- Page 1 VK100 Abyss LED Abyss LED 100w DMX User Manual M126 Please read the instruction carefully before use...
-
Page 2: Technical Specification
The equipment must be installed by professionals. It must be installed in a place where is out of the reach of people and no one can pass by or under it. 2. Technical Specification ◇ The VK100 Abyss LED is a 100w LED Water wave effect, suitable for big clubs, stages, and events ◇ Different working modes:... - Page 3 ◇ Power Consumption: 105W ◇ Light Source: 1 x 100W cold white LED ◇ Weight: 6.2Kgs ◇ Dimension: 309 x 271 x 210 mm 3. How To Set The Unit 3.1 Control Panel 1. Only for remote control: This is not supplied with the DMX version of this product. 2.
- Page 4 5. MAINS IN: IEC Connection from main power supply; this unit MUST NOT be used on a dimmer circuit. 6. MAINS OUT: IEC Connection for main power supply to the next unit. 7. LEDs: DMX input present MASTER Master Mode SLAVE Slave Mode SOUND...
- Page 5 DMX 512 Address Setting Press the MENU button up to when the is shown on the display. Pressing ENTER button and the display will blink. Use DOWN and UP button to change the DMX 512 address. Once the address has been selected, press ENTER button to setup or automatically exit menu mode without any change after one minute.
- Page 6 Show Mode Press the MENU button up to when the is showing on the display. Pressing ENTER button and the display will blink. Use DOWN and UP button to select the (Random show), (show 1) or (show 2). Once the mode has been selected, press the ENTER button to setup or automatically return to the main functions without any change after one minute.
- Page 7 Press the MENU button up to when the is shown on the display. Pressing ENTER button, and use DOWN and UP button to select (0-255) or (000-2555,clockwise/counterclockwise) , or (000-255),press ENTER button to confirm and use DOWN and UP button to adjust the value, once select press ENTER button to setup or automatically exit menu mode without any change after one minute.
- Page 8 setup. Back to the functions without any change press MENU button. 4. How To Control The Unit You can operate the unit in 3 ways: 1. By master/slave function 2. By Standalone using the Display and buttons on the unit 3.
- Page 9 Color Wheel 000 ~ 010 Open 011 ~ 021 Open Amber 022~ 032 Amber 033 ~ 043 Amber Green 044 ~ 054 Green 055 ~ 065 Green Blue 066 ~ 076 Blue 077~ 087 Blue Yellow 088 ~ 098 Yellow 099 ~ 109 Yellow Pink...
