Mount Bracket
Package
MOUNT-BRACKET
SCREW-SPECIAL
Product Overview
This product is an adaptor used to install Fish-Eye camera (the same model as SNF-8010/ 8010RVM /
PNF-9010RVM / 9010RV / 9010R) in the electric gang box or on the wall.
SBF-100B1
Installation Precautions
Please make sure to install on an area which is strong enough to support more than 4 times of the
total weight of this product and the camera. Depending on some installation conditions, this
product can be connected to 0.75" PF which is a screw peak processed pipe.
Installation
1 Install the mount bracket on a desired position.
A
ANCHOR
B
C
Advertisement
Table of Contents
Related Manuals for Hanwha Vision SBF-100B1
Summary of Contents for Hanwha Vision SBF-100B1
- Page 1 This product is an adaptor used to install Fish-Eye camera (the same model as SNF-8010/ 8010RVM / PNF-9010RVM / 9010RV / 9010R) in the electric gang box or on the wall. Mount Bracket SBF-100B1 Installation Precautions Please make sure to install on an area which is strong enough to support more than 4 times of the total weight of this product and the camera.
- Page 2 Product Outline 2 Remove the cap-bolt in the selected direction before inserting the pipe. 3 Attach the case-bottom to the mount bracket. Pipe CAP-BOLT Product Specifications Weight 345g Material Aluminum Operating -50°C~60°C Temperature Operating 0~100% Humidity PT01-004506B_(v1.1)
