SIEGEN S641G Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
protection
instructions
1. SAFETY
WARNING! Disconnect the spray gun from the air supply before changing accessories, servicing or performing any maintenance.
‰
Familiarise yourself with this products application and limitations, as well as the specific potential hazards peculiar to the spray gun.
9
Paint cup remains pressurised after gun is disconnected from air line.
DO NOT pull the trigger, but release the pressure by gently opening cup.
9
Maintain the spray gun in good condition (use an authorised service agent).
9
Replace or repair damaged parts. Use recommended parts only. Non authorised parts may be dangerous and will invalidate the
9
warranty.
Locate the spray gun in an adequate working area for its function, keep area clean and tidy and free from unrelated materials, and
9
ensure there is adequate ventilation and lighting.
Keep the spray gun clean for best and safest performance.
9
Ensure the air system is suitable to the spray gun air consumption, (see specifications).
9
Wear approved respiratory protection and safety eye goggles.
9
Remove ill fitting clothing. Remove ties, watches, rings, and other loose jewellery, and tie back long hair.
9
Keep children and unauthorised persons away from the working area.
9
Avoid unintentional operation.
9
DO NOT point spray gun at yourself, at other persons or animals.
8
DO NOT carry the by the air hose, or pull the hose from the air supply.
8
DO NOT use the spray gun for any purpose other than for which it is designed.
8
DO NOT allow untrained persons to operate the spray gun.
8
DO NOT get the spray gun wet or use in damp or wet locations or areas where there is condensation.
8
DO NOT operate gun if any parts are missing or damaged as this may cause failure or personal injury.
8
DO NOT direct air from the air hose at yourself or others.
8
When not in use switch the spray gun off, and disconnect from the air supply.
9
2. INTRODUCTION
Standard set-up and economy price make this spray gun ideal for applying various materials including adhesives, base coats and finishing
coats. Round/flat fan control allows spray pattern to be adjusted for any job. Brass air cap with steel needle and nozzle. Alternative set-ups
available separately.
3. SPECIFICATION
Model No............................................... S641G...............................................S642G
Standard Set-Up....................................1.4mm................................................1.8mm
Available Set-Ups.....................1.7, 1.8, 2.0mm..................................1.4, 1.7, 2.0mm
Air Pressure.............................................45psi...................................................45psi
Air Consumption.......................................4cfm....................................................4cfm
Pot Capacity............................................600ml..................................................600ml
4. AIR SUPPLY
4.1. Recommended hook-up fig.1
4.1.1. Ensure spray gun air valve (or trigger) is in the off position before connecting to the air supply.
4.1.2. You will require an air pressure of 45psi, and an air flow according to specification.
WARNING! Ensure the air supply is clean and does not exceed 45psi while operating the spray gun. Too high an air pressure and/or
‰
unclean air will shorten the product life due to excessive wear, and may be dangerous causing damage and/or personal injury.
4.1.3. Drain the air tank daily. Water in the air line will ruin the paint finish and damage the spray gun.
4.1.4. Clean air inlet filter weekly.
4.1.5. Line pressure should be increased to compensate for unusually long air hoses (over 8 metres). The minimum hose diameter
should be 1/4" I.D. and fittings must have the same inside dimensions.
4.1.6. Keep hose away from heat, oil and sharp edges. Check hose for wear, and make certain that all connections are secure.
© Jack Sealey Limited
SPRAY GUNS GRAVITY FEED 1.4MM & 1.8MM
S641G & S642G
MODEL NO:
Wear protective Wear safety
gloves footwear
Original Language Version
Wear a mask
Wear protective
clothing
S641G,S642G Issue 3 (H3F) 09/11/20
