Summary of Contents for AquaMaster Master Series
- Page 1 www.aquamasterfountains.com MASTER THE POWER AND BEAUTY OF WATER ® Masters Series 50 Hz 1-5 HP Horizontal Owner’s Manual Floating Fountains Fixed Base Fountains Aeration Lighting Accessories...
- Page 2 Underwriters Laboratories, Inc. (UL) for safety in the USA and Canada. AquaMaster® will continue to build the best units to assure you, the customer, of many years of enjoyable and reliable service.
-
Page 3: Table Of Contents
Troubleshooting Guide ....................23 SHIPPING CLAIMS When you receive your AquaMaster® unit, examine the package for any signs of external damage it may have sustained enroute. If there is apparent damage either outside the box or to its contents, make a claim with the shipper immediately. Save the original shipping carton and the packing material if a claim is to be filed. -
Page 4: Assembly Instructions
MASTERS SERIES 1-5 H.P. HORIZONTAL ® ASSEMBLY INSTRUCTIONS WARNING: Read these instructions carefully. Failure to follow these instructions could cause a malfunction of the system. Improper installation, wiring or anchoring could result in property damage or bodily injury. This unit has been shipped partially assembled to avoid damage during shipment. Please refer to enclosed drawings for part locations. - Page 5 ASSEMBLY INSTRUCTIONS (CONT.) #1 Float Assembly #5 Perimeter with Float Tube Bolt #10 Float Support Bracket #6 AquaLock (ALC) #4 Screws and Washers #2 Elbow #3 Screened Power #7 Wire Harness Unit Assembly #9 Power Cable and Cable Support Grip Page 2 Page 3...
- Page 6 NIGHT GLOW LIGHTING SYSTEMS ASSEMBLY INSTRUCTIONS (Pictures used for representational purposes, may not depict actual product) Check to see that all light fixture retaining bands are in place. To install the retaining bands follow the instructions below, to install light fixtures, skip to step 2. To install light fixture retaining band on existing float: Place the unit on level surface with motor down and float up.
- Page 7 NIGHT GLOW LIGHTING ASSEMBLY INSTRUCTIONS (CONT.) To remove light fixture from float with light fixture retaining band: Pull any fixture toward the open side of the float. As the fixture meets obstruction of the float, angle the fixture slightly as shown to clear the float and continue to pull away from the float center line.
-
Page 8: Electrical Assembly Instructions
ELECTRICAL CONNECTION – 50Hz Electrical connections must be completed by a licensed electrician or installer in accordance with European community, national, local codes or ordinances. CAUTION: Aeration systems require the use of a residual current device (RCD) with a rated residual operating current not exceeding 30 mA for safe operation. - Page 9 ELECTRICAL CONNECTION – 50Hz (cont.) 2. To connect power to control panel: A) Connect Line 1 to L1 on the terminal strip. B) Connect Line 2 to L2 on the terminal strip. C) Connect Line 3 to L3 on the terminal strip (3 Phase Only). D) Connect the neutral to N on the terminal strip (3 Phase Only).
-
Page 10: Digital Timer Operating Instructions
TIMER OPERATING INSTRUCTIONS 1. To set the time, hold down the CLOCK Key while pressing either the HOUR or MINUTE keys. Continue pressing until the desired number is shown. Then simply lift finger off the CLOCK Key to set. 2. To Set Program (ON/OFF) times: Press the TIMER Key once to enter into program mode. -
Page 11: Anchoring Instructions
ANCHORING INSTRUCTIONS CAUTION: If the unit is not properly anchored with adequate tension, the unit will rotate when in operation, resulting in twisted and damaged electrical cable(s). FIGURE 1 is most applicable for a smaller pond, or one that is easily accessible from two sides. - Page 12 ANCHORING INSTRUCTIONS (CONT.) CAUTION: If the unit is not properly anchored with adequate tension, the unit will rotate when in operation, resulting in twisted and damaged electrical cable(s). In a larger body of water or where vandalism is a concern, FIGURE 2 is the preferred method.
