www.deutschermowers.com.au
DEUTSCHER MOWERS
DEUTSCHER
XF560
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XF560 and is the answer not in the manual?

Questions and answers

Related Manuals for Deutscher Mowers XF560

Summary of Contents for Deutscher Mowers XF560

  • Page 1 DEUTSCHER MOWERS DEUTSCHER XF560 OWNER’S MANUAL...

  • Page 2: Initial Assembly

    INDEX Initial Assembly Safety Instructions Maintenance & Storage Specifications & Controls Mowing & Transporting Maintenance Mower Decals 11-15 Exploded Views & Parts Lists Warranty INITIAL ASSEMBLY Tools Required: Two 13mm open-ended spanners) 1. Remove the mower from the packaging and visually check for damage. 2.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS 1. Know your controls. Read the owners manuals thoroughly. Learn how to stop the engine quickly in an emergency. 2. Inspect the area to be mown, remove all debris and obstacles that may be in the path of the mower. Do not attempt to shift obstacles while engine is running.

  • Page 4: Maintenance Safety

    SAFETY INSTRUCTIONS 21. SLOPES • Do not mow excessively steep slopes. • Exercise extreme caution when on slopes. • Mow across the face of slopes, never up and down and exercise extreme caution when changing direction on slopes. • Never leave the mower unattended on a slope. 22.

  • Page 5: Specifications

    SPECIFICATIONS & CONTROLS SPECIFICATIONS MODEL No: 36214 XF560 with 850 series Briggs and Stratton engine. 36215 XF560 with a GSV190 Honda engine. Consult engine owners manual for engine specifications. TRANSAXLE: High and Low gear plus a differential is incorporated in the transaxle. A clutch lever to engage and disengage the drive belt is positioned on the right hand handle.

  • Page 6: Pre-Start Check

    MOWING AND TRANSPORTING PRE-START CHECK: Ensure engine oil is at the correct level before starting. See engine manual for instructions. Your Deutscher Mower comes to you with the transmission filled with oil. • Use fresh unleaded petrol. Do not mix oil with petrol. •...

  • Page 7: Mowing On Slopes

    MOWING AND TRANSPORTING MOWING ON SLOPES: • Reduce speed on slopes and in sharp turns to prevent overturning and loss of control. Mow across the face of slopes, never up and down. • Maintain a firm grip on the handles, as the mower will run away if released. •...

  • Page 8: Maintenance

    MAINTENANCE Frequency Part Task 8 hrs 20 hrs 100 hrs Engine Refer to Engine Manual Transaxle Check oil level Cutter spindle Check sealed bearings King pins Raise & lower frame slides Grease Blades and drive belts Check, replace if necessary Clutch control linkages Height control linkages Throttle cable...
  • Page 9 MAINTENANCE Transaxle Belt Replacement When replacing the belts ensure the mower is turned off and the spark plug lead removed. Ensure the engine is not hot, to avoid contact with hot surfaces. Remove the top cover by removing the 4 screws. Loosen the centre bolt on the idler pulley and move the pulley along the slot so the belt is loose.

  • Page 10: Mower Decals

    MOWER DECALS 3346 SERIAL No: 3951 XF560 3349 3574 HIGH NEUTRAL 3351 3347 THROTTLE DRIVE DEUTSCHER XF560 STOP Raise lever to drive TWO SPEED forward. Release to Read operating dis-engage. instructions before use. FAST 3376 3350...

  • Page 11: Exploded Views And Parts Lists

    EXPLODED VIEWS AND PARTS LISTS XF560 CHASSIS AND COMPONENTS Item No Part No Part Description ( Qty ) Item No Part No Part Description ( Qty ) 1017 Bolt M8 x 20 3541 Connecting rod, deck lift 1018 Spring washer 8mm...
  • Page 12 EXPLODED VIEWS AND PARTS LISTS XF560 DECK and COMPONENTS Item No Part No Part Description ( Qty ) Item No Part No Part Description ( Qty ) 2092 Blade brake disc (4) 1,3,4,7 H650 Blade, nut, bolt, washer x 2 set...
  • Page 13 EXPLODED VIEWS AND PARTS LISTS XF560 HANDLE & CONTROLS Item No Part No. Part Description Item No Part No. Part Description 3547 Handle assembly 1586 Rubber handle grip 1017 Bolt M8 x 20 1584 Throttle control 1072 M8 plain nut...
  • Page 14 EXPLODED VIEWS AND PARTS LISTS XF560 GEARBOX COMPONENTS 16 17 18 25 26 27...
  • Page 15 EXPLODED VIEWS AND PARTS LISTS XF560 GEARBOX COMPONENTS Item No. Part No. Part Description Item No. Part No. Part Description 1886 Gearbox complete 1637 Washer 3230 Gear selector arm 1663 Screw 1691 Selector tappet 1659 Seal, axle 7/8”x1,3/8”x1/4” 1690 O- Ring...

  • Page 16: Warranty Policy

    • DEUTSCHER MOWERS PTY. LTD. will repair or replace, free of charge, any mower or part of a mower that is defective in materials or workmanship (or both) for a period of 24 months from the date of purchase. If parts or units are replaced, the replacement period will be no longer than 3 months.
