Summary of Contents for AIDA IPCOMM-POE
- Page 1 AIDA Imaging support@aidaimaging.com aidaimaging.com/support 1278 Center Court Dr @aidaimaging Covina, CA 91724 IPCOMM-POE WIRELESS VIDEO TRANSMITTER OPERATIONS MANUAL VERSION 1.0 - JUNE 2023 www.aidaimaging.com support@aidaimaging.com Toll-Free (844) 631-8367 US (909) 333-7421...
-
Page 2: Table Of Contents
Table of Content SECTION 1 INTRODUCTION PAGE 03 ..........................................................SECTION 2 SAFETY & OPERATIONAL GUIDE PAGE 04 ............................................... SECTION 3 PACKAGE CONTENTS PAGE 06 ......................................................SECTION 4 QUICK START GUIDE PAGE 07 ................................................SECTION 5 SUPPORT & TROUBLESHOOTING PAGE 13 .............................................. -
Page 3: Introduction
By injecting PoE+ power into any camera through either a DC12V source or an NPF-Battery (sold separately), the IPCOMM-POE enables seamless transmission of IP video and IP control. With its remarkable range extending as far as your Wi-Fi router can reach, this solution revolutionizes on-the-go broadcasting and non-mounting setups. -
Page 4: Safety & Operational Guide
Safety & Operational Guide CAUTION: RISK OF ELECTRIC SHOCK. DO NOT OPEN. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNE L. WARNING PRECAUTION This symbol indicate s that dangerou s This exclamation point symbol is intended to alert the user to the presen ce of important operatin g and... - Page 5 Safety & Operational Guide (cont.) PRECAUTION Please read this Operation Guide before installing and using the camera & retain this copy for your reference. 1. Always follow the instructions in the operations guide when applying power. Fire and equipment damage can occur if power is applied incorrectly.
-
Page 6: Package Contents
Package Contents 1 - IPCOMM-POE 2- Power Adapter & Cable IPCOMM-POE Power Adapter & Cable www.aidaimaging.com support@aidaimaging.com Toll-Free (844) 631-8367 US (909) 333-7421... -
Page 7: Quick Start Guide
Quick Start Guide STEP 1: Connect the IPCOMM-POE to the STEP 2: Connect RJ45 cable to IPCOMM-POE, standard DC12V plug, or NPF Battery and other end to a Notebook, Mac, or PC. Turn attachment*. the device Power switch to ON. - Page 8 Quick Start Guide (cont.) STEP 3: Open an internet web browser and STEP 3a: Follow the instructions on the screen. connect to the IP Address: 192.168.1.108. Find your router and enter the WiFi password When performed if enabled in the Preshared Key Slot. Hit correctly, you will see a pop up login panel.
- Page 9 Quick Start Guide (cont.) STEP 3b: Wait for the timer to completely STEP 4: Re-login into the IPCOMM-POE after finish. Exiting or refreshing the screen may re- completing Step 3b’s bootup with the same sult in a loss of connection, which will require credentials.
- Page 10 Quick Start Guide (cont.) STEP 4a: You can change your router or STEP 4b: Click YES to fully connect. settings of the IPCOMM-POE. When ready, click ENABLE LINK to fully dedicate the IPCOMM-POE to the network. www.aidaimaging.com support@aidaimaging.com Toll-Free (844) 631-8367...
- Page 11 Quick Start Guide (cont.) STEP 4c: Wait for the page the finish. It is STEP 5: Remove RJ45 from your computer. normal to lose signal in areas with a large concentration of routers (i.e tradeshows). When the timer completes, the page will redirect to the Login Portal.
- Page 12 Quick Start Guide (cont.) STEP 6: Plug in the RJ45 end into your camera. FACTORY RESET: To reset the IPCOMM-POE, If the camera is PoE+ compatible, the please use a small pin or stick and hold the IPCOMM-POE will power the device.
-
Page 13: Support & Troubleshooting
Normal Business Hours: Monday - Friday from 8 am - 5 pm, excluding major U.S. holidays and events Please feel free to subscribe to our newsletter which keeps you up to date on the latest news, product launches, and firmware updates from AIDA Imaging at https://bit.ly/3pyyShp www.aidaimaging.com support@aidaimaging.com... -
Page 14: Warranty & Repair
Warranty & Repair AIDA Imaging stands behind the quality of its cameras and accessories, providing a comprehensive warranty for a period of two years from the date of purchase. This warranty ensures that the products are free from manufacturer defects in materials and workmanship under normal use conditions. - Page 15 Thank you for choosing the IPCOMM-POE as your wireless transmission solution. We are committed to providing you with a reliable and innovative product that meets your broadcasting needs. We take pride in the quality and compliance of our products. The IPCOMM-POE is manufactured with the following certifications: HEVC For any inquiries, technical support, or further assistance, please don’t hesitate to contact our customer service team...
