CEP CT63 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CT63 Terminal
User Manual
Revision 1.7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CT63 and is the answer not in the manual?

Questions and answers

Related Manuals for CEP CT63

Summary of Contents for CEP CT63

  • Page 1 CT63 Terminal User Manual Revision 1.7...

  • Page 2: Important Information

    Important information This technical description contains important information for start up and use of the CT63 Terminal. Read it carefully before you start working with the CT63 Terminal. The warranty will be void should damage occur due to non-compliance with these instructions for use.
  • Page 3 In case those measurements with the opened housing are necessary, an isolating-transformer has to be integrated for safety reasons. Alternatively the voltage can be supplied by an appropriate power supply which complies with the safety regulations. All wiring work has to be done in a voltage free state only...

  • Page 4: Table Of Contents

    Table of Contents Important information ..............................2 Safety Instructions ................................2 Mechanical Description ............................7 Overview ................................7 Physical Dimensions and Weight ........................8 Electrical Description ..............................9 Power Connector .............................. 9 Antenna Connector ............................10 SIM card reader ............................... 11 RS232 Serial Port .............................
  • Page 5 CT63 with DSUB15 connector with l2C and SPl interface ................22 CT63 with EGS5 (Java) Module & GPIO’s ......................23 CT63 with Mini USB audio interface ....................... 25 CT63 with Mini USB with USB – Power (host powered) ................. 25 Technical Data ................................. 27 CEP Certified Accessories ............................29 Abbreviations ................................
  • Page 6 Table 5: Operating states of the power up LED ......................16 Table 6: Power consumption in idle and low power mode .................... 17 Table 7: CT63 with DSUB15 connector with l2C and SPl interface ................. 22 Table 8: Mini USB Pin Signal ............................23 Table 9: RJ11 Connector Description ..........................

  • Page 7: Mechanical Description

    Mechanical Description 1.1 Overview The pictures below show the mechanical design of the CT63 Terminal along with the positions of the different connectors and mounting holes. The CT63 Terminal case is made of durable PC/ABS plastic. Figure 1: Connector on rear side of the Terminal...

  • Page 8: Physical Dimensions And Weight

    Please note the following:  Mounting holes positioned at two of the corners make it possible to securely bolt the modem into your application.  Keypad, display, microphone, speaker and battery are not part of the modem.  The SIM card is mounted in the modem, accessible by the user under a lid without any tools. ...

  • Page 9: Electrical Description

    Electrical Description The modem uses the following standard connectors:  RJ11 6-way (power connector)  Mini USB (USB 2.0)  SIM card reader  FME male coaxial jack (antenna connector)  Sub-D female socket, 9 pin (RS232 serial port) 2.1 Power Connector An RJ11 6-way connector, as shown and described below, serves as a means of supplying and controlling DC power to the modem.

  • Page 10: Antenna Connector

    Signal Direction Limits Description Input 5 – 32V Positive power input, DC Not connected Not connected Not connected Not connected EMERG_OFF Input 5 – 32V Active high control line used to switch off > 5V, V < .5V Power off: t >1s TO_IN Input 5 –...

  • Page 11: Sim Card Reader

    2.3 SIM card reader The CT63 Terminal is fitted with a SIM card reader designed for 1.8V and for 3V SIM cards. It is the flip- up type which is lockable in the horizontal position and is accessed through a removable panel.

  • Page 12: Control Signals - Rts, Cts, Dtr, Dsr, Dcd, Ri

    The modem supports a standard USB 2.0 Full Speed slave interface interface for AT-commands. The maximum baud rate to communicate with the CT63 Terminal is up to 12Mbit/s. Drivers for several operating systems (e.g. Windows Vista, Windows XP or Linux) are available. Please ask us (support@cepag.de).
  • Page 13 Signal VUSB not connected Table 4: Mini USB Pin Description...

  • Page 14: Operation

    Operation 3.1 Switch ON the modem There are two ways to switch on the modem, once power is applied:  assert TO_IN to high level for > 1s  activate the RS232 control line DTR The modem is fully operational after 4 seconds. Logging onto a network may take longer than this and is outside the control of the modem.

  • Page 15: Switching Off The Modem

    3.2 Switching OFF the modem There are two ways to switch off (power down) the modem as described below:  use the “AT^SMSO” command  EMERG_OFF to high level for t < 1s A delay of up to 10s is experienced as the modem logs off the network 3.3 Using low power mode of the modem Below are some short descriptions on how to enter and exit the low power state of the modem.

  • Page 16: Operating States / Leds

    3.4.1 Power up LED (green LED in the middle) The modem has a green power up LED, as depicted below, which is used to indicate various operating states. These states are described in following table. Operating state of CT63 Terminal Power up LED state Device off...

  • Page 17: Power Consumption

    4.2 General precautions The CT63 Terminal as a stand alone item is designed for indoor use only. To use outside it must be integrated into a weatherproof enclosure. Do not exceed the environmental and electrical limits as specified in “Technical Data”.

  • Page 18: Sim Card Precautions

     Ensure the cables, supplying power, audio headset, and input cable to the CT63 Terminal, does not exceed 3 metres.  To protect power supply cables and meet the fire safety requirements when the unit is powered from a battery or a high current supply, connect a fast 1.25A fuse in line with the positive supply.

  • Page 19: Installation Of The Modem

    Installation of the modem This chapter gives you advice and helpful hints on how to integrate the CT63 Terminal into your application from a hardware perspective. Please read the information given in “Safety and Product Care”, page 10 and then read the information in this section before starting your integration work.
  • Page 20 Where access is restricted, it may be easier to connect all the cables to the modem prior to securing it in the application.  Securely attach the CT63 Terminal modem to the host application using two 3mm diameter pan-head screws 5.3 Antenna 5.3.1 General...
