Partition Play – EY11775
ASSEMBLY INSTRUCTIONS.
(
Photos correspond to numbered instructions below)
WILL REQUIRE AT LEAST 2 ADULTS.
Fixing Kit:- 10 x 60mm Screws. 16 x 80mm Screws. 2 x 150mm
1. Check all parts are present.
2. Select suitable position on flat, level ground.
3. Screw both back panels into place using 10 x 60mm screws spread evenly.
+
TTS Group Ltd – Building 1, Heyworth Road, Hucknall, Nottinghamshire, NG15 6XJ United Kingdom.
Advertisement
Related Manuals for TTS EY11775
Summary of Contents for TTS EY11775
- Page 1 1. Check all parts are present. 2. Select suitable position on flat, level ground. 3. Screw both back panels into place using 10 x 60mm screws spread evenly. TTS Group Ltd – Building 1, Heyworth Road, Hucknall, Nottinghamshire, NG15 6XJ United Kingdom.
- Page 2 4. Fix first side panel to the right side of the product using 5 x 80mm screws. 5. Fix second panel to the left side of the product using 5 x 80mm screws. TTS Group Ltd – Building 1, Heyworth Road, Hucknall, Nottinghamshire, NG15 6XJ United Kingdom.
- Page 3 6. Drill 2 x 150mm screws. 7. Attach middle section to the product using 6 x 80mm screws. TTS Group Ltd – Building 1, Heyworth Road, Hucknall, Nottinghamshire, NG15 6XJ United Kingdom.
- Page 4 8. Finished Product – Partition Play TTS Group Ltd – Building 1, Heyworth Road, Hucknall, Nottinghamshire, NG15 6XJ United Kingdom.
