Installation GUIDE
NI PXI Slot Blocker
The NI PXI Slot Blocker improves system cooling in PXI chassis by rerouting airflow from
empty slots to slots containing PXI modules. This guide describes how to use the NI PXI Slot
Blocker most effectively.
What You Need to Get Started
•
A PXI or PXI Express chassis recommended for use with the NI PXI Slot Blocker
•
A PXI or PXI Express system controller
•
PXI or PXI Express peripheral modules
•
NI PXI Slot Blockers
•
PXI filler panels
PXI Chassis Recommendations
Table 1 lists NI PXI chassis recommended for use with the NI PXI Slot Blocker.
Table 1. NI PXI Chassis Recommended for Use with the NI PXI Slot Blocker
Chassis Configuration
Chassis with fans in rear
Chassis with fans below
card cage
NI PXI/PXI Express
Chassis
PXI-104x Series
PXIe-106x Series
PXIe-108x Series
(excluding 1088)
PXIe-109x Series
PXI-103x Series
PXIe-107x Series
PXIe-1088
Recommendation
Highly recommended
Recommended
