Split 612 UHD 2.0
USER MANUAL
GEBRAUCHSANLEITUNG
GUIDE UTILISATEUR
MODO DE EMPLEO
MANUALE D'ISTRUZIONI
GEBRUIKSAANWIJZING
20667/ 20170904 • Split 612 UHD 2.0
ALL RIGHTS RESERVED MARMITEK ©
3
11
19
27
35
43

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 25008323 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Marmitek 25008323

  • Page 1 612 UHD Split 612 UHD 2.0 ™ USER MANUAL GEBRAUCHSANLEITUNG GUIDE UTILISATEUR MODO DE EMPLEO MANUALE D’ISTRUZIONI GEBRUIKSAANWIJZING 20667/ 20170904 • Split 612 UHD 2.0 ™ ALL RIGHTS RESERVED MARMITEK ©...
  • Page 2 © MARMITEK...
  • Page 3: Table Of Contents

    1 Table of contents Table of contents ..................... 3 Safety instructions ................... 4 Your product ....................5 Introduction ................... 5 Benefits ....................5 HDMI properties ..................5 Set contents ..................5 Getting started ....................6 Before installation: ................. 6 Installation ..................... 6 Use .........................
  • Page 4: Safety Instructions

    Improper use, self-installed modifications or repairs will void any and all warranties. Marmitek does not accept any product responsibility for incorrect use of the product or use other than for which the product is intended. Marmitek does not accept liability for any consequential damage other than the legal product responsibility.
  • Page 5: Your Product

    3 Your product Introduction Congratulations on your purchase of the Marmitek Split 612 UHD 2.0™! This active HDMI splitter connects 2 TVs or projectors with a single HDMI source. Unlike passive HDMI splitters, it can do this without any loss of signal or encryption, while maintaining optimal image quality.
  • Page 6: Getting Started

    Preferably, connect the TV or projector with the highest resolution (e.g. UltraHD) to "Output 1" and those with a lower resolution (e.g. Full HD) to "Output 2". Connect the power adapter to the "DC 5V" input and insert the plug into the socket. © MARMITEK...
  • Page 7: Use

    5 Use EDID EDID stands for Extended Display Identification Data and is used for communication between HDMI sources and TVs, enabling you to determine the supported display resolutions and audio formats. The HDMI source requests this information from the TV and determines the best resolution or audio format. When using multiple TVs (TVs or projectors), the best resolution and audio format that is supported by all connected TVs is determined.
  • Page 8: Product Details

    Dimensions (H x W x D) 100 x 56 x 17 mm Weight 158 g Environment Ambient temperature +0 to +40° C Humidity 20% to 90% Power External power adapter 100-240VAC @50-60Hz, 5VDC @ 1A Specifications may change without prior notice. © MARMITEK...
  • Page 9: Frequently Asked Questions (Faqs)

    Please check that 3D is displayed correctly by connecting the HDMI source directly to the HD display with an HDMI cable. Do you have other questions that have not been resolved by the above information? Please go to www.marmitek.com SPLIT 612 UHD 2.0™...
  • Page 10: Notification

    Copyrights Marmitek is a trademark of Germatron B.V. Split 612 UHD 2.0™ is a trademark of Marmitek B.V. All rights reserved. Every effort has been made to ensure that the information in this manual is accurate. Marmitek is not responsible for printing or clerical errors. Copyright and all other proprietary rights in the content (including but not limited to model numbers, software, audio, video, text and photographs) rests with Marmitek B.V.
  • Page 11: Inhaltsverzeichnis

    1 Inhaltsverzeichnis Inhaltsverzeichnis ..................11 Sicherheitshinweise ..................12 Ihr Produkt ....................13 Einführung ................... 13 Vorzüge ....................13 HDMI eigenschaften ................13 Verpackungsinhalt ................13 Los geht’s ...................... 14 Bevor Sie beginnen ................14 Installation ................... 14 Verwendung ....................15 EDID ....................
  • Page 12: Sicherheitshinweise

    Gerät längere Zeit nicht nutzen. Bei einer zweckwidrigen Verwendung, selbst angebrachten Veränderungen oder selbst ausgeführten Reparaturen verfallen alle Garantiebestimmungen. Marmitek übernimmt bei einer falschen Verwendung des Produkts oder bei einer anderen Verwendung des Produktes als für den vorgesehenen Zweck keinerlei Produkthaftung.
  • Page 13: Ihr Produkt

    3 Ihr Produkt Einführung Herzlichen Glückwunsch zum Erwerb Ihres Marmitek Split 612 UHD 2.0™! Dieser aktive HDMI Splitter verbindet 2 Bildschirme (TV oder Projektor) mit einer HDMI Quelle. Im Gegensatz zu passiven HDMI Splittern geschieht dies ohne jeglichen Signal- oder Verschlüsselungsverlust und unter Beibehaltung optimaler Bildqualität.
  • Page 14: Los Geht's

