Summary of Contents for EGL 205222
- Page 1 FAN REMOTE CONTROL Installation Manual 205222 Use & Care Guide Warranty Information 4 SPEED Remote Control...
- Page 2 Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local council for more information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the ground water and get into the food chain, damaging your health and well-being. EGLO Lighting has a policy of continual product improvement and development, dimensions, hardware and designs may change to reflect this policy.
-
Page 3: Table Of Contents
CONTENT FOR YOUR SAFETY: ................................ 4 BEFORE INSTALLATION: ..............................4 INSTALLATION: ................................5 WIRING CONNECTIONS: ..............................6 OPERATING YOUR REMOTE CONTROL: ........................6 TROUBLE SHOOTING: ..............................7 WARRANTY CLAIMS ON INSTALLED PRODUCTS: ......................8 1. AUSTRALIAN CONSUMER LAW: ..........................8 2. -
Page 4: For Your Safety
Step Dimming and Timer functions, which will allow the flexibility to control your fan, your way. Your EGLO remote control requires 2 x AAA batteries ( included) to operate. Ensure only quality batteries are used and replace batteries regularly. Specifications Model: 205222 Input: 220-240V, 50/60Hz Rating: Fan: 100W (min. 15W), Light: 300W (min. 5W) Frequency: 433.92MHz... -
Page 5: Installation
INSTALLATION: IMPORTANT: Check that the power is disconnected, and/or the mains switched off at the circuit box to ensure all pole isolation of the power supply. Note: For safe use of the connected fan, and all-pole disconnection MUST be incorporated into the fixed wiring in accordance with the wiring rules, as outlined in clause 7.12.2 of AS/NZS 60335-1 for meeting the minimum electrical safety of this standard. -
Page 6: Wiring Connections
WIRING CONNECTIONS: WARNING: FOR YOUR SAFETY ALL ELECTRICAL CONNECTIONS MUST ONLY BE UNDERTAKEN BY A QUALIFIED AND LICENSED ELECTRICIAN. Note: For safe use of the connected fan, and all-pole disconnection MUST be incorporated into the fixed wiring in accordance with the wiring rules, as outlined in clause 7.12.2 of AS/NZS 60335-1 for meeting the minimum electrical safety of this standard. -
Page 7: Trouble Shooting
TROUBLE SHOOTING: WARNING: FAN MUST BE SWITCHED OFF AND ISOLATED BEFORE COMMENCING ANY TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY No functions operate Main power not restored. (*) Replace fuse. Turn ON circuit breaker. Turn ON wall switch. Wall controller is not removed and interferes with (*) Remove the fan wall controller and replace with ON/OFF remote operation. -
Page 8: Warranty Claims On Installed Products
WARRANTY CLAIMS ON INSTALLED PRODUCTS: EGLO Lighting (EGLO) will not be liable for charges incurred by the consumer for rectification, deinstallation or reinstallation unless appro- ved by EGLO management in writing. All claims are to be submitted in writing to head office with a copy of the original purchaser’s receipt, a copy of the certificate of compli- ance and a completed Warranty Claims Form. -
Page 9: Commercial Use
3. EGLO products not installed in accordance with the product’s installation instructions for use and/or specifications. 4. EGLO products not operated in accordance with the instructions for use, or specifications. 5. EGLO products that have been modified in any manner. 6. - Page 10 4 SPEED Remote Control...
- Page 11 INSTALLER DETAILS Name: Licence No.: Install Date: Cert of Elect Safety: YES PH - Mobile: Email: PRODUCT DETAILS EGLO Model No.: 205222 Connected EGLO Fan Name: Fault Details: EGLO USE ONLY Date: Electrican: Quote No.: Cost to Rectify: Approved By:...
- Page 12 EGLO LIGHTING AUSTRALIA 5/339 Archerfield Road Richlands Queensland 4077 www.eglo.com.au 4 SPEED Remote Control...
