Summary of Contents for ACO AL-35N

  • Page 1 Apendice 1 para Manual de Instalación Oleolift P Oleolift P Instalación de superfície...
  • Page 2 HCP PUMPS – sludge pump for extreme loads – portable waste-water pumps – portable sludge pumps – stainless-steel portable pumps for aggressive waste waters – stainless-steel portable sludge pumps for aggressive sludge AS, AG – pumps for sandy water IC, GD, GDR –...
  • Page 3: Table Of Contents

    Thank you for purchase of HCP pump and read carefully this Operation Manual before using. CONTENT: GENERAL INSTRUCTIONS Specifications SAFETY Summary of important notices TECHNICAL DATA TECHNICAL DESCRIPTION OF PUMPS Production labels Pumps sections Transport and storage CONNECTION TO ELECTRICITY Generally Connecting the pump Commissioning...
  • Page 4: General Instructions Use

    GENERAL INSTRUCTIONS Submersible industrial pumps AF series are designed to pump sludge and water polluted by nonabrasive small solid and fibre particles. When using for pumping wastewater containing abrasive particles, it is necessary to expect an increased wear and tear of the hydraulic part, oil sealing, shaft and mechanical sealing. The maximum content of impurities may be up to 10% of the weight.
  • Page 5: Specifications

    SPECIFICATIONS WARNING Read carefully the specifications for the pump model you have bought. The ambient air temperature within 0 - 40°C. The pump has a heat protection protecting the motor from overheating as a result of a high temperature or should an inter-phase failure occur during the start-up period or a voltage decrease or should the impeller wheel become clogged.
  • Page 6: Technical Data

    2.1.18 Pumps with float switch needs elbow-room around for free movement of float switch. TECHNICAL DATA Dimensions Weight Length Width Height “ / mm 50AFU20.4(F) 0,72/0,7 2“ / 50 3,3/1,3 11,5/5,7 19/18 50AFU20.4L(F) 0,72/0,7 2“ / 50 13,2 3,3/1,3 11,5/5,7 20/19 50AFU40.4 2“...
  • Page 7 2,95 2“ / 50 23,5 499/568 AL-33AN(F) 2,95 3“ / 80 15,5 510(579) AL-43AN(F) 2,95 4“ / 100 11,5 AL-35N 4,65 3“ / 80 49,2 520(589) 50AL21.5 WD 2“ / 50 12,5 18,7 50AL22.2 WD 2,95 2“ / 50 28,1 80AL21.5 WD...
  • Page 8 Dimensions Weight Length Width Height “ / mm /hod SS-05A(F) 0,72/0,7 2“ / 50 3,3/1,3 11,5/5,7 15/14 SS-21A(F) 0,75 1,08/1,05 2“ / 50 10,2 5,2/1,9 18,3/10,1 17/16 SF-05AU(F) 0,72/0,7 2“ / 50 3,3/1,3 11,5/5,7 15/14 SF-21AU(F) 0,75 1,08/1,05 2“ / 50 5,2/1,9 18,3/10,1 16/15 80SFP21.5...
  • Page 9: Technical Description Of Pumps

    Dimensions Weight Length Width Height “/mm /hod L-41 0,75 1,05 4“/100 L-62 6“/150 20,4 L-63 2,95 6“/150 25,3 L-200A 12,6 70,4 L-250A 90,4 1015 L-300A 12,4 22,6 1077 WD: these types of pumps are equipped with WD (water detector – moisture sensor of leakage) in standard. (F) in type marking means pump is equipped with float switch.
  • Page 10: Production Labels

    The pumps are fitted with a heat protection to protect the motor against overheating as a result of a high temperature or should an inter-phase failure occur during the start-up period, or a voltage decrease, or should the impeller wheel become clogged. Sizes from AF-615 to AF-1660 is equipped with MTP (Miniature Thermal Protection) sensors in stator winding, which protects motor against overheating by activating external protection in control panel.
  • Page 11: Pumps Sections