    Auflösung (z.B. Utra HD) an den “Output 1" und mit einer geringeren Auflösung (z.B. Full HD) an den “Output 2“ Anschluss an. Schließen Sie den Speisungsadapter an den “DC 5V“ Eingang an und verbinden Sie diesen mit der Steckdose. © MARMITEK...
  • Page 15: Verwendung

    5 Verwendung EDID EDID bedeutet Extended Display Identification Data und wird für die Kommunikation zwischen HDMI Quellen und Bildschirmen verwendet, um die unterstützten Bildauflösungen und Audioformate zu bestimmen. Die HDMI Quelle ruft diese Informationen vom Bildschirm ab und bestimmt die beste Auflösung oder das beste Audioformat.
  • Page 16: Produktinformationen

    Maßangaben (H x B x T) 100 x 56 x 17 mm Gewicht 158 g Umgebung Umgebungstemperatur +0 to +40° C Relative Feuchte 20% bis905% Speisung Externer Speisungsadapter 100-240VAC @50-60Hz, 5VDC @ 1A Angaben können ohne vorherige Mitteilung geändert werden. © MARMITEK...
  • Page 17: Häufig Gestellte Fragen (Faqs)

    Überprüfen Sie, ob 3D korrekt wiedergegeben wird, indem Sie die HDMI Quelle mit einem HDMI Kabel direkt an den HD Bildschirm anschließen. Sie haben noch Fragen, die im Obigen nicht beantwortet wurden? Schauen Sie dann unter www.marmitek.com SPLIT 612 UHD 2.0™...
  • Page 18: Hinweis

    Entsorgungsdienste oder an den Händler, bei dem Sie das Produkt erworben haben. Urheberrechte Marmitek BV ist ein Warenzeichen von Germatron. Split 612 UHD 2.0™ ist ein Warenzeichen von Marmitek BV. Alle Rechte vorbehalten. Weitergehende Ansprüche sind ausgeschlossen, insbesondere übernimmt Marmitek BV keine Gewähr für die Richtigkeit des Inhalts dieses Handbuchs.
  • Page 19 1 Table des matières Table des matières ..................19 Consignes de sécurité ................... 20 Votre produit....................21 Introduction ..................21 Caractéristiques du produit ..............21 Caractéristiques HDMI ................ 21 Contenu de l'emballage ............... 21 Au travail ....................... 22 Conseils d'installation ................22 Installation ...................
  • Page 20: Consignes De Sécurité

    La garantie n'est plus valable en cas d'usage inapproprié, de modifications ou de réparations effectuées par des personnes non agréées. Marmitek se dégage de toute responsabilité en cas d'usage inapproprié du produit ou d'utilisation non conforme à l'usage auquel le produit est destiné.
  • Page 21: Votre Produit

    3 Votre produit Introduction Félicitations pour l'achat du Marmitek Split 612 UHD 2.0™ ! Ce répartiteur HDMI actif relie 2 écrans (téléviseur ou projecteur) avec une seule source HDMI. Contrairement aux répartiteurs HDMI passifs cela peut être réalisé sans aucune perte de signal ou de cryptage tout en conservant une qualité d'image optimale.
  • Page 22: Au Travail

    (par exemple Ultra HD) sur “Output 1” et celui avec une résolution plus faible (par exemple Full HD) sur “Output 2”. Connectez l'adaptateur secteur sur l’entrée “DC 5V” et branchez la fiche dans la prise de courant. © MARMITEK...
  • Page 23: Utilisation

    5 Utilisation EDID EDID signifie Extended Display Identification Data (Données Étendues d'Identification d'Affichage) et il est utilisé pour la communication entre les sources HDMI et les écrans afin de déterminer les résolutions d'images et les formats audio pris en charge. La source HDMI demande ces informations à...
  • Page 24: Informations Produit

    Boîtier du Répartiteur Dimensions (H x L x P) 100 x 56 x 17 mm Poids 158 g Environnement Température ambiante +0 à +40ºC Humidité ambiante 20% à 90% Alimentation Adaptateur secteur externe 100-240VAC @50-60Hz, 5VDC @ 1A © MARMITEK...
  • Page 25: Foire Aux Questions (Faq)

    Assurez-vous que l'image 3D soit restituée correctement en connectant la source HDMI directement à l'écran HD avec un câble HDMI. Les informations ci-dessus n'ont pas répondu à vos questions ? Veuillez consulter le site internet www.marmitek.com SPLIT 612 UHD 2.0™...
  • Page 26: Notification

    Marmitek est une marque déposée de Germatron BV. Split 612 UHD 2.0™ est une marque déposée de Marmitek BV. Tous droits réservés. Tout a été mis en œuvre pour que les informations présentées dans ce manuel soient exactes. Marmitek n’est pas responsable des erreurs de reproduction ou d’impression.
  • Page 27: Contenido

