- Page 1 Heat Pump Dryer User manual DV9*BB94****/DV9*BB74**** B-PJT_DV9400B_SimpleUX_DC68-04400M-00_EN (SA).indd 1 2023/4/10 15:30:12...
-
Page 2: Table Of Contents
Contents Safety information What you need to know about the safety instructions Important safety symbols Important safety precautions To minimize the risk of fire in a tumble dryer, the following should be observed Critical installation warnings Critical usage warnings Usage cautions Critical cleaning warnings Care for preventing freezing Installation... - Page 3 Troubleshooting Checkpoints Information codes Appendix Fabric care chart Protecting the environment Specification English B-PJT_DV9400B_SimpleUX_DC68-04400M-00_EN (SA).indd 3 2023/4/10 15:30:12...
-
Page 4: Safety Information
Safety information Congratulations on your new Samsung dryer. This manual contains important information on the installation, use, and care of your appliance. Please take the time to read this manual to take full advantage of your dryer’s many benefits and features. -
Page 5: Important Safety Precautions
Important safety precautions WARNING To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. This appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. - Page 6 Safety information 6. For use in Europe: Children of less than 3 years should be kept away unless continuously supervised. 7. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance must not be electrical connected through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by the utility.
- Page 7 15. The final part of a tumble dryer cycle occurs without heat (cool down cycle) to ensure that the items are left at a temperature that ensures such items will not be damaged. 16. Remove all objects from pockets such as lighters and matches. 17.
-
Page 8: To Minimize The Risk Of Fire In A Tumble Dryer, The Following Should Be Observed
Safety information To minimize the risk of fire in a tumble dryer, the following should be observed CAUTION Items that have been spotted or soaked with vegetable or cooking oil constitute a fire hazard and should not be placed in a tumble dryer. Oil-affected items can ignite spontaneously, especially when exposed to heat sources such as in a tumble dryer. -
Page 9: Critical Installation Warnings
Oil-affected items can ignite spontaneously, especially when exposed to heat sources such as in a tumble dryer. The items become warm, causing an oxidation reaction in the oil. Oxidation creates heat. If the heat cannot escape, the items can become hot enough to catch fire. Piling, stacking or storing oil-affected items can prevent heat from escaping and so create a fire hazard. -
Page 10: Critical Usage Warnings
Safety information If the plug (power supply cord) is damaged, it must be replaced by the manufacturer, its service agent or a similar qualified technician in order to avoid a hazard. This appliance should be positioned to be accessible to the power plug after installation. Do not pull or excessively bend the power cord. -
Page 11: Usage Cautions
The use for business purposes qualifies as product misuse. In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse. -
Page 12: Critical Cleaning Warnings
Safety information Also, do not allow children to play around the dryer or touch the door glass. • This may result in burns. Do not press the buttons using sharp objects such as pins, knifes, fingernails, etc. • This may result in electric shock or injury. Do not dry laundry containing forming rubber such as latex or similar rubber textures. -
Page 13: Care For Preventing Freezing
Before cleaning or performing maintenance, unplug the appliance from the wall socket. • Failure to do so may result in electric shock or fire. Clean the filter case before and after using the dryer. Clean the inside of the product on a regular basis by asking an authorized service engineer. Clean the Heat Exchanger with a soft brush or vacuum cleaner once a month, Do not touch the heat exchanger with your hand, there is a danger it may cause an injury. -
Page 14: Installation
Carefully unpack the dryer. Keep all packaging materials away from children. The parts and location of parts shown below may differ from your dryer. Before installation, make sure the dryer has all the parts listed here. If the dryer and/or parts are damaged or missing, contact the nearest Samsung customer service center. - Page 15 • The stacking kit allows the dryer to be stacked on top of a washer. Please note that the stacking kit can only be used with Samsung washers and dryers. To purchase a stacking kit above, contact a Samsung service centre or local appliance retailer. The stacking kit differs with the washer model.
