- Page 1 Form No. 3350–775 18-44Z TimeCutter Z with Side Discharge Mower Model No. 74351—Serial No. 240000001 and Up Operator’s Manual Original Instructions (EN) Register your product at www.Toro.com...
-
Page 2: Table Of Contents
Starting and Stopping the Engine ....Dealer or Toro Customer Service and have the model and Operating the Power Take Off (PTO) .. - Page 3 Safety This machine meets or exceeds the B71.1–1998 specifications of the American National Standards Institute, in effect at the time of production. However, improper use or maintenance by the operator or owner can result in injury. To reduce the potential for injury, comply with these safety instructions and always pay attention to the safety alert symbol, which means...
-
Page 4: Toro Riding Mower Safety
Be alert, slow down and use caution when making Children turns. Look behind and to the side before changing Tragic accidents can occur if the operator is not alert to the directions. presence of children. Children are often attracted to the Use extra care when loading or unloading the machine machine and the mowing activity. - Page 5 Mower blades are sharp and can cut. Wrap the blade(s) or wear gloves, and use extra caution when servicing them. Use only genuine Toro replacement parts to ensure that original standards are maintained. Toro Riding Mower Safety The following list contains safety information specific to Toro products or other safety information that you must know that is not included in the ANSI standards.
-
Page 7: Slope Chart
Slope Chart... -
Page 9: Safety And Instruction Decals
Replace any decal that is damaged or lost. Note: If needed, a Decal Kit, 107-2492, and French manual are available. Order the Decal Kit from the Toro Parts Department and the French manual from either the Toro Parts Department or online at www.toro.com. - Page 10 106-8743 1. Height of cut 106-2224 1. Throttle 6. Power take-off (PTO) 2. Choke 7. Headlights 3. Fast 8. Engine—stop 4. Continuous variable 9. Engine—run setting 10. Engine—start 106-8742 5. Slow 11. Ignition 1. Parking brake 106-7026 107-2486 1. Stop the engine and 2.
-
Page 11: Gasoline And Oil
Gasoline and Oil Recommended Gasoline Warning Use UNLEADED Regular Gasoline suitable for automotive use (87 pump octane minimum). Leaded regular gasoline Gasoline is harmful or fatal if swallowed. may be used if unleaded regular is not available. Long–term exposure to vapors can cause serious injury and illness. -
Page 12: Operation
Operation Controls Become familiar with all of the controls (Fig. 3 and 4) Note: Determine the left and right sides of the machine before you start the engine and operate the machine. from the normal operating position. Think Safety First Please carefully read all of the safety instructions and decals in the safety section. -
Page 13: Starting And Stopping The Engine
Starting and Stopping the Engine Starting the Engine 1. Sit down on the seat and move the motion controls to m–4268 the brake position. Figure 7 2. Move the PTO (power take off) to Off (Fig. 5). 1. Off 3. Start 2. -
Page 14: The Safety Interlock System
Disengaging the PTO Driving Forward or Backward Push the PTO switch to Off (Fig. 8). The throttle control regulates the engine speed as measured in rpm (revolutions per minute). Place the throttle control in the Fast position for best performance. Always operate in The Safety Interlock System the full throttle position. -
Page 15: Stopping The Machine
Backward 1. Move the levers to the center, unlocked position. 2. To go backward, slowly pull the motion control levers rearward (Fig. 9). To go straight, apply equal pressure to both motion control levers (Fig. 9). To turn, release the pressure on the motion control lever 4–1/2 inch (114 mm) toward the direction you want to turn (Fig. -
Page 16: Positioning The Seat
Positioning the Seat The seat can move forward and backward. Position the seat where you have the best control of the machine and are most comfortable. 1. Raise the seat and loosen the adjustment knobs (Fig. 12). 2. Move the seat to the desired position and tighten the knobs. -
Page 17: Adjusting The Footrest
Removing and Installing the Engine Hood 1. To remove the hood, loosen the knobs and then pull the hood back and up (Fig. 16). m–7276 Figure 14 1. Lever position for pushing 2. Lever position for m–6424 the machine operating the machine Figure 16 1. -
Page 18: Tips For Mowing Grass
If a blade is Mowing Direction damaged or worn, replace it immediately with a genuine Toro replacement blade. Alternate mowing direction to keep the grass standing straight. This also helps disperse clippings which enhances... -
Page 19: Maintenance
Maintenance Note: Determine the left and right sides of the machine from the normal operating position. Recommended Maintenance Schedule Maintenance Service Maintenance Procedure Interval Check the engine oil level. Each use Check the safety system. Clean the mower housing. After first 5 hours Change the engine oil. -
Page 20: Servicing The Engine Oil
Servicing the Engine Oil 3. Unscrew the oil dipstick and wipe the metal end clean (Fig. 19). Check the oil level daily or after every 8 hours. Change the oil after the first 5 operating hours and every 50 operating hours thereafter. Oil Type: Detergent oil (API service SF, SG, SH, SJ, or higher) Crankcase Capacity:... -
Page 21: Servicing The Air Cleaner
1256 Figure 21 m–6438 1. Oil filter 3. Adapter Figure 20 2. Gasket 1. Oil drain valve 2. Oil drain tube 4. Install the replacement oil filter to the filter adapter. Turn the oil filter clockwise until the rubber gasket 9. -
Page 22: Servicing The Spark Plug
Important Replace the foam element if it is torn or worn. Cleaning the Paper Element: 1. Lightly tap the element on a flat surface to remove dust and dirt. 2. Carefully clean the rubber seal on the paper element to prevent debris from entering the engine. -
Page 23: Servicing The Cutting Blades
Check the cutter blades daily for sharpness, and for any wear or damage. File down any nicks and sharpen the blades as necessary. If a blade is damaged or worn, replace it immediately with a genuine Toro replacement blade. For m–6419 convenient sharpening and replacement, you may want to Figure 24 keep extra blades on hand. - Page 24 (Fig. 27). Measure from a level surface to the the machine, use genuine Toro replacement blades. cutting edge, position A, of the blades (Fig. 27). Note Replacement blades made by other manufacturers may this dimension.