    1 Contenido Contenido ...................... 27 Instrucciones de seguridad ................28 El producto ....................29 Introducción ..................29 Características del producto ..............29 Características HDMI ................29 Contenido del embalaje ............... 29 Primeros pasos ..................... 30 Consejos para la instalación ..............30 Instalación ...................
  • Page 28: Instrucciones De Seguridad

    En caso de uso indebido o modificaciones y reparaciones montados por su mismo, la garantía se caducará. En caso de uso indebido o inapropiado, Marmitek no acepta ninguna responsabilidad de producto. Marmitek no acepta la responsabilidad para daños consecuenciales que difieren de la responsabilidad de producto legal.
  • Page 29: El Producto

    3 El producto Introducción Felicidades por la compra del Marmitek Split 612 UHD 2.0™! Este splitter HDMI activo conecta 2 pantallas (TV o proyector) con una fuente HDMI. En comparación con Splitters HDMI pasivos, el Splitter activo realiza la transmisión sin pérdida de señal o encriptación, manteniendo la calidad superior de la imagen.
  • Page 30: Primeros Pasos

    Conecta preferentemente el TV o proyector con la resolución más alta (p.e. Ultra HD) con “Output 1” y el TV con una resolución más baja (p.e. Full HD) con “Output 2”. Conecta el adaptador de alimentación con la entrada “DC 5V” y enchufa en la toma de corriente. © MARMITEK...
  • Page 31: Uso

    5 Uso EDID EDID signífica “Extended Display Identification Data“ y se usa para la comunicación entre las fuentes HDMI y las pantallas para determinar las resoluciones de imagen y los compatibles formatos de audio. La fuente HDMI solicita esta información de la pantalla y determina cuales son la mejor resolución o el mejor formato de audio.
  • Page 32: Información Del Producto

    100 x 56 x 17 mm Peso 158 g Ambiente Temperatura ambiental +0 hasta +40° C Humedad ambiental 20 % hasta 90 % Alimentación Adaptador de alimentación externo 100-240 VAC @50-60 Hz, 5VDC@ 1ª Las especificaciones se pueden cambiar sin previo aviso. © MARMITEK...
  • Page 33: Preguntas Frecuentes (Faqs)

    Tanto la fuente HDMI como la pantalla HD tienen que ser compatibles con los mismos formatos de 3D. Controla si la fuente HDMI reproduce el 3D correctamente. Por este objetivo, conéctala con la pantalla a traves de un cable HDMI. ¿Tiene otras preguntas? Visite www.marmitek.com SPLIT 612 UHD 2.0™...
  • Page 34: Notificación

    Derechos de propiedad intelectual Marmitek es una marca registrada de Germatron BV. Split 612 UHD 2.0™ es una marca registrada de Marmitek BV. Todos los derechos reservados.En la realización de este manual se ha puesto el máximo cuidado para asegurar la exactitud de la información que en él aparece.
  • Page 35: Indice

    1 Indice Indice ......................35 Precauzioni di sicurezza ................36 Il prodotto ...................... 37 Introduzione ..................37 Vantaggi ....................37 Caratteristiche HDMI ................37 Contenuto della confezione ..............37 Per iniziare ....................38 Consigli per l’installazione ..............38 Installazione ..................38 Uso .......................
  • Page 36: Precauzioni Di Sicurezza

    In caso di utilizzo scorretto, di riparazioni o modifiche apportate personalmente decade qualsiasi garanzia. della responsabilità civile sui prodotti. Marmitek declina ogni responsabilità per i danni derivanti da un utilizzo non appropriato del prodotto o da utilizzo diverso da quello per cui il prodotto è stato creato.
  • Page 37: Il Prodotto

    3 Il prodotto Introduzione Congratulazioni per l’acquisto del Marmitek Split 612 UHD 2.0™! Questo splitter HDMI attivo collega 2 schermi (televisore o proiettore) ad una sorgente HDMI. Al contrario degli splitter HDMI passivi, questo è possibile senza perdita di segnale o crittografia pur mantentendo una qualità ottimale dell’immagine. Ideale anche per l’uso con estensori HDMI, per esempio in un’altra stanza.
  • Page 38: Per Iniziare

    Preferibilmente collegare il televisore o proiettore con la risoluzione più alta (per esempio Ultra HD) alla porta “Output 1” e con una risoluzione più bassa (per esempio Full HD) alla porta “Output 2”. Collegare l’alimentatore all’ingresso “DC 5V” ed inserire la spina nella presa. © MARMITEK...
  • Page 39: Uso