-
Page 16: Installation Requirements
• Do not let children or pets play in, on, or around the dryer. Proper supervision is necessary at all times. • Keep all packaging materials away from children. • Do not replace a damaged power cord or power plug yourself. Have Samsung or a qualified service technician replace a damaged power cord or power plug. -
Page 17: Step-By-Step Installation
Alcove or closet installation For alcove or closet installation, the dryer requires the following minimum clearances: Sides Front Rear 25 mm 25 mm 490 mm 50 mm If installing the dryer with a washing machine, the front of the alcove or closet must have an unobstructed air opening of at least 550 mm. - Page 18 Installation STEP 2 Adjust the levelling feet 1. Gently slide the dryer into the desired location. 2. Use a level (A) and check the levelness of the dryer from side to side and front to back. 3. If the dryer is not level, turn the levelling feet (B) left or right to adjust the height.
- Page 19 STEP 3 Connect the drain hose • We strongly recommend connecting the drain hose to your drainage system. • If the drain hose connected on the dryer is too short to reach the drainage system, use the provided accessory hose (long drain hose). •...
- Page 20 Installation Over a wash basin: 1. Make sure to place the end of the accessory hose lower than 90 cm (*) from the bottom of dryer. 2. To bend some point of the accessory hose, use the supplied plastic hose guide (B) and secure the guide to the wall with a hook or to the tap with a piece of string.
-
Page 21: Door Reversal
STEP 4 Check the installation • All packaging material is completely removed and properly disposed. • The dryer is level and standing firmly on the floor. • Make sure no accessory remains inside the drum. • Do not block the air inlet hole of the cooling grill at the front of the dryer. •... - Page 22 Installation 2. Remove the screws on the inner glass holder of the door. First, loosen and remove the 3 screws on the bottom. Then, loosen and remove the 3 screws on the top of the holder. 3. Detach the glass holder. CAUTION Use caution not to drop any part of the holder when detaching it.
- Page 23 5. Remove the upper screw on the left of the door frame, and then insert it in the corresponding right hole of the door frame. Do not remove the lower bracket screws. 6. Remove the 2 bracket screws on the right frame, and then remove the 2 holder screws on the left frame.
- Page 24 Installation 9. Insert the lever holder on the right frame, and then tighten the 2 holder screws. 10. Insert the door hinge in the opposite position of the door frame, and then, tighten the 2 bolt screws. 11. Insert the inner glass holder in the door cover that has been installed on the left frame.
-
Page 25: Environment
13. Attach the door packing to the door. NOTE To return the door to the initial position, follow the steps again. Please note that the door, hinges, and other parts would be in the opposite orientation as listed in these steps. Environment Please dispose of the packaging materials for this product in an “environmentally friendly”... -
Page 26: Before You Start
Before you start Initial setup • When you turn on your dryer for the first time, the screen shows the initial setup process. Follow the onscreen instructions to complete it. • If you complete the initial setup and operate a cycle for more than a minute, the initial setup will not appear again. -
Page 27: Drying Guidelines
Drying guidelines STEP 1 Sort • Do not mix heavy and lightweight items together. • Wash and dry dark-colored items separately from light-colored items. • Unless recommended on the care label, do not dry woolens or fiberglass items. • Do not dry items soiled with oil, alcohol, gasoline, etc. •... - Page 28 Before you start STEP 4 Determine the load capacity Do not overload the dryer. Overloading reduces the tumbling action, resulting in uneven drying and wrinkling. • Put one wash load in the dryer at a time. • To improve drying efficiency for one or two items, add a dry towel to the load. •...
-
Page 29: Operations
Operations Control panel Tap to turn the dryer on or off. • If you do not manipulate the control panel for 10 minutes after the dryer is turned on, the dryer automatically turns off. • The dryer automatically turns off when the drying completes. 01 Power ... - Page 30 Operations Tap to select the cycle time for Time Dry, Warm Air, or Cool Air. You can set 08 Time the drying time between 20 minutes and 240 minutes. Available drying time depend on the selected cycle. • Tap to enter the Options menu. 09 Options ...
