Flex 2
PCIe 4.0 Vertical Riser Bracket
Contents
1
2
GPU Support Bracket
3
Flexible PCIe 4.0 Riser Cable
4
2 x 6-32 Thumbscrew for PCI Cover
5
2 x 6-32 Captive Thumbscrew
6
2 x 6-32 Screw for Riser Cable
7
2 x 6-32 Screw for Bracket
5
4
1
7
6
2
3
Advertisement
Table of Contents
Related Manuals for Fractal Flex 2
Summary of Contents for Fractal Flex 2
- Page 1 Flex 2 PCIe 4.0 Vertical Riser Bracket Contents PCI Slot Cover Bracket GPU Support Bracket Flexible PCIe 4.0 Riser Cable 2 x 6-32 Thumbscrew for PCI Cover 2 x 6-32 Captive Thumbscrew 2 x 6-32 Screw for Riser Cable 2 x 6-32 Screw for Bracket...
- Page 2 Insert 2 x Screw (6-32) for Riser Cable Install the Graphics Card Insert 2 x Thumbscrew in PCI Slot Cover Bracket Mount Flex 2 Bracket in the Case Connect PCIe 16x Riser Cable to Motherboard Fractal Gaming AB, Represented by: Victor Hasselblads Gata 16A, Authorised Rep Compliance Ltd.
