Summary of Contents for Blackrock Microsystems 9027301
- Page 1 12x20x9.3 Ft. ROUND SHELTER Owner’s Manual Items #9027301 Tools required for assembly (not included) Page 1...
- Page 2 TABLE OF CONTENTS SAFETY AND PRE-ASSEMBLY CAUTIONS……………………………………………………….…………………………………………………….2 PARTS LIST…………………..………………………………………………………………………………………………………………………………3 ASSEMBLY INSTRUCTIONS………..…………….…………………………………………………………………………………………………..…4-9 SAFETY and PRE-ASSEMBLY CAUTIONS WARNING! Read all safety instructions to reduce the risk of injury or death. No responsibility is accepted by Canadian Tire for damages or injuries resulting from improper installation or noncompliance ...
-
Page 3: Part List
ASSEMBLY Please read instructions fully before beginning assembly Step 1: Checking the Parts Unpack and check the contents of the box. Make sure that you have all the parts described in the parts list shown hereafter PART LIST Description Illustration Q’ty Top Roof Tube Rafter Roof Tube... -
Page 4: Assembly Preparation
ASSEMBLY PREPARATION Place all parts from the packaging box in a cleared area and arrange them on the ground in front of you. Remove all packaging materials and place them back in the box. Do not dispose the packaging materials until assembly is complete. ... -
Page 5: Step 1: Frame Assembly
ASSEMBLY Diagram B Step 1: Frame Assembly Select level and suitable location for your shelter. 1. Assembly the two End Ribs a. Follow Diagram B connecting the 7 tubes together (1pc tube #1, 2pcs tube #2, 2pcs tube #3 & 2pcs Bent Legs #6) to form 1 End Rib. - Page 6 ASSEMBLY Diagram E B Insert the male end of tube #8 into tube #7. See Diagram E C Connect the two parts of Support Brace (#9 & #10) by Fittings (#16, #17 & #20) D Fix one end of the Support Brace on tube #3 by Fittings (#16 #17 &...
- Page 7 ASSEMBLY Diagram H 5. Square and Anchor the Frame Check the measure of frame both 12' at the front and back corners, as well as the center. Diagram Take a diagonal measure as shown in When these two measures are equal the frame is square.
- Page 8 ASSEMBLY Diagram K. d. Insert the Cross Rail into each hole on the Door edge, and slip the webbed belt to be outside of the tube. Rejoin the pipes. See Diagram K1, K2, K3. e. Next, taking 1-pieceRatchet (Part #13), untie one end of the webbed belt at the foot of the leg and insert the belt to the ratchet as shown in the Diagram K4 Ratchet a few times to tighten the belt to the ratchet.
- Page 9 ASSEMBLY d. Assemble the ratchets (Part #13) to the web ends on the 4 corner of the cover, 1pc for each corner. e. Insert the "S" - hook on ratchet into hole on the Bent Corner Leg. Wind the ratchet so that the webbing Diagram N overlaps itself.
- Page 10 Distributed by Forcome (shanghai) Co., Ltd South Sizhuan Road,Shanghai 201612 Made in China Page 10...
