Owner's Manual
Thank you, and congratulations on your choice of the Roland Personal Monitor System PM-3.
Before using this unit, carefully read the sections entitled: "IMPORTANT SAFETY
INSTRUCTIONS" (p. 2), "USING THE UNIT SAFELY" (p. 3), and "IMPORTANT NOTES" (p.
4). These sections provide important information concerning the proper operation of the
unit. Additionally, in order to feel assured that you have gained a good grasp of every
feature provided by your new unit, Owner's manual should be read in its entirety. The
manual should be saved and kept on hand as a convenient reference.
Features
• The PM-3 personal monitor system is perfect for electronic percussion set-ups such as V-Drums,
SPD-20, etc. And also fills the needs for small keyboard monitoring systems.
• When set up as Roland advises, the woofer unit and two speakers provide a three-dimensional
depth and sound, creating an ambience similar to when playing acoustic drums.
• The woofer unit features an "Active Dual-Drive" system, consisting of two speakers producing a
powerful "low end."
• MIX INPUT, LINE OUTPUT and MAIN INPUT jacks are provided to expand the possibilities
(practice/monitoring/live performance etc.)
Copyright © 2000 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the
written permission of ROLAND CORPORATION.

Advertisement

Table of Contents
loading

Related Manuals for Roland PM-3

Summary of Contents for Roland PM-3

  • Page 1 Features • The PM-3 personal monitor system is perfect for electronic percussion set-ups such as V-Drums, SPD-20, etc. And also fills the needs for small keyboard monitoring systems.

  • Page 2: Grounding Instructions

    CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN ATTENTION : RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS.
  • Page 3 • Before using the unit in a foreign country, consult with your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the "Information" page.

  • Page 4: Important Notes

    (including padding) that it came in, if possible. Otherwise, you will need to use equivalent packaging materials. • Use a cable from Roland to make the connection. If using some other make of connection cable, please note the following precautions.
  • Page 5 Attaching the Mount Bracket fig.1e Hole Mount Plate Screw No. 10-32 x 3/8" Flat/Phillips Black (included) 1. Using the provided screws, attach the mount plate to the bottom of the speaker so it is oriented as shown in the diagram. fig.2e 2.

  • Page 6: Panel Descriptions

    This adjusts the volume of the device connected to the MAIN INPUT Jacks 7 . * The input sensitivity of the PM-3 has been set somewhat high, to allow use with percussion sound modules having relatively low output levels. But if you connect a sound module with a high output level (such as the TD-10), distortion may occur if you turn the volume level up too much.
  • Page 7 Jacks (Side Panel) fig.5 fig.ADD_logo2 With the Active Dual-Drive system driving one woofer that is facing outwards, along with the aligned bass-reflex woofer inside the cabinet, this system, despite its compact size, delivers rock-bottom bass sounds with impressive attack, outperforming even bigger, cabinet-sized speakers. 7.
  • Page 8 1. Make sure that all volume controls on the PM-3 and connected devices are set to “0.” 2. Turn on the devices connected to the MAIN INPUT Jacks and MIX INPUT Jacks.

  • Page 9: Sample Setting

    Attach the speakers to the drum stand using the mount brackets (included). * Do not use any speakers except the included speakers. Roland Woofer Unit * Be sure to place the woofer unit so that the heat sink on the side panel is not obstructed.

  • Page 10: Block Diagram

    Block Diagram fig.8...

  • Page 11: Specifications

    Specifications System Configuration Speaker (x 2) + Woofer Unit Rated Power Output Speaker 50 W/8 ohms x 2 Woofer Unit 100 W/4 ohms Total 200 W Nominal Input Level Main Input -10 dBu Mix Input -10 dBu Nominal Output Level Line Output -10 dBu Speakers...
  • Page 12 17055111 3*RAD...
