Introducing the Wireless-N Router
The Wireless-N Router is designed to support sharing
internet access wirelessly with range up to four times
farther than standard Wireless-G.
Features and Benefits
•
High Internet Access throughput
•
Allow multiple users to share a single Internet line
•
Share a single Cable or xDSL internet connection
•
Access private LAN servers from the internet
•
Four wired LAN ports (10/100M) and one WAN
port (10/100M)
System Requirements
•
Internet connection, provided by xDSL or cable
modem wih RJ-45 Ethernet port
•
Computer or network devices with wired or
wireless network interface card
•
Web browser (Microsoft Internet Explorer 4.0 or
above, Netscape Navigator 4.7 or above, Opera or
Safari)
•
Windows
2008 (32-/64-bit) / Vista (32-/64-bit)
04-0538B
Wireless-N Router
Quick Installation Guide
2000 / XP (32-/64-bit) / Server 2003 &
®
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for SIIG CN-WR0512-S1
-
Page 1: Quick Installation Guide
Wireless-N Router Quick Installation Guide Introducing the Wireless-N Router The Wireless-N Router is designed to support sharing internet access wirelessly with range up to four times farther than standard Wireless-G. Features and Benefits • High Internet Access throughput • Allow multiple users to share a single Internet line •... - Page 2 Package Contents • Wireless-N Router • Switching power adapter • User's manual CD & Quick Installation Guide Layout Figure 1: Front Panel...
- Page 3 Antenna A Antenna B Power Reset/WPS Figure 2: Back Panel...
-
Page 4: Safety Information
Safety Information In order to keep the safety of users and your properties, please follow the following safety instructions. This router is designed for indoor use only. DO NOT place this router outdoors. DO NOT put this router at or near hot or humid places, like kitchen or bathroom. -
Page 5: System And Network Setup
System and Network Setup Please follow the instructions below to build the network connection between your new wireless router and your computers, network devices. Connect your xDSL/cable modem to the WAN port of router by Ethernet cable, shown in Figure... - Page 6 Connect all your computers, network devices (network-enabled consumer devices other than computers, like game console, or switch / hub) to the LAN port of the router, shown in Figure 4. Connect the A/C power adapter to the wall socket, and then connect it to the Power socket of the router, shown in Figure 5.
-
Page 7: Connecting To Wireless Broadband Router By Web Browser
If PWD LED is not on, or any LED you expected is not on, please recheck the cabling. Connecting to Wireless Broadband Router by Web Browser After the network connection is built, the next step you should do is setup the router with proper network parameters, so it can work properly in your network environment. -
Page 8: Windows Vista
Windows XP/Server 2003 Click Start, then click Control Panel. Double click Network Connections, double click Local Area Connection, then click Properties. Select Internet Protocol (TCP/IP) and then click Properties. Select Obtain an IP address automatically , Obtain DNS server address automatically, then click OK. Windows Vista™... - Page 9 Click Manage network connections. Right click Local Area Connection, click Properties. Select Internet Protocol Version 4 (TCP / IPv4), and then click Properties. Select Obtain an IP address automatically and Obtain DNS server address automatically, then click OK. Select Internet Protocol Version 6 (TCP / IPv6), and then click Properties.
-
Page 10: Router Ip Address Lookup
Router IP Address Lookup After the IP address setup is complete, please click Start then Run, type in cmd, then click OK. At the command prompt, type ipconfig, then press Enter. Please check the IP address followed by Default Gateway (In this example, the IP address of router is 192.168.2.1, please note that this value may be different), shown in Figure 6. - Page 11 Connect the router’s management interface by web browser. After your computer obtained an IP address from router, please start your web browser, and input the IP address of router in address bar, shown in Figure 7. Figure 7...
- Page 12 Please input user name and password in the field respectively, default user name is admin, and default password is 1234, then press OK button, and you can see the web management interface of this router, shown in Figure 8. Note: If you can’t see the web management interface, and you’re being prompted to input user name and password again, it means you didn’t input username and password correctly.
- Page 13 Changing Management Password This section is located in the General Setup in the home page. Default password of this router is 1234, and it’s displayed on the login prompt when accessed from web browser. There’s a security risk if you don’t change the default password, since everyone can see it.
-
Page 14: Troubleshooting
Troubleshooting If the router is working improperly or stops responding, don’t panic! Before you contact SIIG Technical Support for help, please read this troubleshooting first. Some problems can be solved by you within very short time. Problem: Router is not responding when I want to access it by web browser. - Page 15 Solution 7: If all above solutions don’t work, contact the place of purchase for help. Problem: Can’t connect to the Internet. Solution 1: Go to Status, Internet Connection menu, and check Internet connection status. Solution 2: Please be patient, sometime Internet is just that slow.
- Page 16 Problem: My wireless client cant' locate the router. Solution 1: Broadcast ESSID set to off. Solution 2: Check that antennas are properly secured. Solution 3: Are you too far from your router? Try to get closer. Solution 4: Please remember that you have to input ESSID on your wireless client manually, if ESSID broadcast is disabled.
- Page 17 Problem: The password is wrong. Solution 1: Password is case-sensitive. Make sure the Caps Lock light is not on. Solution 2: If you forgot the password, do a hard reset. Problem: The router becomes hot. Solution 1: This is not a malfunction, if you can keep your hand on the router’s case.
- Page 18 Blank Page...
-
Page 19: Technical Support And Warranty
• Clearly write your RMA number on the top of the returned package. SIIG will refuse to accept any shipping package, and will not be responsible for a product returned without an RMA number posted on the outside of the shipping carton. - Page 20 Fremont, CA 94538-3152, USA Ph: 510-657-3308 Wireless-N Router is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft, Windows and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other contries.
