WLAN Module Spec-WM101-Rel
Revision
V2.1,2019.8
V2.2,2019.12
V3.1,2021.10.12
1. Introduction
WLAN module,complies with IEEE 802.11 a/b/g/n standard.
2. Specification：
Model
Material Coding
Input Voltage
Current
Connector
Interface
Antenna Connector
WM101
01-036-00143/01-036-00196/01-036-00212
5V
<1200mA
30pin，Model: DF12E(5.0)-30DP-0.5V(81)
UART0：1，115200，8N1，console
UART1：1，1000000，8N1，traffic
USB2.0：1，traffic
RGMII：1，traffic or test
2 port，MMCX Female
1
