TMG -SCM61 Product Manual

61 -in skid steer concrete mixer

Hide thumbs

Table Of Contents

Quick Links

61-IN SKID STEER

WWW.TMGINDUSTRIAL.COM

IN SKID STEER CONCRETE MIXER

Please read the product manual completely before assembly Check

against the parts list to make sure all parts are received

Wear proper safety goggles or other protective gears while in assembly

Missing parts or questions on assembly?

Please call: 1-877-761-2819 or email: cs@tmgindustrial.com

Please call: 1

Do not return the product to dealer, they are not equipped to handle your

requests

PRODUCT MANUAL

PRODUCT

CONCRETE MIXER

MODEL:

cs@tmgindustrial.com

Toll Free:1-

TMG-SCM61

-877-761-2819

Table of Contents

Need help?

Do you have a question about the TMG-SCM61 and is the answer not in the manual?

Questions and answers

Summary of Contents for TMG TMG-SCM61

Page 1 61-IN SKID STEER IN SKID STEER CONCRETE MIXER CONCRETE MIXER MODEL: TMG-SCM61 Please read the product manual completely before assembly Check Please read the product manual completely before assembly Check Please read the product manual completely before assembly Check against the parts list to make sure all parts are received...
Page 2: Table Of Contents
TABLE OF CONTENTS TO THE OWNER..........................2/14 SAFETY PRECAUTIONS........................3/14 CONCRETE MIXER ASSEMBLY......................7/14 OPERATION INSTRUCTIONS......................11/14 MAINTENANCE INSTRUCTIONS.......................12/14 STORAGE INSTRUCTIONS........................13/14 SPECIFICATIONS..........................14/14 W W W . T M G I N D U S T R I A L . C O M P 1 / 1 4 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
Page 3: To The Owner
TO THE OWNER GENERAL COMMENTS Congratulations for having this concrete mixer! Your concrete mixer was carefully designed and manufactured to give you years of dependable service. Your concrete mixer will require some minor maintenance(such as cleaning and lubricating) to keep it in top working condition. Be sure to observe all safety precautions and maintenance procedures as described in this manual.
Page 4: Safety Precautions
SAFETY PRECAUTIONS The concrete mixers are designed to be easy to use and maintain. They are operated by the skid steer auxiliary hydraulics. The concrete mixers mount to the toolbar or quick attach mechanism for easy mounting. BEFORE OPERATION 1. The operator must read the operation manual carefully before installation, operation or maintenance.
Page 5 SAFETY PRECAUTIONS These are common practices that may or may not be applicable to the products described in this manual. W W W. T M G I N D U S T R I A L . C O M P 4 / 1 4 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
Page 6 SAFETY PRECAUTIONS SAFETY PRECAUTIONS W W W . T M G I N D U S T R I A L . C O M W W W . T M G I N D U S T R I A L . C O M P 5 / 1 4 T o l l F r e e : 1 - - 8 7 7 - 7 6 1 - 2 8 1 9...
Page 7 SAFETY PRECAUTIONS SAFETY PRECAUTIONS W W W . T M G I N D U S T R I A L . C O M W W W . T M G I N D U S T R I A L . C O M P 6 / 1 4 T o l l F r e e : 1 - - 8 7 7 - 7 6 1 - 2 8 1 9...
Page 8: Concrete Mixer Assembly
CONCRETE MIXER ASSEMBLY W W W. T M G I N D U S T R I A L . C O M P 7 / 1 4 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
Page 9 CONCRETE MIXER ASSEMBLY PART NO. S/N NUMBER PART DESCRIPTION QTYS NOTE 0310L04.01 BUCKET BODY 0310L04.04 FENCE 0310L04.02 COVER GB5783-2000 BOLT M16X40 GB93-1987 SPRING WASHER D16 GB97.1-2000 FLAT WASHER D16 0310L04.05-01 SPROCKET PRESSING PLATE 0310L04.05-02 BIG SPROCKET 0310L04.05-04 ROTATING SHAFT 55*70-40 BEARING GB5783-2000 BOLT M10X25...
Page 10 CONCRETE MIXER ASSEMBLY PART NO. S/N NUMBER PART DESCRIPTION QTYS NOTE 0310L04.05-07 PRESSING PLATE GB5783-2000 BOLT M8X25 GB93-1987 SPRING WASHER D8 GB97.1-2000 FLAT WASHER D8 GB5783-2000 BOLT M16X50 GB5789-2000 BOLT M8X16 0310L04.07-01 CONNECTING ROD GB5783-2000 BOLT M12X40 GB97.1-2002 FLAT WASHER D12 GB6128-2000 LOCK NUT M12 0310L04.07.04...
Page 11 CONCRETE MIXER ASSEMBLY PART NO. S/N NUMBER PART DESCRIPTION QTYS NOTE F381CACA101005-2000 OIL HOSE F381CACF181810-2000 OIL HOSE IE18LM33X2ED JOINT IE10LM14X1.5ED JOINT F6KW MOTOR GB5783-2000 BOLT M16X65 GB93-1987 SPRING WASHER D16 GB97.1-2000 FLAT WASHER D16 0310L04.03-02 BIG SPROCKET 0310L04.03-01 PRESSING PLATE GB5783-2000 BOLT M12X35 GB93-1987...
Page 12: Operation Instructions
OPERATION INSTRUCTIONS The concrete mixer has the lateral discharge hole with manual opening. It can help to realize much more quickness and high efficiency to discharge the material. Attach the concrete mixer to the toolbar or quick attach mechanism of your skid steer loader.
Page 13: Maintenance Instructions
MAINTENANCE INSTRUCTIONS 1. Always keep the clean hydraulic oil, keep the hose joint clean, if the hydraulic oil is mixed with dirt, it will possibly cause the whole operation system abnormally. 2. Daily check all hydraulic lines, make sure the connection of the hydraulic line good, the pipe without distortion, wear, cracking, no loose joint to leak.
Page 14: Storage Instructions
STORAGE INSTRUCTIONS 1. Clean all the debris, all mud, dirt and grease. 2. Inspect the unit for bent, loose, cracked, damaged or missing parts, Order any parts required, and make the necessary repairs to avoid delays when starting next season. 3.
Page 15: Specifications
SPECIFICATIONS MODEL TMG-SCM61 TOTAL LENGTH (MM) 1100 TOTAL WIDTH (MM) 1875 TOTAL HEIGHT (MM) 1100 TOTAL WEIGHT (KGS) BUCKET CAPACITY (CBM) 0.45 SYSTEM FLOW (L/MIN) 60-110 MAX. PRESSURE (MPA) 16-21 DISCHARGING MATERIAL FORM FRONT OR SIDE DISCHARGING W W W . T M G I N D U S T R I A L . C O M...
