1. Features:
Specifications:
• Negative Ion Generation
Technology
• Adjustable Ozone Generation
• Activated carbon
Deodorization
• UVC bulb & Photo-catalytic
filter to kill virus and bacteria
• Washable HEPA filter to
eliminate small particles, dust
• Adjustable Fan Speed Control
• Washable Permanent
Pre-filter.
•
Adjustable Ozone Control and
Plate Configuration.
• Adjustable Ion Control
Model:
LB-444
Rated Voltage:
USA/JapanAC 100-120V/50-60Hz
Power Consumption:
40W
Fan Speed (non-grade): 1500-3000R/M
Ion Output:
≥5 x 10
Air Volume:
Max 106 CFM(3 m
Active Oxygen (Off/On) ≤0.05ppm / Max=500mg/h
UV Spectrum:
≥20ìw/cm
Sound Level (DB):
Silent20 Low35 Med45 High50
Particulate
0.3 micron can reach 80%
Purifying Rate:
1 micron can reach 99.97%
Product Size (mm):
W210 x D263x H290mm
Gross Weight:
6.5kgs/14.5 Pounds
Applicable Area:
100m
1
6
cm
3
(or≥2.5 x 10
6
/cm
3
)
3
/min)
2
(at 10cm-distance)
2
Advertisement
Table of Contents
Related Manuals for Enerzen LB-444
Summary of Contents for Enerzen LB-444
- Page 1 1. Features: Model: LB-444 Specifications: Rated Voltage: USA/JapanAC 100-120V/50-60Hz • Negative Ion Generation Power Consumption: Technology Fan Speed (non-grade): 1500-3000R/M • Adjustable Ozone Generation Ion Output: ≥5 x 10 (or≥2.5 x 10 • Activated carbon Air Volume:...
- Page 2 110 volt models: fusing current no morethan1.0 Amp. 230 volt models: fusing current no more than 1.0 Amp. 2. INTRODUCTION The LB-444 purifies and cleanses the air you breathe though circulated purification, disinfection and sterilization. 3. FEATURES • Compact • Portable • No Duct work Required • No Chemicals • Low Maintenance •...
- Page 3 120 volt outlet. Make sure the power switch is on, and adjust controls according to the application. 6. BACK COVER & HEPA FILTER, CARBON FILTER REMOVAL Step 1: Unplug the LB-444 to prevent electric shock when you want to wash or maintain the unit. 3 ...
- Page 4 Step1 Step 2: Push the two latches down on the back cover. Step 3: Remove the HEPA filter by gently pulling out the white ribbon on the top. Step 4: Pull out each filter with white ribbons. 7. PLACING THE UNIT: In order to maximize the purification function, the unit should be placed as high as possible.
- Page 5 Caution: This unit should never be placed where it can blow directly into the face of any person or pet. 8. SETTINGS AND ADJUSTMENTS: 8.1 FAN & UV CONTROL The fan control can turn on or turn off the fan, or adjust wind speed. When the fan is rotating at the fastest speed, there may be a relatively loud noise, please place the unit at a certain distance according to your personal preference.
- Page 6 9. MAINTENANCE Periodic maintenance is required to insure that the LB-444 operates properly. A severely polluted environment can soil an air purifier plate in as little as four weeks or as long as a year. Shown here are basic maintenance procedures that should be carried out to keep your unit running at top performance.
- Page 7 11. REPLACING THE FUSE A fuse holder is located on the back of the unit next to the power cord. To replace or check the fuse, remove the fuse holder by pressing on the clip and pulling straight out. If the fuse is blown, replace with the backup fuse. Insert the new fuse into the fuse holder.
- Page 8 Do not attempt to disassemble the unit, due to the Limited Warranty of the product. ⑶. It is normal that the LB-444 air purifier plate is making a sound, having a burning smell, and/or appearing arcing or sparking. ⑷. What are the most typical application problems? ...
