disposing of old appliance... -
Page 29: Declaration Of Conformity
A detailed Declaration of Conformity can be found on- A detailed RED Declaration of Conformity can be found line at siemens-home.bsh-group.com/uk/ among the online at siemens-home.bsh-group.com among the ad- additional documents on the product page for your ditional documents on the product page for your appli- appliance. - Page 30 en How it works ¡ Place the poultry onto the cookware breast-side or The "Grill" type of heating is good for cooking thinner skin-side down. pieces of poultry, meat and fish such as steaks, drum- ¡ Turn roasting joints, grilled items or whole fish after sticks and burgers.
- Page 31 How it works en ¡ Turn or stir the food 2-3 times during cooking. ¡ Distribute foods that are in the form of separate pieces, such as bread rolls and potato products, so ¡ After cooking, leave the food to rest for 2-3 minutes. that they are spread out flat and evenly on the ac- cessory.
- Page 32 en How it works Food Accessories/cook- Shelf pos- Type of Temperature in Microwave Cooking ware ition heating °C/grill setting power setting time in → Page 10 in W mins Quiche Dark coated 200-210 35-45 quiche tin Tarte flambée Universal pan 220-230 15-25 Bake, savoury, cooked Ovenproof dish 200-220 35-55...
- Page 33 How it works en Food Accessories/cook- Shelf pos- Type of Temperature in Microwave Cooking ware ition heating °C/grill setting power setting time in → Page 10 in W mins Long-grain rice, 250 g + Covered cookware 1. 600 1. 7-9 500 ml water 2. 180 2. 13-16 Millet, whole, 250 g, + Covered cookware 1.
- Page 34 en How it works ¡ Use heat-resistant, microwave-safe cookware. 26.7 Special cooking methods and other ¡ The recommended settings are for freezer-temperat- applications ure food (-18 °C). Information and recommended settings for special ¡ Defrosting works best if you divide it into more than cooking methods and other applications, e.g.
- Page 35 How it works en ATTENTION! Metal touching the wall of the cooking compartment will cause sparks, which may damage the appliance or the inner door pane. Metal (e.g. a spoon in a glass) must be kept at least ▶ 2 cm from the cooking compartment walls and the inside of the door.
- Page 36 en How it works Food Accessory/cook- Shelf pos- Type of Temperature in Microwave Cooking ware ition heating °C power setting time in → Page 10 in W mins Rich fruit cake Deep, 23 cm dia- 130-150 150-180 meter tin Rich fruit cake Deep, 23 cm dia- 130-140 80-90 meter tin Rich fruit cake...
- Page 37 How it works en Roasting and braising ¡ For 1.5 kg, the cooking time would therefore be 95 minutes. Cooking tips for roasting and braising Cooking time range, e.g. 10-15: Follow this information when frying or braising poultry ¡ Your food will be ready within the specified range of or meat.
- Page 38 en How it works Recommended settings for baking Food Accessory/cook- Shelf pos- Type of Temperature in Microwave Cooking ware ition heating °C power setting time in → Page 10 in W mins Shortbread Baking tray 150-160 20-30 Shortbread Baking tray 140-150 25-35 Small cakes Baking tray 25-35 Small cakes...
-
Page 39: Installation Instructions
Installation instructions en Food Accessory/cook- Shelf pos- Type of Temperature in Microwave Cooking ware ition heating °C power setting time in → Page 10 in W mins Cakes Uncovered cook- 190-210 12-18 ware Chicken, halved Uncovered cook- 180-200 25-35 ware 27 Installation instructions ¡... - Page 40 en Installation instructions 27.2 Appliance dimensions 27.3 Installation below a worktop You will find the dimensions of the appliance here Observe the installation dimensions and the installation instructions when installing below a worktop. ¡ To ventilate the appliance, the intermediate floor must have a ventilation cut-out. ¡...
- Page 41 Installation instructions en ¡ To ensure that the appliance door can be opened, 27.5 Installation in a tall unit you must take the minimum dimensions into consid- Observe the installation dimensions and the installation eration when installing in a corner. The dimension instructions when installing in a tall unit.
- Page 42 en Installation instructions Pre-drill aluminium profiles to establish a screw con- 27.8 Installing the appliance nection. Slide the appliance in fully and centre it. Secure the appliance using a suitable screw. Screw the appliance into place. Note: The gap between the worktop and the appliance 27.10 Removing the appliance must not be closed by additional battens.
- Page 44 Valid within Great Britain: Imported to Great Britain by BSH Home Appliances Ltd. Grand Union House Old Wolverton Road Wolverton, Milton Keynes MK12 5PT United Kingdom Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG *9001756067* 9001756067 (030315)
