Summary of Contents for Roadefend RDT600
- Page 1 Installation Instruction RDT600 Proactive AI Safety System...
- Page 2 RDT600 Installation Instruction Ver.1.1 Revision History: Version Revised By Revision Date Revision Description Number V1.0 Xu Zhiwu 2023.04.24 <1> First draft of integrated release <1> Update some images in the V1.1 Xu Zhiwu 2023.06.25 instructions section of the web side configuration tool...
-
Page 3: Table Of Contents
RDT600 Installation Instruction Ver.1.1 Table of contents 1. Overview ................................... 4 2. Product Configuration............................... 4 2.1 Product standard packing list ..........................4 2.1.1 The standard package is as follows: ......................4 2.2 Product optional accessories list .......................... 5 2.3 Equipment Harness ............................... 5 2.3.1 Power harness ............................ - Page 4 RDT600 Installation Instruction Ver.1.1 5.3 Parameter setting ............................... 19 5.3.1 Set vehicle information .......................... 19 5.3.2 Set switch value ............................. 19 5.3.3 Mirror/Flip Settings ..........................19 5.3.4 Test mode............................... 19 5.4 ADAS calibration ..............................20 5.5 Live image ................................21...
-
Page 5: Overview
RDT600 Installation Instruction Ver.1.1 1. Overview This article introduces in detail the composition of the RDT600 active safety intelligent prevention and control system , the installation standards and precautions of the host and its accessories . Provide reference and guidance for on-site installation personnel , provide construction personnel with installation operation requirements , standardize the installation and commissioning process , Improve construction efficiency , Make sure the equipment is working properly . -
Page 6: Product Optional Accessories List
RDT600 Installation Instruction Ver.1.1 2.2 Product optional accessories list Serial Name Quantity Unit Remark Number Optional according to project DMS Camera indivual requirements Optional according to project OMS Camera indivual requirements Aviation head interface This adapter cable is required when... -
Page 7: 4- Core Io Communication Harness ( Optional)
RDT600 Installation Instruction Ver.1.1 Figure 2: Diagram of power harness Table 3: Definition of harness pins 2.3.2 4- core IO communication harness ( optional) Used to connect the body hardware line signal , Such as brakes , left/right turn signals , high/low beams , CAN communication, etc. -
Page 8: 8- Core Io Communication Harness (Optional)
RDT600 Installation Instruction Ver.1.1 2.3.3 8- core IO communication harness (optional) Figure 4 8- core IO communication line Table 5: Pin definition of 8- core IO communication line 2.3.4 Aviation head interface camera adapter cable For host and 4- core aerial camera... -
Page 9: Preliminary Preparation
RDT600 Installation Instruction Ver.1.1 Picture 6 Aviation head interface camera adapter cable 3. Preliminary preparation 3.1 Site condition preparation 3.1.1 Site terrain requirements Find an open area before installation . In principle, it is required to be on a flat road with a wide view (you can see the skyline ) , Areas with lane lines for installation and calibration . -
Page 10: Installer Requirements
RDT600 Installation Instruction Ver.1.1 3.1.2 Installer Requirements On-site construction personnel should be familiar with the functions and applications of the product , understand the composition and working principle of the entire system , and be familiar with the internal structure and electrical circuits of motor vehicles , etc. -
Page 11: Device Information Confirmation
RDT600 Installation Instruction Ver.1.1 Electric Pen Universal Screwdriver Length greater than 20cm , with a cross and a cape General purpose , for measuring voltage , left and Multimeter right turn signals , brake signal etc. 2cm straight , Beautiful packaging for wiring , Prevent... -
Page 12: Software Information Confirmation
RDT600 Installation Instruction Ver.1.1 Before installation, check whether the equipment is complete and whether there is any damage , etc. The specific equipment list is subject to the project plan . 3.3.2 Software information confirmation Check the shipping information sheet before installation to confirm the correctness of the factory version of the device software.If you find that the device software version is inconsistent with the... -
Page 13: System Connection Diagram
RDT600 Installation Instruction Ver.1.1 4.1.3 System connection diagram 4.2 Equipment and wiring harness docking... -
Page 14: Installation Location Requirements
RDT600 Installation Instruction Ver.1.1 4.2.1 Installation location requirements 1). The host is fixed near the rearview mirror of the front windshield (the top function line is hidden in the roof compartment), and it is as close as possible to the middle of the entire width of the windshield. -
Page 15: Adas Camera Debugging
RDT600 Installation Instruction Ver.1.1 Find the corresponding wiring position through the instructions of the body fuse box , As shown below : If the description of the fuse box is vague and cannot be judged , The corresponding wiring harness can be found through the electric pen measurement method . -
Page 16: Dms Camera Installation And Debugging
RDT600 Installation Instruction Ver.1.1 4.3 DMS camera installation and debugging 4.3.1 Installation location requirements DMS The camera is installed in front of the driver , distance from driver's face 60cm~ 120cm range , The angle between the normal line of the face and the driver is required to be less than ±30° when looking straight ahead ;... -
Page 17: Routing And Precautions
RDT600 Installation Instruction Ver.1.1 front windshield near the left A- pillar (you can power on the device first, and check the DMS video screen through the mobile APP real-time video to confirm whether the installation location is suitable) , and use a paper towel Or clean the installation position with a dry towel, tear off the 3M adhesive sticker on the base of the DMS camera , stick the base to the installation position on the windshield and use a little force to make it stick firmly . -
Page 18: Storage Media And Iot Card Installation ( Picture)
Open the WiFi connection interface on the mobile phone, and you can see the hotspot with the WiFi name "RDT600-the last six digits of the device number", such as RDT600-000949, Connect to this WiFi hotspot, the WiFi hotspot password of all RDT600 is uniform: 12345678, after the... -
Page 19: Log In To The Web Tool
RDT600 Installation Instruction Ver.1.1 connection is successful, go to the next step. 5.1.2 Log in to the web tool Open the mobile browser, enter " 192.168.1.1 " in the URL bar , click Go, and enter the login page; After... -
Page 20: Parameter Setting
RDT600 Installation Instruction Ver.1.1 5.3 Parameter setting 5.3.1 Set vehicle information Click "Parameter Settings-General-Vehicle Information" to set the license plate number, license plate color , etc. The online number can be clicked on the right " +" Select "Freight" or "Default" (recommended to choose "Freight") or fill in according to your needs . -
Page 21: Adas Calibration
RDT600 Installation Instruction Ver.1.1 simulated actions to trigger alarms. This page can be set at the same time speed value for test mode. 5.4 ADAS calibration Click "Algorithm Configuration" to enter the algorithm configuration page for ADAS calibration. a . Distant skyline calibration Drive the vehicle to the center of the long straight horizontal lane, and ensure that the vehicle stops straight. -
Page 22: Live Image
RDT600 Installation Instruction Ver.1.1 b. Calibration bar calibration When the on-site conditions are limited, there are obstacles in front of the vehicle, and the lane line and distant skyline cannot be seen, the on-site installer can also use the calibration rod for calibration. -
Page 23: Notice To Users
RDT600 Installation Instruction Ver.1.1 images of each channel. After checking "Large image preview automatically refreshes", you can click A channel to view the real-time video screen of the channel. 6. Notice to users 1). This product is a full HD on-board intelligent analysis system, which can help companies manage fleets and understand the status of vehicles in real time. - Page 24 RDT600 Installation Instruction Ver.1.1 FCC Warning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