    PUMPS SECTIONS AL, BF, SS, SF...
  • Page 12: Transport And Storage

    AS, IC GD, GDR TRANSPORT AND STORAGE The pump can be transported in both vertical and horizontal position. It must be firmly anchored in WARNING order not to tip over or roll away. When handling, hang the pump for the handle only; never stretch the cable by pulling it!! Is possible to use only approved and undamaged hanger with load capacity higher then weight of pump.
  • Page 13: Connecting The Pump

    necessary to install separate fuses or circuit breakers for supply conductors. Series AF, AL, BF, AS, AG, IC, GD, GDR, SS, SF, L Fuse: fuse nominal current of 100 % - 115 % of the pump nominal current. Characteristics: gG Circuit breaker: nominal current 100 % - 115 % of the pump nominal current.
  • Page 14 Connection of motor Y-D, Y, D with motor controler (OVL1/OVL2) for sizes from AF-615 to 830 Y-D connection 690/400V D connection – direct start 400V: OVL1 OVL2 Y-D connection is recomended by manufacturer. Motor winding thermal protection + Water detector (sizes from AF-615 to 830): Common signal cable has four line wires.
  • Page 15: Commissioning

    COMMISSIONING Before commissioning it is necessary to carry out inspection of the electric part, particularly: • To check whether the pump supply cable, float switch or water detector cable is not damaged • To check the correct setting of the current protection •...
  • Page 16 Minimal dimensions of sump [mm]: width length height AL-01NF, BF-01UNF, AL-05NF AL-05LNF, AL-21NF, AL-31NF BF-05UNF, BF-21UNF, BF-31UNF, BF-21PNF AL-23ANF, AL-32ANF, AL-33ANF, AL-43ANF 1000 BF-32AUNF, BF-32APNF, BF-33AUNF, BF-33APNF 32GF21.0F, 32GF21.2F 1000 1060 SS-05AF, SS-21AF, SF-05AUF, SF-21AUF 6.2.5 Deaerate the sump tank or septic tank in accordance with the local rules and regulations. 6.2.6 When pumping from a reservoir where loose materials are sedimented, it is not suitable to put the pump on these sediments as for one the pump will "bury"...
  • Page 17 Picture of the BF pump with guide rail system 6.2.16 The Guide rail system consists of the following parts: - footing - 2x guide rail (not included in the shipment – provided by customer according to the necessary length) - movable hook - upper holder of guide rails - stainless-steel chain of 4m length 6.2.17 Dimensions of discharge flanges series AL.
  • Page 18: Mechanical Inspection

    6.2.27 If check valve is installed on discharge pipe pumps AF, AL, BF series is necessary to deaerate pump after the first afloat. Especially in cases where the discharge pipe is equipped with check-valve. 6.2.28 Series AL, BF, SS, SF, AF is equipped with air vent bolt or hole in top of pump casing. This bolt/hole alows outflow of gas, which may accumulate in casing when pump rest.
  • Page 19: Service, Repairs, Spare Parts

    If the pump is equipped with WD detector and evaluation device is signalizing leakage into the mechanical seal oil bath, is necessary to check the mechanical seal condition and eventually change mechanical seal and pour new oil refill into chamber. Although it is not serious defect needs to quick switch off operation, but mechanical seal must be changed as soon as possible, that will not worn-out upper couple of mechanical seal and leakaging water into the motor.
  • Page 20: Operation Failures, Their Causes And Removal

    • GRS – guide rail system (if having been ordered) consisting of: footing movable hook upper holder of guide rails stainless steel chain Warning: The guide rails are not included in the shipment!!! They are available upon order. OPERATION FAILURES, THEIR CAUSES AND REMOVAL FAILURE CHARACTERISTIC PROBABLE CAUSE REMEDY...
  • Page 21: 11.0 Declaration Of Conformity

    11.0 DECLARATION OF CONFORMITY EC DECLARATION OF CONFORMITY Importer/manufacturer’s representative in the European Community: K+H čerpací technika s.r.o., Dolní Novosadská 55/66 CZ 779 00 Olomouc, Czech Republic, IČO : 25356933 Name and address of the person authorized to draw up and keep documentation on behalf of the importer/manufacturer’s representative in EC: Ing.
  • Page 22: Guarantee Certificate

    GUARANTEE CERTIFICATE TO BE FILLED IN BY VENDOR IN SELLING TYPE OF PUMP : ……………………………………………………….… PUMP SERIAL NUMBER : …………………………………… DATE OF ACCEPTANCE BY PURCHASER : ……………………….… STAMP AND SIGNATURE ELECTRIC INSTALLATION PERFORMED BY QUALIFIED COMPANY INSTALLATION DATE : ………………….………………… ………………………..
  • Page 23 ACO. we care for water Todos los productos de ACO Iberia apoyan el ACO WaterCycle Todos os produtos da ACO Iberia apoia o ACO WaterCycle Drenaje sanitario ƒ Drenagem sanitária Drenaje del cubiertas ƒ Drenagem de coberturas Sistemas de tuberías ƒ...
