Microsens MS659150M User Manual

Indoor enterprise access point
Hide thumbs Also See for MS659150M:
Table of Contents

Advertisement

Quick Links

Download this manual
Indoor Enterprise Access Point
- User Manual - MS659150M
MICROSENS GmbH & Co. KG
Kueferstr. 16
59067 Hamm/Germany
Tel. +49 2381 9452-0
FAX +49 2381 9452-100
E-Mail info@microsens.de
Web www.microsens.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS659150M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Microsens MS659150M

Summary of Contents for Microsens MS659150M

  • Page 1 Indoor Enterprise Access Point - User Manual - MS659150M MICROSENS GmbH & Co. KG Kueferstr. 16 59067 Hamm/Germany Tel. +49 2381 9452-0 FAX +49 2381 9452-100 E-Mail info@microsens.de Web www.microsens.de...

  • Page 2: Table Of Contents

    Wi-Fi............  - ii - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...

  • Page 3: Scope Of Delivery

    • 1G Eth: Connect Ethernet cable for LAN (local area network) connection. • 2.5G Eth PoE: Connect Ethernet cable for LAN (local area network) connection, or a con­ nection with LAN and PoE+. - 1 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...

  • Page 4: Leds

    The LEDs indicate the access point’s power and connection as follows: Flashing Amber Device is being powered on Cyclic between Firmware upgrade in process. Amber/Red Solid Amber Device has no Internet access. - 2 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...

  • Page 5: Installation

    In an AP Network, we first configure the Controller’s Wi-Fi and other related information. For details, please go to Network > AP Network. After the AP Network is established, the config­ urations of Controller will be automatically synchronized to all Agents. - 3 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...

  • Page 6: Connect To Network

    1. Place only one access point in a suitable location, and connect to the network as described in step 4.1. 2. Open a web browser and enter the URL https://ms659150m.local. 3. Log in to the Web UI using the default username: admin and password (Located on bottom of your access point).
  • Page 7 MAC address at the bottom of each access point and relative position in AP network. When all access points have successfully connected to the network, only the Controller’s LED is blue, the rest of the access points’ LEDs are green. - 5 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 8 Once the assigned Controller is recovered, it will act as the Controller of the AP Network again, and the automatically elected Controller will become Agent again. - 6 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...

  • Page 9: Automatically Elect Controller

    4.4. Change Password Change Access Point Password The user will be forced to change the password when logging into access point for the first time. - 7 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 10 • New Password: New sign in password for access point. Its length must be 8-16 characters and a strong password. • Confirm Password: Confirm new sign in password for access point. - 8 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...

  • Page 11: Settings

    The Wi-Fi password must be 8 characters or longer. 5. Settings Your access point comes with an intuitive Web User Interface (Web UI) that allows you to eas­ ily setup its feature. - 9 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...

  • Page 12: Dashboard

    Click LAN button to configure the LAN connection settings: 1. LAN Connection Type: Choose the Internet Service type. There are two options: DHCP and Static IP. 2. If you select DHCP: - 10 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 13 ◦ Default Gateway: Enter a gateway, usually the default gateway is the same as the LAN ◦ DNS 1 & DNS 2: Either of them indicates IP address of a DNS Server. ◦ Click Save. - 11 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 14 The access point supports two AP Modes: Agent and Controller. No matter which mode the access point is, both 2.5G and 1G Eth port act as LAN ports. - 12 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 15 6. Broadcast SSID: Unable to search for SSID when is OFF. 7. Wi-Fi Password: Enter your Wi-Fi password. A complex, hard-to-guess key is recom­ mended. The Wi-Fi password must be 8 characters or longer. - 13 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 16 14. WMM: Deployment of WMM will deliver useful QoS functionality for services such as voice over 802.11 and streaming media. 15. WMM APSD: Enable/disable automatic power save delivery. 16. Rate Limit: Enable/disable SSID related rate limit. 17. Click Save. - 14 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 17 5. Control Channel: Select a wireless radio channel or use the default “Auto” setting from the drop-down menu. Changing radio channel can improve Wi-Fi signal depending on how crowded the channel is with other radio signals and interference. - 15 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 18 Steps to set up the ACL: 1. Frequency: In the frequency field, select the frequency band that you want to use for the - 16 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 19 MAC addresses from associating with the AP, or specifically indicates which MAC addresses can associate with the AP. 6. Click Save. RRM (Radio Resource Management), contains functions as follows: - 17 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 20 Band steering: lets the access point identify the Wi-Fi devices that are dual-band capable and steer those devices to the 2.4 GHz or 5 GHz band of a Wi-Fi network. - 18 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 21 Steps to set Schedule 1. SSID: Select the SSID to configure. 2. Wireless Scheduler: Enable or disable wireless schedule. 3. Effective Working Day: Select working days to enable Wi-Fi. - 19 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 22 The VLAN is applied to Wi-Fi Settings, for details, please go to Network > AP Network > Basic. Mesh The Mesh page allows you to configure all APs’ mesh mode: standalone, root and extender. - 20 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 23 APs in root or standalone mode will display on the same level. APs in extender mode will display in next level which they connected the AP in root mode. - 21 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...

