Product Installation - Midea MRF18B4AST User Manual

PRODUCT INSTALLATION

Install Instruction
Installing an Optional Ice Maker
The refrigerator comes set up for ice maker installation, This refrigerator is
compatible with Midea IM1900MD ice maker. Please refer to individual ice
maker installation instruction manual.
• WARNING: Connect to potable water supply only.
• Minimum/Maximum inlet water pressure: 138/827 kPa (20/120 psig).
Dimensions and Clearances
• Too small of a distance from adjacent items may result in the degradation
of freezing capability and increased electricity costs. Allow over 100 mm of
clearance from each adjacent wall when installing the appliance.
ATTENTION
The picture above is only for reference. The actual configuration will depend on the physical
product or statement by the distributor.
>100mm
07
>100mm
T T op V op Vie iew w
EN
