8" AC BLOWERS
9513
9513-AU
9513-E
9513-05
9513-05E
9514
9514-AU
9514-E
9514-05
9514-05E
9514-06
9514-06E
9514-25
9514-25AU
9514-25E
9534
9534-15
9534-25
8" DC BLOWERS
9506
9506-01
9506-25
9537
9537-15
9537-25
Read and understand all instructions before using this product. Open carton carefully
and inspect product for damage caused by carrier. If any damage is found, report and
submit claim to carrier.
USER'S MANUAL
for
AXIAL BLOWERS
1
12" AC BLOWERS
9509
9509-01
9509-01E
9509-50
9509-50AU
9509-50E
12" DC BLOWER
9529
16" AC BLOWERS
9515
9515-AU
9515-E
9515-01
9516
20" AC BLOWERS
9525
9525-E
9525-01
9525-50
26" AC BLOWER
9530
9530-220T
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Allegro Industries 9513
Summary of Contents for Allegro Industries 9513
- Page 1 USER’S MANUAL AXIAL BLOWERS 8” AC BLOWERS 12” AC BLOWERS 9513 9509 9513-AU 9509-01 9513-E 9509-01E 9513-05 9509-50 9513-05E 9509-50AU 9514 9509-50E 9514-AU 12” DC BLOWER 9514-E 9514-05 9529 9514-05E 16” AC BLOWERS 9514-06 9514-06E 9515 9514-25 9515-AU 9514-25AU 9515-E...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE INTRODUCTION ......................3 DESCRIPTION ......................3-4 SAFETY PRECAUTIONS ................... 4-5 WARNINGS AND LIMITATIONS..................6 OPERATING INSTRUCTIONS ................... 6-8 SPECIFICATIONS ......................9 MAINTENANCE ......................10 STORAGE ........................11 CONFINED SPACE ..................... 11 HAZARDOUS LOCATION INFORMATION ..............12 WARRANTY &... -
Page 3: Introduction
INTRODUCTION This manual provides instructions for the use and maintenance of Allegro Industries Axial Blowers. You must read and understand this manual and be trained in the proper use of the equipment before using it in a contaminated atmosphere. There are many federal, state and local codes and regulations governing sales, construction, installation and/or use of products for certain purposes which may vary. -
Page 4: Safety Precautions
Com-Pax-ial 8” Blower with 15’ Ducting and Canister 9534-15 Com-Pax-ial 8” Blower with 25’ Ducting and Canister 9534-25 The following are available with a 12-volt DC motor, models include: Standard Axial 8” Blower 9506 Standard Axial 8” Blower with 15’ Ducting Canister 9506-01 Standard Axial 8”... - Page 5 DO ensure the blower is in its original, factory configuration and has not been modified. Any modifications may result in potentially dangerous configurations that can lead to property damage and/or personal injury. As well as voiding the manufacturer’s warranty DO ensure operator(s) are in adequate physical condition, mental health and not under the influence of any substance (drugs, alcohol, etc.) which might impair vision, dexterity or judgment.
-
Page 6: Warnings And Limitations
WARNINGS AND LIMITATIONS Manufacturing tolerances and specific operating parameters will affect the overall flow rate(s) for each particular blower. Actual flow rate will decrease when the total length of the ducting is increased more than 15 feet (7.6m). Actual flow rates may change if blower is used with ducts manufactured and/or supplied by other sources. - Page 7 For the 8” & 12” Com-Pax-ial blowers, duct can be secured on either side of blower with canister only. For the 8” 9513 Series Axial blowers an optional inlet adapter (P/N: 9500-03) must be used. i. Remove the inlet grill.
- Page 8 DANGER! Before using the blower, check all applicable federal, state, industry and local regulations regarding the use of flame resistant and/or self-extinguishing duct materials for the intended job applications. It is the responsibility of the owner(s) and/or operator(s) to determine that the duct material in use for the job application meets all applicable fire code and OSHA requirements.
-
Page 9: Specifications
SPECIFICATIONS SIZE PART No VOLTAGE WEIGHT MINIMUM GENERATOR SUGGESTION (FREE AIR) 9513 120V/60 Hz 19 lbs. 1275 2 KW * 8” 9513AU/-E 220V/50Hz 19 lbs. 9514 120V/60Hz 32 lbs. 2 KW * 8” 9514AU/-E 220V/50Hz 32 lbs. 9514-25 120V/60Hz 46 lbs. -
Page 10: Maintenance
MAINTENANCE Maintenance & Repair: Use only genuine Allegro approved, replacement parts for maintenance and repair. Use of parts manufactured by others can result in property damage and/or personal injury. Follow the service instructions as outlined in the Maintenance section of this User’s Manual. ... -
Page 11: Storage
STORAGE The proper procedure for long-term storage of the blower will protect it against the effects of corrosion and damage. If the blower is not to be operated for a period of 30 days or more, proceed to store as follows: 1. -
Page 12: Hazardous Location Information
Only Statically Conductive Ducting may be used with Explosion Proof Blowers. The Allegro Explosion Proof Blowers are designed to be used in the following hazardous locations: Blower 9513-05 9514-05 9514-06 9509-01 9515-01 9525-01 Class Division 1 &... -
Page 13: Warranty & Return Policy
ALLEGRO INDUSTRIES LIMITED WARRANTY AND WARRANTY SERVICE AND RETURN POLICY Express Warranty The warranty obligations of Allegro Industries (“Allegro”) are limited to the terms set forth below: All products, equipment and parts (collectively “Product” or “Products”) sold by Allegro, either directly to its customers, or indirectly from its suppliers or distributors to their customers, are warranted, to the original end-user purchaser who/that receives the original, unaltered Product (“Purchaser”), to be free from defects in workmanship and materials under normal use... - Page 14 The Purchaser may obtain this RMA# by telephoning Allegro’s Customer Service number at (800) 622-3530, or by requesting it in writing by mailing the written request to Allegro Industries, 1360 Shiloh Church Road, Piedmont, South Carolina 29673, or by faxing the written request to Allegro Industries at (800) 362-7231.
- Page 15 Warranty Terms This Limited Warranty represents the complete and exclusive agreement covering this subject matter between Allegro and Purchaser and supersedes any prior agreements and/or communications regarding the subject matter hereof. The terms of this Limited Warranty shall be governed and construed in accordance with the laws of the State of California, without regard to any conflict of law principle that would result in the laws of any other jurisdiction governing this Limited Warranty.