- Page 13 FOUR-POINT ANCHORING At times, because of pond depth, pattern, or pond size, four-point anchoring may become necessary or desirable to prevent your unit from rocking. 1. Below are two drawings that depict the manner in which the anchors are to be deployed.
-
Page 14: Winterization
WINTERIZATION AquaMaster® strongly suggests removing the unit for winter if you experience long periods of cold, freezing weather. Damage to the float, lighting, and power unit could result from ice around the unit or lighting system. Also, possible damage to the motor could result if the propeller or impeller is frozen in the ice when the unit tries to start. -
Page 15: Maintenance
For warranty repair or replacement consideration, equipment must be pre-approved and returned to the AquaMaster® factory for inspection, repair or replacement. If you have a lot of debris floating in your pond (plastic bags, fishing line, etc.) you may choose to perform maintenance on all units annually,... -
Page 16: Product Warranty
MASTERS SERIES® 1-5 HP IN-WATER COMPONENTS PRODUCT WARRANTY AQUAMASTER®, hereinafter referred to as The Seller, warrants your Series 304 and/ or Series 316 Stainless Steel 1-5 HP motor and seal assembly, float and underwater power cable (referred to as in-water components) for a period of 3 years on parts and 3 years on labor, when used in fresh water only. -
Page 17: Underwater Night Glow Lighting System Warranty
The warranty period commences on the date the unit is installed as shown on the warranty registration card that must be returned to AquaMaster®. If no card has been returned, the warranty commences on the date the unit was shipped from our factory. -
Page 18: 220 Volt Lamp Replacement Procedure/Break Down
Failure to keep the lamps clean will result in premature burn out. c. Lighting fixtures with LED lamps must be returned to AquaMaster® for service. There are no field serviceable components inside the fixtures. - Page 19 Housing Single Hub 880106 880106 880106 Housing Double Hub 880107 880107 880107 Cord Connector 860015 860015 860015 NOTE: Lighting fixtures with LED lamps must be returned to AquaMaster® for service. There are no field serviceable components inside the fixtures. Page 17...
-
Page 20: Internal Fountain Components List
ITEM QTY PART # DESCRIPTION 760335 FLOAT ASSEMBLY WITH TUBE (1HP) 760336 FLOAT ASSEMBLY WITH TUBE (2-3HP) 760337 FLOAT ASSEMBLY WITH TUBE (5HP) 820195 FLOAT TUBE ASSEMBLY, 1-3HP 820196 FLOAT TUBE ASSEMBLY, 5HP #244 O-RING NOZZLE O-RING, 1-3HP #252 O-RING NOZZLE O-RING, 5HP #244 O-RING HOUSING O-RING, 1-3HP #252 O-RING HOUSING O-RING, 5HP 820181... -
Page 21: Internal Parts Drawing
MD002-569 Page 19... -
Page 22: Power Unit Parts Lists
Page 20... -
Page 23: Power Unit Drawing
MD002-246 Page 21... -
Page 24: Aqualock (Alc) Components View
MATCHING WIRE COLOR TO PIN LOCATION FOR AQUALOCK (ALC) USE FOR DIAGNOSTIC PURPOSES ONLY Page 22... -
Page 25: Troubleshooting Guide
TROUBLESHOOTING GUIDE WARNING: Turn off all electrical power before servicing your unit. To prevent accidental startup of your unit while repairs are in process or while servicing your unit, the main electrical equipment disconnect should be turned off and the panel should be locked out with a padlock. PROBLEM: Unit will not operate. - Page 26 Notes:...
- Page 27 Notes:...
- Page 28 Worldwide leader in the engineering and manufacturing of fountains and aeration equipment MASTER THE POWER AND BEAUTY OF WATER for ponds and lakes Please Contact Us For Floating Fountains Additional Information Masters Series® Classic Series Address: Celestial Fountains® 16024 County Road X Kiel, Wisconsin 53042 Fixed Base Fountains Fixed Base Fountains Series...
