EUROSTYLE ANDERSON-79 Assembly Instructions Manual

Assembly Instructions
ANDERSON-79 Sideboard
A (20 pcs) B (24 pcs)
8x35mm 15x12mm
F (2 pcs) G (6 pcs)
3x12mm 3.5x12mm
K (2 pcs) L (1 pc)
350mm 4x70x50mm
P (28 pcs) Q (2 pcs)
6x14x2mm 6.5x47mm
3.28.22 so
C (24 pcs) D (4 pcs)
7x35mm
H (6 pcs) I (26 pcs)
3x18mm 4x15mm
M (20 pcs) N (8 pcs)
6x20mm 6x35mm
R (2 pcs) S (2 pcs)
3
9
E (4 pcs)
J (20 pcs)
3.5x35mm
O (28 pcs) U (6 pcs)
6x10x2mm
T (2 pcs) Z (2 pcs)
446x56x150mm
PLEASE NOTE: Check that you have received all
components and hardware before assembling.
If you are missing any parts, contact your retailer.
17
1
7
5
18
8
12
12
15
16
15
11 16
11
2
19 19
V (8 pcs) W (8 pcs) X (8 pcs)
20mm 20mm
AA (2 pcs)
215x20mm
During assembly, hand tighten screws only. When
the screws are in place, tighten completely.
14
14
13
6
17
13
7
4
10
Y (1 pc)
256x60x147mm
1 of 14
