Rose electronics RCP-12RS Specifications

Remote Control Panel

Features and Benefits

Simple push button operation
Extended distance capabilities with standard RJ11
data cable
Available in 4, 8, 12, and 16 switch models that match
the number of CPU ports on your KVM switch
Plugs into the RS232 port of a Rose KVM switch
Has 1-DB9M, RS232 communication port
Rack mount kits available for mounting in a 19", 23",
or 24" rack
No set-up or configuration required, connect the RJ11
cable, the power adapter and it is ready to use
LEDs in the center of each select button indicates
which CPU port is active
Made in USA
Remote Control Panel – RCP
Remotely switch a KVM port to any CPU port
Compatible with Rose Electronics UltraView,
ServeView, and MultiVideo products
Connects directly to the RS232 port of a KVM switch
using a single RJ11 Data cable
The Remote Control Panel™ Advantage. .
The Remote Control Panel provides quick, easy, push-
button switching to 4, 8, 12, or 16 computers.
When you push button 4 on the Remote Control Panel,
CPU port 4 on the KVM switch is instantly switched to
the KVM station.
The Remote Control Panel is ideal for system
applications where remotely switching different
computers to a common keyboard, monitor, and mouse
is needed.
Video switching applications, presentations, training
sessions, and many other applications are made easy
by using the push-button features of the Remote
Control Panel.
Connect to a CPU with
the push of a button
W W W . R O S E . C O M
