Arizant Healthcare Bair Hugger 775 Operator's Manual

Temperature management unit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Check the Bair Hugger therapy website to ensure you have the most recent version of this document.
Bair Hugger*
Temperaturmanagementgerät
Modell 775 Benutzerhandbuch
Bair Hugger* Unité de contrôle de
température, modèle 775
Manuel de l'utilisateur
Bair Hugger* Unità per la gestione
della temperatura mMdello 775
Manuale d'uso
Bair Hugger* Unidad de control de
temperatura, Modelo 775
Manual del operador
Bair Hugger* Unidade de Gestão de
Temperatura Modelo 775
Manual do Utilizador
Bair Hugger* Model 775
temperatuurregelunit
Gebruikershandleiding
To t a l Te m p e r a t u r e M a n a g e m e n t S y s t e m
Bair Hugger
Temperature Management Unit
Model 775
Bair Hugger*
Temperaturstyringsenhed
Model 775 Brugervejledning
Bair Hugger*
Temperaturregleringsenhet,
Modell 775 Bruksanvisning
Bair Hugger*
Temeraturadministrasjonsenhet
Modell 775 Brukerhåndbok
Bair Hugger* Lämpötilan
valvontayksikkö edestä
Malli 775 Käyttöopas
Bair Hugger* Μονάδα
Διαχείρισης Θερμοκρασίας
Μοντέλο 775 Εγχειρίδιο Χρήσης
ベアーハガー
体温管理装置モ
*
デル775 取扱説明書
www.bairhugger.com
*
Operator's Manual
Bair Hugger* Dmuchawa
Model 775 Instrukcja obsługi
Bair Hugger* Hőmérséklet
szabályozó egység 775-ös
Modell Használati utasítás
Bair Hugger* Termoregulační
jednotka, Model 775
Návod k obsluze
Bair Hugger* Temperatūros
kontrolės įrenginys, Modelis 775
Naudotojo vadovas
Bair Hugger* Устройство
управления температурой,
модель 775 Руководство по
эксплуатации
Bair Hugger*
操作员手册
reorder #771022C
775 型温度管理仪

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bair Hugger 775 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Arizant Healthcare Bair Hugger 775

  • Page 1 Check the Bair Hugger therapy website to ensure you have the most recent version of this document. www.bairhugger.com reorder #771022C Bair Hugger Temperature Management Unit Model 775 Operator’s Manual Bair Hugger* Bair Hugger* Bair Hugger* Dmuchawa Temperaturmanagementgerät Temperaturstyringsenhed Model 775 Instrukcja obsługi Modell 775 Benutzerhandbuch Model 775 Brugervejledning Bair Hugger* Hőmérséklet...
  • Page 2 Bair Hugger Temperature Management Unit Model 775 Operator’s Manual English Deutsch Français Italiano Español Português Nederlands Dansk Svenska Norsk Sumoi Ελληνικά 日本語 Polski Magyar Česky Lietuvių Kalba Русский 英语...

  • Page 3: Table Of Contents

    Table of Contents Introduction � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � Description of the Total Temperature Management System �...

  • Page 4: Description Of The Total Temperature Management System

    Thermal injury may result. The Bair Hugger temperature management unit has been designed to operate safely ONLY with Arizant Healthcare* disposable components. Use with other products may cause thermal injury. (To the full extent permitted by law, the manufacturer and/or importer declines all responsibility for thermal injury resulting from the unit being used in conjunction with non-Arizant Healthcare products.)

  • Page 5: Cautions

    We recommend clamping the unit no higher than 44" (112 cm) on an IV pole with a minimum 28" (71 cm) diameter wheelbase. Failure to do so may result in IV pole tipping, catheter site trauma, and patient injury. Arizant Healthcare Inc.

  • Page 6: Notices

    To reliably ground this Bair Hugger warming unit, only connect to receptacles marked “Hospital Only” or “Hospital Grade”. Proper Use and Maintenance Arizant Healthcare assumes no responsibility for the reliability, performance, or safety of the temperature management unit if the following events occur: •...

  • Page 7: Overview And Operation

    However, if the temperature management unit loses power for longer than 1 second, the unit’s software will reset when you restore power. The unit will then enter the Standby mode. Arizant Healthcare Inc.

  • Page 8: Overview Of Control Panel

    Bair Hugger Model 775 Temperature Management Unit Operator’s Manual Bair Hugger Model 775 Temperature Management Unit Operator’s Manual Overview of Control Panel Temperature Modes Alphanumeric Display High Fan Setting Low Fan Setting TEMP IN RANGE AMBIENT FAULT OVER TEMP STANDBY Figure C.
  • Page 9 If the unit senses an over-temperature condition, the red Over-temp indicator light flashes and an alarm sounds. Please refer to What to Do in Case of an Over-Temperature Condition on page 9 for additional information. Arizant Healthcare Inc.

  • Page 10: Mounting The Temperature Management Unit To An Iv Pole

    Bair Hugger Model 775 Temperature Management Unit Operator’s Manual Bair Hugger Model 775 Temperature Management Unit Operator’s Manual Mounting the Temperature Management Unit to an IV Pole caution To prevent tipping, clamp the Model 775 temperature management unit to an IV pole at a height that provides stability.

  • Page 11: Instructions For Use

    Note: At any time, the fan speed setting can be switched between high fan setting ( and low fan setting ( ) by pressing the corresponding button. However, these buttons will not place the unit into Standby. Arizant Healthcare Inc.

  • Page 12: Viewing The Temperature Mode Timer

    Bair Hugger Model 775 Temperature Management Unit Operator’s Manual Bair Hugger Model 775 Temperature Management Unit Operator’s Manual Viewing the Temperature Mode Timer The temperature mode timer records the amount of time the temperature management unit has been operating in the selected temperature mode. The timer resets itself every time you select a different temperature mode.

  • Page 13: General Maintenance

    Disconnect the temperature management unit from the power source before cleaning. Wipe the cabinet and the outside of the hose with a damp, soft cloth and a mild detergent or antimicrobial spray. Dry with a separate soft cloth. Arizant Healthcare Inc.

  • Page 14: Technical Service And Order Placement

    Bair Hugger temperature management unit. In-Warranty Repair and Exchange Call Arizant Healthcare customer service if your Model 775 temperature management unit requires factory service. A customer service representative will give you a Return Authorization (RA) number. Please use this RA number on all correspondence concerning your temperature management unit.

  • Page 15: Specifications

    Over-temperature (≤56°C, 53°C ± 3°C typical): red Over- temp indicator light flashes, alarm sounds, heater and blower shut down, operating indicator lights turn OFF, control panel becomes unresponsive. Fault: amber Fault indicator light flashes, alarm sounds. overcurrent protection Dual input fused lines. Arizant Healthcare Inc.
  • Page 16 Bair Hugger Model 775 Temperature Management Unit Operator’s Manual Electrical Characteristics heating element 1400 W Resistive leakage current Meets UL 60601-1 and IEC 60601-1 requirements. blower motor Operating speed: 4,700 rpm (high fan setting), 4,100 rpm (low fan setting) Airflow: up to 48 cfm or 23 L/s power consumption Peak: 1550 W Average: 800 W...

  • Page 17: Definition Of Symbols

    Equipotentiality plug (ground) Fuse Attention, consult appropriate documents Nonexplosion proof Dangerous voltage Type BF equipment (patient applied) Voltage, alternating current (AC) Special refuse, discard separately Protective earth ground No free hosing High fan setting Low fan setting Arizant Healthcare Inc.
