Air Impact Hammer

• Ergonomic grip for comfort and stability.

• Heat treated impact parts for long life durability.

• Positive action trigger and built-in air regulator for simple power and speed control.

• Screened filter air inlet to keep dirt and debris from damaging the tool.

• Standard quick-change spring for speed and ease of chisel change.

• Front exhaust.

• Recommended air pressure 90 psi.

Chisel

Part Number

Shank

(mm)

AP17621

Air

Inlet

Blows

per min

10.2

4,500

1/4"

Air

Overall Length

Hose

Imp

Metric

(")

(mm)

3/8"

6.10

155

Average Air

Net Weight

Consumption

cfm

l/min

lbs

2.8

79.8

2.65

1.2

Table of Contents

Need help?

Do you have a question about the AP17621 and is the answer not in the manual?

Questions and answers

Summary of Contents for Aeropro AP17621

Page 1 • Standard quick-change spring for speed and ease of chisel change. • Front exhaust. • Recommended air pressure 90 psi. Average Air Overall Length Net Weight Chisel Inlet Hose Consumption Blows Part Number Shank per min Metric (mm) l/min (“) (mm) AP17621 10.2 4,500 1/4” 3/8” 6.10 79.8 2.65...
Page 2: Air Supply
Operating Instructions Description Hardened steel barrel and piston for less wear and longer life. Lightweight aluminum pistol grip housing. Front exhaust. 150mm air hammer set includes 4 chisels and a retainer spring. Ideal for general cutting, chipping and scraping. Air Supply 1.
Page 3: Loading And Operation
Operating Instructions In the event that it becomes necessary to store the tool for an extended period of time (overnight, weekend, etc.) lubricate the tool generously. The tool should be run for approximately 30 seconds to ensure that the oil has been evenly distributed throughout the tool. The tool should be stored in a clean and dry environment.
Page 4: Troubleshooting
Operating Instructions Trouble Shooting The following table details the common operating system with problem and solutions. Please read the table carefully and follow it. WARNING: If any of the following symptoms appear during your operating, stop using the tool immediately, or serious personal injury could result. Only qualified persons or an authorised service centre can perform repairs or replacement of tool.
Page 5: Residual Risks
Safety Rules and Hazards Residual Risks Even when the tool is used as prescribed it is not possible to eliminate all residual risk factors. The following hazards may arise in connection with the tool’s construction and design: 1. Damage to lungs if an effective dust mask is not worn. 2.
Page 6: Projectile Hazards
Safety Rules and Hazards General Safety Rules 1. For multiple hazards, read and understand the safety instructions before installing, operating, repairing, maintaining, changing accessories on, or working near the power tool. Failure to do so can result in serious bodily injury. 2.
Page 7: Operating Hazards
Safety Rules and Hazards Operating Hazards 1. The use of the tool can expose the operators hands to hazards including crushing, impacts, cuts, abrasions and heat. Wear suitable gloves to protect hands. 2. Operators and maintenance personnel shall be physically able to handle the bulk, weight and power of the tool.
Page 8: Dust And Fume Hazards
Safety Rules and Hazards Dust and Fume Hazards 1. Dust and fumes generated when using power tools can cause ill health (for example, cancer, birth defects, asthma or dermatitis); risk assessment and implementation of appropriate controls for these hazards is essential. 2.
Page 9: Vibration Hazards
Safety Rules and Hazards Vibration Hazards 1. Exposure to vibration can cause disabling damage to the nerves and blood supply of the hands and arms. 2. Keep the hands away from the nutrunner sockets. 3. Wear warm clothing when working in cold conditions and keep your hands warm and dry. 4.