-
Page 31: Operating A Cycle
Operating a cycle 1. Tap to turn on the dryer. 2. Turn the Navigation dial to select the cycle you want. For more information on “Cycle overview”, see page 32. 3. Tap , or to change the default cycle settings. 4. -
Page 32: Cycle Overview
Operations Cycle overview NOTE Other cycles can be used after adding them to your cycle list using the My Cycles function. For more information, see the “My Cycles” section on page 36. Sensor Dry cycles Cycle Description Max load (kg) For cottons, bed linen, table linen, underwear, towels, and shirts. - Page 33 Manual Dry cycles Cycle Description Max load (kg) For drying light cotton synthetics or items that needs quick drying. Quick Dry 35’ The default dry time is 35 minutes. Use to set a desired dry time. Turn the Navigation dial to select Time Dry and tap to set the drying time between 20 minutes and 240 minutes.
- Page 34 Operations Air Wash cycles Cycle Description Max load (kg) Use this cycle to disinfect clothes and make them feel fresher Air Refresh and cleaner. Use this cycle to keep both the drum and the heat exchanger fresh. Self Tub Dry •...
-
Page 35: Options
Options Using Options Damp Alert Tap O to set alert 1. Tap 2. Turn the Navigation dial to select the desired additional function. 3. Tap to change the selected function’s settings or start the function. NOTE • To return to the main screen, tap again or turn the Navigation dial to select Back and tap •... - Page 36 Operations My Cycles Add or remove cycles to create a personal cycle list. 1. Tap 2. Turn the Navigation dial to select My Cycles, and then tap You can only edit a cycle to create a personal cycle when the dryer is not operating. 3.
-
Page 37: Settings
Settings Using System Functions AI Pattern Tap O for AI suggestion * Tap and hold 3 seconds. 1. Tap and hold for 3 seconds. 2. Turn the Navigation dial and select the desired system function, and then tap 3. Tap to change the selected function’s settings or start the function. - Page 38 Operations Calibration You can run calibration again for accurate weight detection. 1. Tap and hold for 3 seconds. 2. Turn the Navigation dial to select Calibration, and then tap Calibration does not start if the door is not closed properly. The drum rotates clockwise and anticlockwise for about 3 minutes.
-
Page 39: Special Features
Special features Smart Control You can connect to the SmartThings app and control your dryer remotely. Connecting your dryer • Download and open the SmartThings app on your mobile device • Tap and hold to turn on the dryer. • Tap and hold on the dryer. - Page 40 • This appliance supports the Wi-Fi 2.4 GHz protocols. Download On an app market (Google Play Store, Apple App Store, Samsung Galaxy Apps), find the SmartThings app with a search term of “SmartThings”. Download and install the app on your device.
- Page 41 UK. The full text of the EU declaration of conformity and the UK declaration of conformity is available at the following internet address: The official Declaration of conformity may be found at http://www.samsung.com, go to Support > Support home and enter the model name.
- Page 42 Operations Using the drying rack (applicable models only) Set the drying time up to 150 minutes according to the moisture and weight of the items to dry. When drying laundry using the drying rack, the Time Dry cycle is recommended. 1.
-
Page 43: Maintenance
Maintenance Emptying the water tank Empty the water tank after each use to prevent leaks. 1. Remove the water tank (A) from the dryer. Pull the water tank handle with one hand until the tank is halfway out. Once the water tank is halfway out, support the bottom of the tank with the other hand and pull it slowly with both hands. -
Page 44: Cleaning
Maintenance Cleaning WARNING • Do not clean the dryer by directly spraying water onto the dryer. • Do not clean the dryer with benzene, thinner, alcohol, or acetone. This may cause discoloration, deformation, damage, electric shock, or fire. • Before cleaning the dryer, be sure to unplug the power cord. Exterior Clean with a soft, damp cloth. - Page 45 2. Open the outer filter and remove the inner filter (A). 3. Spread open the outer filter and the inner filter. 4. Remove the lint from both filters, and then clean the filters with the cleaning brush. NOTE To clean the filters thoroughly, clean the filters in running water, and then dry them completely.
