- Page 1 Aston Commode Mobile Shower Chair (CWC003HD, CWC003ATC) Instructions for use...
-
Page 2: Parts Description
(CWC003HD) also supports up to 260 kg (41 stone). The optional self propel kit (530400815) adds two 24” wheels and brakes, with quick release axles for easy attachment and removal. If you have questions or need additional information, contact Drive DeVilbiss Healthcare Ltd or your approved supplier. parts description... - Page 3 indications symbols • Impaired mobility and/or inability to transfer to a toilet or shower • Inability to move a wheelchair (for example, those with limited strength and grip function or a lack of coordination ability of the arms / hands) •...
-
Page 4: Assembly And Adjustment
assembly and adjustment Fitting the Castors Insert the four 5” wheels to the desired position in mounting tube and secure with the ‘E’ clips provided (pic 1-2). To readjust, remove and reinsert the ‘E’ clips. Ensure they are all set to the same height. Note: Models may be supplied with a nut and bolt to secure the castor, which require a spanner and hex key... - Page 5 assembly and adjustment Moving the Bucket Push the bucket from the rear into the guide rail under the seat. Pull out backwards to remove (pic 4). Warning Ensure the chair is empty when moving the bucket to prevent trapping. Fitting the Footrests Hang the footrests in the receiver tubes at the top of the frame and swivel inwards (towards the front)
- Page 6 fitting 24” self propel wheels symbols Optional 24” wheel kits (530400815) are also available from Drive DeVilbiss Healthcare Ltd. To fit the wheels with rear castors fitted, face them forwards and lock the brakes to prevent trapping. Install each bracket so the rear castors are about 3 mm from the ground once added.
- Page 7 using the commode Before using the commode, read the safety notices below; • Check all components are secured before use. • Only use on flat ground at slow speeds. Do not use on steep or uneven terrain, kerbs or large obstacles. •...
- Page 8 using the commode Using the Brakes To lock the castors, press down on the locking tab with a foot (pic. 11). To release, press the other side of the locking tab with a foot. To lock and unlock the 24” wheels, push the lever as shown (pic. 10). Transferring Users Move the seats as close as possible to each other.
-
Page 9: Care And Maintenance
Do not use a damaged or badly worn chair. Users should routinely check for any malfunctions or changes in performance. Contact Drive DeVilbiss Healthcare Ltd or your provider for spares, or to replace damaged or worn parts. -
Page 10: Warranty
Your Drive branded product is warranted to be free of defects in materials and workmanship for one year from date of purchase. This device was built to exacting standards and carefully inspected prior to shipment. This warranty is an expression of our confidence in the materials and workmanship of our... -
Page 11: Specification
specification Standard with Comfort Safety Heavy Duty Model Seat (CWC003HD) (CWC003ATC) Maximum occupant mass 160 kg 260 kg Overall length with footrest 90 cm 90 cm Overall width 56 cm 65 cm Overall height 98 - 103 cm 98 - 103 cm Total mass 13 kg 17 kg... - Page 12 Holmfield, Halifax, West Yorkshire, HX2 9TN, GB Drive DeVilbiss Sidhil Ltd 4 Trench Road, Mallusk, Newtownabbey, BT36 4TY, Northern Ireland Drive DeVilbiss Healthcare Ltd provide these instructions for use and product markings. info@drivedevilbiss.co.uk www.drivedevilbiss.co.uk Customer Service: +44 (0) 845 0600 333...
