Deep Cycle LiFePO4 Lithium Battery with Built-in BMS
User Manual
WARNING: Read carefully and understand all assembly and
operation instructions before operating. Failure to follow the
safety rules and other basic safety precautions may result in
serious personal injury.
Voltage:12v~24v
Capacity:100AH~400AH
SAVE THESE INSTRUCTIONS
1 / 10
Advertisement
Summary of Contents for Netberg 12V 100Ah
- Page 1 Deep Cycle LiFePO4 Lithium Battery with Built-in BMS User Manual WARNING: Read carefully and understand all assembly and operation instructions before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Voltage:12v~24v Capacity:100AH~400AH SAVE THESE INSTRUCTIONS 1 / 10...
-
Page 2: Important Safety Information
Important Safety Information Thank you for choosing an NetBerg LiFePO4 Lithium Battery. Save the receipt and these instructions. You must read the entire manual to become familiar with this product before you begin using This product is designed for certain applications only. The distributor cannot be responsible for issues arising from modification. - Page 3 WARNING Read and understand all instructions. Failure to follow all instructions may result in serious injury or property damage. The warnings cautions, and instructions in this manual cannot cover all possible conditions or situations that could occur. Exercise common sense and caution when using this tool. Always be aware of the environment and ensure that the tool is used in a safe and responsible manner.
- Page 4 Caution This product has a built-in high-voltage power supply and battery. Keep away from children. For long-term storage(more than one month), please charge the LiFePO4 Lithium Battery to about 70%. Do not place the unit close to or in a fire or expose it to heat. Keep out of direct sunlight.
-
Page 5: Part List
Part List Reference Quantity/pcs LiFePO4 Battery Manual busbars Product Function Negative Electrode Positive Electrode 5 / 10... - Page 6 LP12-100A Picture Model 12V 100Ah Standard Voltage 12.8V(12V) Rate Capacity 100Ah Max charging current Continuous discharge current 100A Output port Positive and Negative Lifecycle 6000times Material Lithium Iron LiFePO4 Over-charge, over-discharge, over-current, short circuit BMS Protection protection Body size 330*172*215mm...
- Page 7 LP12-200A Picture Model 12V 200Ah Standard Voltage 12.8V(12V) Rate Capacity 200Ah Max charging current Continuous discharge current 200A Output port Positive and Negative Lifecycle 6000times Material Lithium Iron LiFePO4 Over-charge, over-discharge, Over-current, short circuit BMS Protection protection Body size 345*190*245mm Weight 20kg 7 / 10...
- Page 8 LP12-400A Picture Model 12V 400Ah Standard Voltage 12.8V(12V) Rate Capacity 400Ah Max charging current 100A Continuous discharge current 200A Output port Positive and Negative Lifecycle 6000times Material Lithium Iron LiFePO4 Over-charge, over-discharge, Over-current, short circuit BMS Protection protection Body size 522*240*218mm Weight 36kg...
- Page 9 LP24-200A Picture Model 24v 200Ah Standard Voltage 25.6V(24V) Rate Capacity 200Ah Max charging current 100A Continuous discharge current 150A Output port Positive and Negative Lifecycle 6000times Material Lithium Iron LiFePO4 Over-charge, over-discharge, over-current, short circuit BMS Protection protection Body size 522*240*218 mm Weight 36kg...
- Page 10 Different Rate Discharge Diagrams at 25°C Common Malfunction Judgement Malfunction Solution 1) Check whether the line connection is correct. 2) Check whether the battery pack voltage is normal. 3) Check whether the battery The battery pack cannot be connection is loose. charged and discharged 4) Disconnect the load and normally...