- Page 46 Maintenance 5. Put the inner filter into the outer filter, and then reinsert the lint filter into the original position. CAUTION • Clean the lint filter after each load. Otherwise, the drying performance may decrease. • If the filter surface is wet, allow it to completely dry before use. Inserting the filter while it is wet can cause mold and/or odor to form and/or result in less drying.
- Page 47 2. Unlock the inner cover fixers (B), and then pull the inner cover to remove. 3. Clean the dust on the heat exchanger using the provided brush. After cleaning with the brush, wipe off the remaining dust using a smooth, damp cloth. CAUTION •...
- Page 48 Maintenance 5. Reinsert the inner cover to its original position, and then lock the fixers. 6. Close the heat exchanger’s outer cover. NOTE • After cleaning the heat exchanger, tap to dismiss the notification message. The message remains on until you dismiss it. •...
-
Page 49: Troubleshooting
Troubleshooting Checkpoints If you encounter a problem with the dryer, first check the table below and try the suggestions. Problem Action • Make sure the dryer is plugged in. • Make sure the door is properly closed. • Check the fuse or reset the circuit breaker. Dryer does not start. - Page 50 If the hose is frozen, submerge it in warm water to allow the water inside the hose to melt and drain out. Reconnect the hose and check for proper draining. If a problem persists, contact a local Samsung service center. English B-PJT_DV9400B_SimpleUX_DC68-04400M-00_EN (SA).indd 50...
-
Page 51: Information Codes
Information codes If the dryer fails to operate, you may see an information code on the screen. Check the table below and try the suggestions. Information code Meaning Action • Close the door and start again. • If this continues, call for service. Close the dryer door •... - Page 52 PBAs. • If this continues, call for service. Compressor overheating • Call for service. If any information code keeps appearing on the screen, contact a local Samsung service center. English B-PJT_DV9400B_SimpleUX_DC68-04400M-00_EN (SA).indd 52 2023/4/10 15:30:25...
-
Page 53: Appendix
Appendix Fabric care chart The following symbols provide garment care Bleaching direction. The Clothing care labels include symbols for drying, bleaching, drying and ironing, Any bleach allowed. or dry cleaning when necessary. The use of symbols ensures consistency among garment Only oxygen bleach allowed. -
Page 54: Protecting The Environment
Appendix Ironing Professional dry-cleaning in hydrocarbons (heavy benzines) Iron at maximum sole plate with normal process. temperature of 200 °C. Professional dry-cleaning in Iron at maximum sole plate hydrocarbons (heavy benzines) temperature of 150 °C. with gentle process. Iron at maximum sole plate Do not dry-clean. -
Page 55: Specification
Specification TYPE FRONT LOADING DRYER MODEL NAME DV9*BB94**** DV9*BB74**** 600 mm 600 mm 850 mm 850 mm DIMENSIONS 600 mm 600 mm 650 mm 650 mm 1100 mm 1100 mm WEIGHT 53kg 52 kg ELECTRICAL REQUIREMENTS AC 220–240 V / 50 Hz 1300 W ALLOWABLE TEMPERATURE 5-35 °C... - Page 56 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT 1300 362 603 (Other) AUSTRALIA www.samsung.com/au/support 1300 425 299 (HHP) 0800 726 786 (All Product) NEW ZEALAND 0800 6 726 786 (Support for www.samsung.com/nz/support Smart Mobile Devices) DC68-04400M-00 B-PJT_DV9400B_SimpleUX_DC68-04400M-00_EN (SA).indd 56...
