- Page 1 Oldfield Amplifiers User Guide Model 59...
- Page 2 Thank You Welcome to the Oldfield family and thank you for putting your trust in Oldfield Amplifiers. We value that trust as much as you will enjoy your new Oldfield amplifier. Your new Oldfield amplifier is built to provide you with the best tonal experience and durability available in a guitar amplifier.
-
Page 3: Table Of Contents
Table Of Contents Important Safety Instructions....................4~5 Overview...........................6 Front Panel Controls And Features..................7 Rear Panel Controls And Features...................9 Tube Layout........................11 Warranty...........................1 2 Operational Tips.......................1 3... -
Page 4: Important Safety Instructions
∆ Do not drip or splash liquids, nor place liquid filled containers on the unit. ∆ CAUTION: No user serviceable parts inside, refer servicing to qualified personnel only. Do not expose the circuit of the amplifier under any circumstances. Oldfield Amplifiers Page 4... - Page 5 ∆ CAUTION: By nature vacuum tubes get very hot during operation. Do not touch vacuum tubes until they have sufficiently cooled. ∆ Oldfield amplifiers are capable of producing very high sound pressure levels which may cause temporary or permanent hearing damage. Use care when setting and adjusting volume levels during use.
-
Page 6: Overview
The 5922 has two very distinctly voiced channels. Channel One is smooth and bold with great clean tone and tweedy overdrive. Channel Two is a little brighter and edgier. Both channels use the complete tone stack and Channel One has it’s own Top Cut control. -
Page 7: Front Panel Controls And Features
(Reference the front panel viewing left to right) Manual Channel Selector: This switch is used to select either Channel One or Channel Two of the 5922. (Note: The switch must be in the Channel Two position when operating the amplifier with the footswitch.) - Page 8 “On” position for at least one minute to give the tubes time to warm up. Mains: Move to the up position to power up the amplifier and down to shut the amplifier completely off. Oldfield Amplifiers Page 8...
-
Page 9: Rear Panel Controls And Features
If no noise is heard the amp should be turned off immediately and speaker connections checked. SPEAKER IMPEDENCE SELCTOR: Position the selector switch to match the amplifier speaker load. The amplifier is capable of handling a 4, 8, or 1 6 ohm load. Oldfield Amplifiers Page 9... - Page 10 Rear Panel: Controls And Features EFFECTS LOOP: Send / Receive / Bypass switch for the serial effects loop. The bypass switch disables the effects loop. Footswitch Jack: Connect the channel switching footswitch to this jack. Oldfield Amplifiers Page 1 0...
-
Page 11: Tube Layout
POWER TUBES: 6V6 (x2). Replace only with a high quality matched pair of 6V6 tubes. The 5922 is a Class A, cathode biased amplifier and therefore does not need to be re- biased when changing output tubes. PHASE INVERTER TUBE: Replace with any high quality 1 2AX7 tube. -
Page 12: Warranty
The following warranties apply to the original owner of the amplifier. All warranty work must be performed by Oldfield or an authorized technician for the warranty to be in effect. Warranties do not cover normal wear and tear or abuse. Failure to comply with the safety precautions outlined earlier in the owner’s manual will void all warranties. -
Page 13: Operational Tips
Operation Tips 1 . The 5922 is a cathode biased Class A amplifier. This style of amplifier responds really well to the position of the master volume control. The amplifier can obtain many different tones by controlling the master volume. As with most Class A amplifiers the amplifier's tone greatly opens up with the master volume turned up to 1 2 o'clock and beyond.
