Sealey 500TTJ.V2 Manual

thank you for purchasing a sealey product. manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear
instructions safety
footwear
1. safety
WarninG: The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions
‰
and situations that may occur. It must be understood that common sense and caution are factors which cannot be built into this
product, but must be applied by the operator.
WarninG! ensure all preliminary checks are carefully carried out before use of jack. Immediately repair or replace damaged
‰
parts (use authorised service agent). ensure use of genuine parts only. Unauthorised parts may be dangerous and will invalidate
the warranty.
WarninG! Use jack on level, solid ground, preferably concrete. ensure the floor over which the jack will be transported is swept clean.
‰
▲ DanGer! Do not use on tarmacadam, or any other soft surface as jack may sink or topple. Serious injury may result if ignored.
▲ DanGer! If jack tips or leans stop What your are DoinG. moVe QuickLy to a safe Distance. Do not try to hoLD
or steaDy jack.
Use jack in a suitable work area. Keep the area clean and tidy and free from unrelated materials. ensure there is adequate lighting.
9
Before use ensure the gearbox weight and size does not exceed the capacity of the jack.
9
ensure the vehicle is raised and stabilised at the correct height before attempting to move the jack under the vehicle.
9
ensure the jack saddle is fully lowered and is clean, dry, and oil free before attempting to transport the jack with or without a load.
9
Keep all unauthorised persons away from the jack during lifting and lowering and when in transit.
9
maintain correct balance and footing. ensure the floor is not slippery and wear non-slip shoes.
9
Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery, and contain and/or tie back long hair.
9
WarninG! ensure that the load is placed level and centrally on the jack saddle and that it is fixed in place before attempting to lift,
9
lower or transport the load.
The lowering speed will vary according to the weight of the load and the release valve setting.
9
diligence is required in ensuring that you continually monitor the operation until completed.
9
Should the jack make any abnormal sounds during use, SToP ImmedIATelY and contact your local service agent.
9
Do not operate the jack if any parts are damaged or missing.
8
Do not exceed the rated capacity of the jack.
8
Do not raise/lower vehicle lifting platform whilst the transmission jack is being used.
8
Do not transport the jack with/without a load, with the saddle in the raised position.
8
Do not get the jack wet, or use it in damp or wet locations or areas where there is condensation.
8
Do not operate the jack when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
Do not lift or support vehicles with the jack and Do not use the jack as a load sustaining device.
8
Do not use the jack for any purpose other than removal, transportation and the installation of transmissions.
8
Do not make any modifications to the jack.
8
Do not adjust, or tamper with, the safety valve.
8
Do not remove any labels from the jack. If the labels are damaged or unclear, replace them.
8
Do not use brake fluid to top up the hydraulic unit.
8
Use Sealey hydraulic oil only.
9
Use a qualified person to to lubricate and maintain the jack.
9
Before storing the jack in a safe area, ensure that all parts, especially the saddle are clean and free of grease and oil.
9
2. introDuction
Telescopic 2-stage model for reduced clearance lifts. Featuring high speed lift to gearbox - just lift piston. Foot pedal operation
keeps hands free. Spring loaded dead man's safety release control reduces the risk of inadvertent lowering. Highly manoeuvrable on
castors.
© Jack Sealey limited
transmission jack 0.5 tonne
500ttj.V2
model no:
Original Language Version
500TTJ.V2 | Issue 1 28/02/19
