Summary of Contents for SYXmoto 58CC
- Page 1 58CC 4-Stroke Dirt Bike...
- Page 2 Distributed by IceBear Powersports Address: 10580 mulberry ave. Fontana CA 92337 WWW.SYXMOTO.COM *Please note that this is a generic manual. The model of the vehicle you have may slightly differ from the pictures shown in this manual. Instructions Please read this owner’s manual carefully before using this product! This is very important! It’s required for driver’s safety and vehicle’s maintenance!
-
Page 3: Table Of Contents
Contents Safety warning …………………….……………..............2 Assembling …………………………………................3 Emergency kill switch and speed limiter …………………………………......4 Tire pressure gauges …………………………………............5 Operating / Inspection before riding ..............5 Idling (inspection) …………………………………..............5 Front, rear suspension (inspection) ………………………………........6 Front brake system (inspection) …………………………………........6 Rear brake system (inspection) …………………………………........6 Tool bag (inspection) …………………………………............6... -
Page 4: Safety Warning
Safety warning 1. This vehicle is not a toy. 2. Children must be trained before operating this vehicle. 3. Be sure of children's riding capability. 4. Children must understand the manual and the importance of warnings in the manual. 5. User must read the owner’s manual carefully and understand the content of the manual. -
Page 5: Assembling
Assembling guide 1. Place the packing box on the flat ground, and then open it. (With scissors or cutter) 2. Use 10# open-end wrench and 6# Allen wrench to take apart the packing metal for non- iron cage packed models, this step is not applicable. 1st step: Please install the rear shock absorber, and tighten nuts on both sides with 25N.m force. -
Page 6: Emergency Kill Switch And Speed Limiter
Emergency kill switch The switch is located on the left side of the handlebar. Pull Kill switch tether or press down on the red button and the engine will be stopped. The Kill switch tether can be fastened to the rider in case there is an emergency. -
Page 7: Tire Pressure Gauges
The throttle limiter is located on the right side of the handlebars. The speed limiter can be adjusted to Two-thirds of the normal speed. Tire gauge The proper tire pressure can provide the maximum stability and performance. Check and adjust the tire pressure regularly, to make sure the pressure is correct. -
Page 8: Front, Rear Suspension (Inspection)
Front brake inspection Check the front brakes. 1. Front brake handle is mounted on the right side of the handlebars pull the lever making sure the brake is engaging and firm. 2. Check that tire rotation is good after releasing the brake lever. 3. -
Page 9: Starting
Every check and inspection step above is necessary. Danger exists when riding. Please conform to the above process before riding and operating this vehicle. The warning label on the surface of the vehicle includes important safety information. User must fully understand. This vehicle may cause extreme injury and could even lead to death if the above mentioned procedure is not followed. -
Page 10: Storage
2. Chain should be always lubed with chain lubricant. Storage The performance will be reduced if you do not use vehicle for a long time and properly prepare the vehicle. Before storage, vehicle must be checked to ensure it is in a good condition. -
Page 11: Maintenance List, Age Warning And Warning Labels
Maintenance list (Please operate according to maintenance list) I：Inspection，This includes servicing, cleaning, lubricating, oiling, repairing or replacing if necessary A：Adjustment C：Cleaning R：Replacement L：Lubrication Maintenance period Odometer (km) Everyday check Items 1500 2500 3500 4500 before riding Spark Plug Fuel System Engine Oil Valve Gap I, A... -
Page 12: Accessory Description/Spec Data/Circuit Diagram
Accessory description/Spec data/Circuit diagram PRODUCT NAME DIRT BIKE PRODUCT MODEL LENGTH X WIDTH X HEIGHT 1230×550×80 ENGINE MODEL 1P43FMY (mm) AXLE BASE(mm) BORE×STROKES 43.8×38.2 DISPLACEMENT(m MIN GROUND CLEARANCE(m 57.6 l） TURNING CIRCLE DIAMENTER 2900 IDLE SPEED(r/min） 3300±200 (mm) DRY WEIGHT(kg) RATED POWER HP 1.48/7000... - Page 13 (r/min） MAXIMUM TORQU WETWEIGHT(kg) 2.01/7000 N.m(r/min） ≤50 RATED LOAD QUALITY(kg) CARBURETOR TYPE MP11 AUTOMATIC MAXIMUM SPEED(Km/h) CLUTCH TYPE CENTRIFUGAL FUEL TANK CAPACITY(L) SPARK PLUG TYPE A7TC IMPEDANCE FRONT/REAR BRAKE SHOCK SPRING MUFFLER TYPE COMPOUND ABSORBER TYPE MUFFLER FRONT/REAR BRAKE TYPE DISC BRAKE STARTING MODE PULL START...
- Page 14 Installation Instruction 1.Open packing box, take out 2. All tools you need as below; 3.Remove the front brake motorcycle and accessories. Matching pot with scale mark. caliper; prepare install front wheel. 4.Install the front wheel, put the 5.Install the front brake caliper. 6.Install the handle-bar and spacer before fixed nut.
- Page 15 7.Install the front fender. 8.Install the front number plate. 9.Install the handle-bar pad. Start enjoy your riding! Search SYX MOTO on Youtube and Facebook for video instructions.
