SMC Networks SMC8724M Specifications page 2

TECHNICAL SPECIFICATIONS
PORTS
• 24/48 RJ-45 10/100/1000 Ports
• 4 Combo Ports (SFP/RJ45)
• 2 Stacking connectors
UPLINKS OPTIONS
• 10G Module slot
STACKING
• 8 units (MAX)
SWITCHING FABRIC
• Non-Blocking 108 Gbps - 24 port
• 156 Gbps - 48 port
PACKETS PER SECOND
• Store and forward
SWITCHING MODE
• Operating 5% to 95% (non-condensing)
MAC ADDRESS
• 16K
WARRANTY
• Limited Lifetime
BUFFER SIZE
• 2MB - 24 Port
• 4MB - 48 Port
BANDWIDTH CONTROL
• Link Aggregation
• 32 groups 8 ports per group
• Stack-wide trunking
• Rate Limiting
NETWORK & TRAFFIC CONTROL/SECURITY
• VLAN support
• 255
• Protocol based vlans
• Spanning Tree protocols
• 802.1D, 802.1w, 802.1s
• IGMP snooping
• v1,v2 - 64 groups
• Jumbo frames (9K)
• L3/L4 priority mapping
• Broadcast storm control
• Flow Control
• MAC address filter
• 802.1x
• RADIUS
• TACACS+
• ACL
• SSL/HTTPS
• SSH
EMISSIONS
• FCC Class A
• Industry Canada Class A
• EN55022 (CISPR 22) Class A
• VCCI Class A
SAFETY
• CSA/NRTL (CSA 22.2.950 & UL 1950), EN60950 (TÜV/GS)
www.smc.com
SMC8724M / SMC8748M
MANAGEMENT
• RMON
• 4 groups
• SNMP
• v1,v2 and V3
• CLI
• Web interface
• Port mirroring
• DNS
• SNTP
• Syslog remote logging
REDUNDANCY
• Dual firmware image
• Redundant Power
STANDARDS COMPLIANCE
• CE
DIMENSIONS
• 17.3 x 16 x 1.8 in
• 440 x 407 x 43 mm
WEIGHT
• 11 Lb
• 5 Kg
OPTIONAL PLUG-IN TRANSCEIVERS
SMCBGSLCX1
• 1000BASE-SX
• LC Multimode fiber
• Range - 220m for 62.5/125m, 850nm
• Range - 550m for 50/125m, 850nm
SMCBGLLCX1
• 1000BASE-LX
• LC Singlemode fiber
• Range - 10Km for 9/125m, 1310nm
SMCBGZLCX1
• 1000BASE-ZX
• LC single mode fiber
• Range - 70 to 100Km for 9/125, 1310nm
