Introducing the Dual Profile GigaLAN PCI
The Dual Profile GigaLAN PCI adds Gigabit Ethernet to
your system.
Ethernet, eliminating network bottlenecks.
Features and Benefits
•
Integrated 10/100/1000 transceiver
•
Supports PCI 2.2, 32-bit/33 MHz bus
•
Crossover detection and auto-correction
•
Supports Full Duplex flow control (IEEE 802.3x)
•
3.3V signaling, 5V PCI I/O tolerant
•
Led Indicators for activity and network connection
•
Compliant with IEEE 802.3, 802.3u, 802.3ab and
802.1q
System Requirements
•
Pentium or equivalent PC with an available PCI slot
•
Windows
Server 2003 (32-/64-bit) and Vista (32-/64-bit)
•
Linux with Kernel 2.4.x or later
•
CD-ROM drive
Package Contents
•
Dual Profile GigaLAN PCI
•
Spare full height bracket
•
Driver CD
•
Quick Installation Guide
04-0323E
Dual Profile GigaLAN PCI
Quick Installation Guide
This adapter supports 10/100/1000
98SE, ME, NT 4.0, 2000, XP (32-/64-bit),
®
1
Advertisement
Table of Contents
Summary of Contents for SIIG CN-GP1011-S3
- Page 1 Dual Profile GigaLAN PCI Quick Installation Guide Introducing the Dual Profile GigaLAN PCI The Dual Profile GigaLAN PCI adds Gigabit Ethernet to your system. This adapter supports 10/100/1000 Ethernet, eliminating network bottlenecks. Features and Benefits • Integrated 10/100/1000 transceiver • Supports PCI 2.2, 32-bit/33 MHz bus •...
- Page 2 Board Layout The board shown is with a low profile bracket installed. For full height form factor systems, a full height bracket is included. 100/ACT 1000/ACT Figure 1. Dual Profile GigaLAN PCI LED Indicators Two LEDs to monitor your network connection are visitble through the slot bracket.
- Page 3 Static Electricity Discharge may permanently damage your system. Discharge any static electricity build up in your body by touching your computer case for a few seconds. Avoid any contact with internal parts and handle cards only by their external edges. Turn OFF the power to your computer and any other connected peripheral devices.
- Page 4 Insert the driver CD, check Specify a location, uncheck the other boxes, type X:\PCI\Win98SE, then click Next. (Change X: to match your CD-ROM drive) Click Next, Finish, then click Yes to restart. Windows ME Install the board and boot up Windows. At the Add New Hardware Wizard, insert the driver CD, select Automatic search for a better driver (Recommended), click Next.
- Page 5 At the Input Network Address window, click OK. At the Input Tx Early Threshold window, click OK. At the Network window, click Close. 10. Input your TCP/IP address or select DHCP, then click OK. (Check with your system administrator for the correct settings) 11.
- Page 6 For XP SP2 or later/Server 2003 SP1 or later: Select No, not this time, then click Next. Insert the driver CD, select Install the software automatically (Recommended), then click Next. Accept the selected driver, click Next, then click Finish. Restart your computer to complete the installation. Verify Windows 2000/XP/Server 2003 Installation Right click My Computer, click Manage, then click Device Manager.
- Page 7 Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. If the product is determined to be defective, an RMA number will be issued. SIIG RMA department can also be reached at (510) 413-5333.
- Page 8 6078 Stewart Avenue Fremont, CA 94538-3152, USA Dual Profile GigaLAN PCI is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft, Windows and Windows Vista are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel Corporation. Other names used in this publication are for identification only and may be trademarks of their respective companies.