-
Page 25: Greasing And Lubrication
3. Clean the grease fittings with a rag. Make sure to scrape any paint off of the front of the fitting(s). 4. Connect a grease gun to the fitting. Pump grease into the fittings until grease begins to ooze out of the m–1854 bearings. -
Page 26: Servicing The Battery
Servicing the Battery Warning Warning Incorrect battery cable routing could damage the tractor and cables causing sparks. Sparks can CALIFORNIA cause the battery gasses to explode, resulting in personal injury. Proposition 65 Warning Always disconnect the negative (black) battery Battery posts, terminals, and related accessories cable before disconnecting the positive (red) contain lead and lead compounds, chemicals cable. - Page 27 5. Slide the red terminal boot onto the positive (red) 3. Remove the vent caps from the battery (Fig. 34). battery post. 4. Slowly pour distilled water into each battery cell until 6. Secure the battery with the hold-down (Fig. 33). the electrolyte level is up to the Upper line (Fig.
-
Page 28: Draining The Fuel Tank
Draining the Fuel Tank Replacing the Fuel Filter Replace the fuel filter after every 100 operating hours or Danger yearly, whichever occurs first. Never install a dirty filter if it is removed from the fuel line. In certain conditions, gasoline is extremely 1. -
Page 29: Adjusting The Front-To-Rear Blade Slope
2. Move the motion control levers to the brake position, stop the engine, remove the key, and wait for all moving parts to stop before leaving the operating position. 3. Check the air pressure of all four tires. If needed, adjust to the recommended inflation;... -
Page 30: Inspecting The Belts
12. After adjusting both adjustment nuts evenly, check the front-to-rear slope again. Continue adjusting the nuts until the front blade tip is 1/16–5/16 inch (1.6–7.9 mm) lower than the rear blade tip (Fig. 42). Note: After adjusting the adjustment nuts, make sure there is no slack in either support rod (Fig. -
Page 31: Removing The Mower
5. Pull the idler pulley in the direction shown in Figure 43 Removing the Mower and roll the belt off of the pulleys. Note: Before removing the mower, make a note for which holes are used in the leveling brackets (Fig. 45). Caution 1. -
Page 32: Installing The Mower
7. Slide the mower rearward to remove the mower belt from the engine pulley. 8. Slide the mower out from underneath the tractor. Note: Retain all parts for future installation. Installing the Mower 1. Park the machine on a level surface and disengage the blade control (PTO). -
Page 33: Replacing The Grass Deflector
4. Lower the mower to the lowest height-of-cut. 5. Sit on the seat and start the engine. Engage the PTO and let the mower run for one to three minutes. 6. Disengage the PTO, stop the engine, and remove the ignition key. -
Page 34: Wiring Diagram
Wiring Diagram... -
Page 35: Cleaning And Storage
Cleaning and Storage crank the engine and distribute the oil inside the cylinder. Install the spark plug(s). Do not install the wire on the spark plug(s). 1. Disengage the PTO, set the parking brake, stop the engine, and remove the key. 12. -
Page 36: Troubleshooting
Troubleshooting Problem Possible Causes Corrective Action The engine overheats. 1. The engine load is excessive. 1. Reduce ground speed. 2. The oil level in the crankcase is 2. Add oil to the crankcase. low. 3. The cooling fins and air 3. - Page 37 Problem Possible Causes Corrective Action The engine loses power. 1. The engine load is excessive. 1. Reduce ground speed. 2. The air cleaner is dirty. 2. Clean the air cleaner element. 3. The oil level in the crankcase is 3. Add oil to the crankcase. low.
- Page 38 Problem Possible Causes Corrective Action The blades do not rotate. 1. The drive belt is worn, loose or 1. Install a new drive belt. broken. 2. The drive belt is off of the 2. Install the drive belt and check pulley.
-
Page 40: The Toro Total Coverage Guarantee
If for any reason you are dissatisfied with your Distributor’s service or have difficulty obtaining guarantee information, contact the Toro importer. If all other remedies fail, you may contact us at Toro Warranty Company.
