Instruction Manual
Draft Issue n. 1.2 of 27/02/11
DE-OX
ZIP PRO
®
OXYGEN ANALYZER
2009 All Rights reserved
www.temc.it
Contents
Contents.................................................................................................................................................... 1
Discharge of Liability................................ ................................ ................................ ................................ ... 2
General Specifications................................................................................................................................. 2
Powering On and Warming Up ..................................................................................................................... 3
Reading Page............................................................................................................................................. 3
Programming Procedures ............................................................................................................................ 4
Threshold Alarms Setting............................................................................................................................. 4
Full Scale Value Setting .............................................................................................................................. 4
Calibration Oxygen value ............................................................................................................................. 4
Threshold Alarms ........................................................................................................................................ 5
Oxygen Sensor Calibration .......................................................................................................................... 5
Powering Off............................................................................................................................................... 5
Factory Reset............................................................................................................................................. 5
Note For Correct Oxygen Analysis ............................................................................................................... 6
Replacement of the Battery and of the Oxygen Sensor ................................ ................................ ................... 6
Central Unit Specifications................................ ................................ ................................ ........................... 7
General Oxygen Sensor Specifications ......................................................................................................... 7
1
DE-OX® ZIP PRO Oxygen analyzer Draft Issue n. 1.2 of 27/02/11
page
Advertisement
Table of Contents
Summary of Contents for TEMC DE-OX ZIP PRO
-
Page 1: Table Of Contents
Draft Issue n. 1.2 of 27/02/11 DE-OX ZIP PRO ® OXYGEN ANALYZER 2009 All Rights reserved www.temc.it Contents Contents..............................1 Discharge of Liability........................... 2 General Specifications..........................2 Powering On and Warming Up ........................3 Reading Page............................. 3 Programming Procedures .......................... -
Page 2: Discharge Of Liability
ZIP PRO utilisation. The operator of this instrument is responsible for any damage or injury resulting from improper use, unauthorized repair, improper maintenance, or damage by anyone other than TEMC ® . Use always another instrument for data cross checking. -
Page 3: Powering On And Warming Up
Battery low indicator. mV sensor output reading Standard 9 Volt transistor battery. Simple battery and sensor replacement. Direct connection to every kind of tank valve with TEMC ® rubber cup. Soft protection and transport bag. Dimensions: max 7,5x4,2 cm weight 250 grams. -
Page 4: Programming Procedures
Programming Procedures Keep the ^ Prog key pressed for more than two seconds, then release the key. On the display will appear “Pr” for two second in order to advice the start of the programming procedure. It is possible to program: AL1 Minimum alarm threshold expressed in % oxygen concentration AL2 Maximum alarm threshold expressed in % oxygen concentration FSc Value expressed in % oxygen concentration corresponding to the current output full scale value... -
Page 5: Threshold Alarms
Threshold Alarms Should the oxygen reading goes over the maximum or below the minimum threshold alarms (AL2 or AL1) the instrument goes to alarm mode and it activates the relays output (open collector max 100mA) and the internal buzzer. On the display will be shown the trespassed alarm and the actual measured value. For stopping the buzzer song it is enough to press any key. -
Page 6: Note For Correct Oxygen Analysis
All the analysis concentration shown on the display would be wrong. Wrong Oxygen analysis may lead to death. Note For Correct Oxygen Analysis Before doing mixed gas analysis, connect the mixed gas hose (not supplied) to the adapter in the rear of the instrument and let the gas flow goes through the internal oxygen sensor. -
Page 7: Central Unit Specifications
- Avoid exposure to spray liquids and to corrosive gas, don’t submerge and do not expose to water splash. - For cleaning, use a soft dry brush not soaked with any liquid. - Don’t try to remove screws from DE-OX® ZIP PRO or to open it. For any problem call TEMC ®... -
Page 8: 4-20Ma Connections (If Available)
100% RH Weight: approximately 26 g Material in contact with media: PA, PPS, PTFE, stainless steel In the interest of product improvement, TEMC ® reserves the right to alter design features and specifications without notice. Check TEMC ®... -
Page 9: Open Collector Connections (If Available)
® ZIP PRO according to TEMC ® instructions. To avail oneself of the warranty, send the product with carriage prepaid to TEMC ® THESE WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED, IMPLIED, OR LEGAL. TEMC ®... - Page 10 Under no circumstances will TEMC ® be liable for economic, special, incidental or consequential damages of any kind whatsoever. This warranty does not cover any damage due to accidental events (ex. impact or falls) or natural events (ex. fires calamities , earthquakes, etc.).
-
Page 11: Cartolina Di Garanzia (Warranty Registration Card)
(Fill with required data and send in a sealed envelope within 5 days from purchase to): TEMC ® Via Donna Prassede 5 A I-20142 MILANO ITALY Phone +39 02 8463648 or +39 080 4490264 E-Mail: temc@iol.it Website: www.temc.it Nome ________________Cognome___________________ (First name) (Family name) Via_______________________________________n_____ (Address) Città______________________________CAP__________... -
Page 12: Disposal Of Old Electrical And Electronic Equipment
Disposal of Old Electrical and Electronic Equipment In the EU when you buy a new equipment you may give back the old equivalent unit to the supplier free of charge for correct disposal. DE-OX® ZIP PRO Oxygen analyzer Draft Issue n. 1.2 of 27/02/11 page... - Page 13 ON/OFF and the <CALIB keys. TEMC ® Via Donna Prassede 5 A I-20142 MILANO ITALY Phone +39 02 8463648 or +39 080 4490264 E-Mail: temc@iol.it Website: www.temc.it D E -OX ZIP PRO ANALIZZATORE DIGITALE DI OSSIGENO ® Guida veloce di riferimento: Attenzione Fare sempre riferimento al manuale completo in formato elettronico prima di utilizzare lo strumento.
- Page 14 ON/OFF e <CALIB. TEMC ® Via Donna Prassede 5 A I-20142 MILANO ITALY Phone +39 02 8463648 or +39 080 4490264 E-Mail: temc@iol.it Website: www.temc.it DE-OX® ZIP PRO Oxygen analyzer Draft Issue n. 1.2 of 27/02/11 page...