  • Page 24: Authentication

    1. Username: Name to sign in radius server. 2. Password: Password to sign in radius server. 3. Confirm Password: Confirm password to sign in radius server. 4. Click Add. - 22 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 25 3. IP Address: Enter the IPv4 address of the Radius Server. The access point must be able to reach the IP address. 4. Shared Secret: It’s used between the access point and the RADIUS server during the authentication or accounting process. - 23 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...

  • Page 26: Diagnostics

    Display the APs’ information in AP Network, with quick links to SSID List, Radio Settings and AP Settings. And you can quickly find the relevant AP through the search function. - 24 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 27 Indoor Enterprise Access Point - User Manual - MS659150M SSID List Display Radio, SSID, VLAN and other information of the Wi-Fi Network. - 25 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 28 Indoor Enterprise Access Point - User Manual - MS659150M Radio Status The Radio Status page shows you radio information of each AP in the AP Network. - 26 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 29 Info in detail by clicking Clients MAC. And you can quickly find the relevant clients through the search function. Clients Info Display the details of the client’s connection information. - 27 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 30 Indoor Enterprise Access Point - User Manual - MS659150M Events Record Controller, Agent status, Wi-Fi client connection status, etc. And you can quickly find the relevant events log through the search function. - 28 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 31 Indoor Enterprise Access Point - User Manual - MS659150M Neighbouring AP List Displays nearby Wi-Fi Network information. And you can quickly find the relevant Wi-Fi Net­ works through the search function. - 29 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 32 Indoor Enterprise Access Point - User Manual - MS659150M Spectral Scan Scan the selected Wi-Fi channel. - 30 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...

  • Page 33: Qos

    6. Current Client List: Select client by MAC address. 7. Client MAC: Manually enter a client MAC address 8. Percentage: Set the percentage for client which will be used for ATF control. 9. Click Confirm. - 31 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 34 Indoor Enterprise Access Point - User Manual - MS659150M - 32 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...

  • Page 35: System Settings

    4. Confirm Password: Confirm new sign in password for access point. 5. Time Zone: The default value is Auto. 6. Auto Logout: Auto sign out after a specified period of time. - 33 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 36 You can reset the access point back to its default settings using the Reset button on the back of the access point (press and hold for 5+ seconds). - 34 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 37 MIB Browser, which can connect to the network device of the specified IP, and obtain the OID value of the specified MIB through the SNMP protocol, supporting v1, v2, and v3 versions. - 35 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 38 3. Get Community String: The community name with read permission. 4. Set Community String: The community name with write permission. 5. SNMP Traps: Enable or disable SNMP Traps. - 36 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 39 5. Context Name: Used to determine the MIB view of the SNMP unique identifier to the man­ aged device. 6. SNMPv3 Traps: Enable or disable SNMPv3 Traps. 7. Address for SNMPv3 Trap Server 8. SNMPv3 Trap Server Port - 37 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...

  • Page 40: Troubleshooting

    5 seconds and wait for the access point to restart. Then repeat the connection process as described in 4. Establish AP network. - 38 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...

  • Page 41: Cannot Access The Web User Interface To Configure Settings

    • Main SoC: Qualcomm IPQ8072A, Quad A53 @ 2.2GHz • Memory: 1GB DDR4, 8GB eMMC RF Functions • DBDC 802.11ax Wi-Fi with 8 spatial Wi-Fi streams Power Input • DC input: 12V • PoE+ - 39 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...

  • Page 42: Wi-Fi

    • 5Ghz VHT80/HE80 : -91dBm @ MCS0 Max Number of • Up to 128 per radio, so 256 if 2,4 and 5 GHz are used Clients ESSIDs • Up to 8 - 40 - © 2022 MICROSENS GmbH & Co. KG, All Rights Reserved...
  • Page 43 All information in this document is provided 'as is' and is subject to change without notice. MICROSENS GmbH & Co. KG disclaims any liability for the correctness, completeness or quality of the information provided, fitness for a particular purpose or ensuing damage.