    5 Uso EDID EDID è l’acronimo per Extended Display Identification Data e viene utilizzato per la comunicazione tra le sorgenti HDMI e gli schermi, per determinare le risoluzioni dell’immagine ed i formati audio. La sorgente HDMI chiede queste informazioni allo schermo e determina la migliore risoluzione o formato audio.
  • Page 40: Informazioni Prodotto

    100 x 56 x 17 mm Peso 158 g Ambiente Temperature ambiente +0 fino ai +40° C Umidità di ambiente 20% all’ 90% Alimentazione Adattatore esterno 100-240VAC @50-60Hz, 5VDC @ 1° Le caratteristiche tecniche possono essere modificate senza preavviso. © MARMITEK...
  • Page 41: Domande Frequenti (Faq)

    Sia la sorgente HDMI che lo schermo HD devono supportare gli stessi formati 3D. Controllare se è corretta la riproduzione 3D collegando la sorgente HDMI direttamente allo schermo HD con un cavo HDMI. Hai ulteriori domande che non sono state risposte qui sopra? Visita www.marmitek.com SPLIT 612 UHD 2.0™...
  • Page 42: Notifica

    Marmitek. Tutti i diritti d’autore e altri diritti di proprietà intellettuale su tutte le riproduzioni devono essere conservati. I nomi di altre società e prodotti qui menzionati potrebbero essere marchi delle rispettive società.
  • Page 43: Inhoudsopgave

    1 Inhoudsopgave Inhoudsopgave ....................43 Veiligheidsinstructies ..................44 Uw product .....................45 Introductie ....................45 Voordelen.....................45 HDMI eigenschappen ................45 Inhoud van de verpakking ..............45 Aan de slag ....................46 Tips voor installatie ................46 Installatie ....................46 Gebruik ......................47 EDID ....................47 EDID Auto of Copy 1 ................47 Productinformatie ...................48 Technische specificaties ..............48 Veel gestelde vragen (FAQs) .................49...
  • Page 44: Veiligheidsinstructies

    Bij oneigenlijk gebruik, zelf aangebrachte veranderingen of reparaties, komen alle garantiebepalingen te vervallen. Marmitek aanvaardt geen productaansprakelijkheid bij onjuist gebruik van het product of door gebruik anders dan waarvoor het product is bestemd. Marmitek aanvaardt geen aansprakelijkheid voor volgschade anders dan de wettelijke productaansprakelijkheid.
  • Page 45: Uw Product

    3 Uw product Introductie Gefeliciteerd met de aankoop van de Marmitek Split 612 UHD 2.0™! Deze actieve HDMI splitter verbindt 2 tv’s of projectors met één HDMI bron. In tegenstelling tot passieve HDMI splitters kan dit zonder enig signaal- of encryptieverlies en met behoud van optimale beeldkwaliteit.
  • Page 46: Aan De Slag

    Sluit bij voorkeur de tv of projector met de hoogste resolutie (bijvoorbeeld Ultra HD) aan op “Output 1” en met een lagere resolutie (bijvoorbeeld Full HD) aan op “Output 2”. Sluit de voedingsadapter aan op de “DC 5V” ingang en steek de stekker in het stopcontact. © MARMITEK...
  • Page 47: Gebruik

    5 Gebruik EDID EDID staat voor Extended Display Identification Data en deze wordt gebruikt voor communicatie tussen HDMI bronnen en tv’s of projectors om de ondersteunde beeldresoluties en audio formaten te bepalen. De HDMI bron vraagt aan de tv of projector deze informatie op en bepaalt de beste resolutie of audio formaat.
  • Page 48: Productinformatie

    Afmetingen (H x B x D) 100 x 56 x 17 mm Gewicht 158 g Omgeving Omgevingstemperatuur +0 to +40° C Luchtvochtigheid 20% tot 90% Voeding Externe voedingsadapter 100-240VAC @50-60Hz, 5VDC @ 1A Specificaties kunnen wijzigen zonder voorafgaande melding hiervan. © MARMITEK...
  • Page 49: Veel Gestelde Vragen (Faqs)

    Controleer of 3D correct wordt weergegeven door de HDMI bron direct op uw tv of projector aan te sluiten met een HDMI kabel. Heeft u vragen die hierboven niet beantwoord worden? Kijk dan op www.marmitek.com SPLIT 612 UHD 2.0™...
  • Page 50: Kennisgeving

    8 Kennisgeving Verklaring van Overeenstemming Bij deze verklaart Marmitek BV, dat deze Split 612 UHD 2.0™ voldoet aan de essentiële eisen en aan de overige relevante bepalingen van Richtlijnen: Richtlijn 2014/30/EU van het Europees Parlement en de Raad van 26 februari 2014 betreffende de harmonisatie van de wetgevingen van de lidstaten inzake elektromagnetische compatibiliteit (herschikking).
  • Page 51 SPLIT 612 UHD 2.0™...
