  • Page 1 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 This document contains information on a product under development. The parametric information contains target parameters that are subject to change. Copyright  Elevate Semiconductor Page 1 of 2...
  • Page 2 Figure 3: PMU FV Block Diagram ......................14 Figure 4: Device Config Menu Options ...................... 17 Figure 5: Elevate Semiconductor EVM Overview Block Diagram ............. 18 Figure 6: Triton EVM Loadboard Detailed Block Diagram ................. 19 Figure 7: Triton EVM Capacitor/Resistor Network Block Diagram ............20 Figure 8: Controller Section Detailed Block Diagram ................
  • Page 3 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 Table 9: Triton EVM Loadboard Analog Mux Definitions – LB_AMUX Mapping ........21 Copyright  Elevate Semiconductor Page 3 of 4...
  • Page 4 Triton performance and functionality. This document provides the instructions to install, setup, and operate the Triton EVM. Refer to the Elevate Semiconductor EVM User’s Guide for a detailed description of the FVMI and Motherboard. 1.1 Unpacking - Triton EVM Contents Please check the contents of the Triton EVM shipping carton to make sure you have received all of the items listed in Table 1.
  • Page 5 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 1.2 Recommended Test and Measurement Setup 1.2.1 Power Supply Table 2 provides the required power supplies and current rating. The power supplies are connected using standard banana plugs. The customer needs to provide the power supply cables.
  • Page 6 To install the Triton EVM software package, run the SETUP program on the distribution Flash Drive and follow the prompts. The ElevATE.exe executable will be installed in the EVM GUI sub-directory. In addition, a short cut will be installed onto the desktop and in the Start->Programs folder. The Start->Programs folder also contains links to the different EVM User’s Guide, and documentation...
  • Page 7 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 1.3.2.1.2 Select “Advanced options” and “Startup Settings”. 1.3.2.1.3 You need to restart your computer one last time to modify boot time configuration settings. 1.3.2.1.4 You will be given a list of startup settings, including “Disable driver signature enforcement”.
  • Page 8 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 1.3.2.1.5 Continue with section 1.3.2.2 to finish installation of USB driver except choose the windows 10 or windows 8 option. 1.3.2.2 Windows 7 To install the USB device driver on a Windows 7 system, connect the USB port on the EVM board to a USB port on your PC using the included USB A/B cable.
  • Page 9 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 1.3.2.1.1 After connecting the USB cable from the PC to the USB port, navigate to the Device Manager screen on your computer and look for the EZ-USB Icon. Right-Click on the EZ-USB Icon and select “Update Drive Software…”...
  • Page 10 Rev A05: 09/11/2019 1.3.2.1.3 Install driver from the newly installed folder on your computer: Windows 7: \ElevATE Semi\EVM GUI\Elevate USB Driver\wlh-win7\(x64 or x86) Select x64 for a 64-bit system. Select x86 32-bit system. Select “Next”. The USB driver will be installed.
  • Page 11 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 1.3.2.2.1 After connecting the USB cable from the PC to the EVM board, the following window appears. Select “No, not this time” and click Next. 1.3.2.2.2 Choose “Install from a list or specific location (Advanced)” and click Next.
  • Page 12 After the Triton EVM and USB software is installed, it is recommended to re-boot the machine. 1.3.4 Launching the Elevate Semiconductor Program The user can launch the Elevate Semiconductor GUI from the desktop, Start->Programs folder, or EVM GUI sub-directory. 1.3.5 Software Un-Installation The Elevate Semiconductor demonstration program may be un-installed using the Add/Remove Program from the Windows Control Panel.
  • Page 13 2.1 Quick Start Instructions 1. Disable external power supplies 2. Connect the power supplies cables (not provided) from the power supply to the Elevate Semiconductor EVM Motherboard and Triton loadboard; refer to Section 2.2.1. 3. Connect the USB cable (provided) from the PC to the USB port on the “USB FX2 to Parallel” board.
  • Page 14 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 2.2 Default Configuration Setup Options The EVM has several default options for configuring for device into different modes. Table 3: Triton Default Configuration Options Mode See Section # Brief Description Hardware Reset All registers default to the hardware default state.
  • Page 15 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 2.3 Triton EVM Jumper Definitions Table 4 lists the Triton EVM Jumper definitions. Table 4: Triton EVM Jumper Definitions Jumper Description Configuration Connect VFORCE Installed VCC Source Short Pin 1 & 2. Towards back of board VEE Source Short Pin 1 &...
  • Page 16 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 Table 5: TC# Resource Allocation Usage EVM MB EVM MB Jumper Jumper Configuration TPIN CPU_SDIO CPU_STB RESET MONITOR MON_REF Reserved MON# MON_REF# CPU_CK EXT_FORCE#_P EXT_SENSE#_P LB_AMUX_P DUT_GND Only applicable when DUT_GND_SEL = TC_15...
  • Page 17 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 2.5 Triton EVM Menu Dialog Boxes Figure 4 illustrates the Triton EVM menu options. These provide access to the Triton registers. Figure 4: Device Config Menu Options Copyright  Elevate Semiconductor Page 17 of 18...
  • Page 18 • voltage regulators/references, and EVM controller. Represented in blue in the figure. Refer to the Elevate Semiconductor EVM User’s Guide document for a detailed description of the Octal FVMI and Motherboard. Figure 5: Elevate Semiconductor EVM Overview Block Diagram +20V...
  • Page 19 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 3.1 Triton EVM Loadboard Detailed Description Figure 6 illustrates the Triton EVM loadboard. Almost all of the circuitry is used to test, validate & characterize on the bench and ATE environment. Besides decoupling caps, the only external component required is the 10K resistor connected to REXT.
  • Page 20 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 3.2 Capacitor and Resistor Network Definitions Figure 7 illustrates while Table 6 and Table 7 list the Triton EVM capacitor/resistor load network definitions. Any capacitor combination can be switched in. The software only allows a single resistor value to be switched in.
  • Page 21 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 3.3 ADC and Analog Mux The Octal FVMI contains a 24-bit ADC and analog muxes which allows for the accurate measurement of many device and system voltages. Table 8 lists the Triton EVM loadboard specific mux input sources.
  • Page 22 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 3.4 Triton EVM Loadboard Controller The Triton EVM loadboard contains seven 8-bit latches (registers), 16K EEPROM, Thermal Sensor, and an Analog-to-Digital Converter (ADC). The Cbit1 to CBit7 are also used to control various relays, the C- Bit# originate from the Octal FVMI board.
  • Page 23 Triton/ISL55185 EVM Getting Started Rev A05: 09/11/2019 Document Revision History Revision Date Description 02/07/06 Initial Draft 05/20/13 Change to Elevate Semiconductor format 08/26/14 Updated software installation to support USB interface 06/21/18 Added Windows 10 USB Driver Installation 09/11/19 Delete functions that are no longer used.
