- Page 1 1200 - Wireless Light Gate Sensor Version: 0 | DS166 © Copyright Data Harvest Group Ltd - All Rights Reserved - Freely photocopiable for use within the purchaser’s establishment...
-
Page 2: Table Of Contents
1200 - Wireless Light Gate Sensor Table of contents Introduction ...................... 3 Pack Contents ....................4 Operational Overview ..................5 Connectivity ...................... 8 Charging the Sensor ................... 9 Firmware Updates .................... 10 Usage Information .................... 11 Practical Investigations ..................13 Sensor Specifications .................. -
Page 3: Introduction
Thank you for purchasing the Smart Wireless Light Gate Sensor. We pride ourselves on producing high quality products that meet with the demands of the busy classroom environment. If you have any problems using this sensor, please read this documentation in full before contacting the Data Harvest support team. -
Page 4: Pack Contents
1200 - Wireless Light Gate Sensor Pack Contents This product is supplied with the following items: · 1 x Smart Wireless Light Gate Sensor · 1 x USB Connecting Lead · 1 x Link Cable · 1 x Mounting rod... -
Page 5: Operational Overview
1200 - Wireless Light Gate Sensor Operational Overview The diagram below shows the specific parts of the sensor. Read further to explore the functionality of each part of the sensor. 1.On/Off Switch 2.USB Port 3.Connection socket to attach Light Gates together 4.Unique ID Number... - Page 6 1200 - Wireless Light Gate Sensor The Status Indicators (5) The sensor features a single status indicator that changes colour and flashes. See the table below for further information. Status Light Indicates No light Sensor is Off. Short press the On/Off switch...
- Page 7 · Press and hold down the On/Off button for at least 8 seconds until the status LED gives a flash of blue light, then release. · If the sensor fails to respond, contact Product Support at Data Harvest. Please provide details of: The computer platform it is being used with and the EasySense2 app’s version number.
-
Page 8: Connectivity
1200 - Wireless Light Gate Sensor Connectivity The sensor is both USB and Bluetooth compatible. Install the EasySense2 app, if it is not already on your device. For details of how to operate the EasySense2 app, please refer to the EasySense2 documentation. -
Page 9: Charging The Sensor
1200 - Wireless Light Gate Sensor Charging the Sensor The Smart Wireless sensors are fitted with a rechargeable lithium-ion battery and can be charged via the USB port. Use the supplied USB lead to connect the sensor either directly to a USB port on your computer, a powered USB hub or a USB mains charger that outputs 5 V at 500 mA or more. -
Page 10: Firmware Updates
1200 - Wireless Light Gate Sensor Firmware Updates Occasionally Data Harvest may release updated firmware which will contain improvements or new features. Updates will take place when you connect your sensor to the EasySense2 app. You will be given the option to decline an update. -
Page 11: Usage Information
If you connect with a USB connection the process is the same with the exception that USB connections to Data Harvest data logging devices will automatically be identified as active connections in the EasySense2 app. You will not need to worry about the identity number. - Page 12 If you connect with a USB connection the process is the same with the exception that USB connections to Data Harvest data logging devices will automatically be identified as active connections in the EasySense2 app. You will not need to worry about the identity number.
-
Page 13: Practical Investigations
1200 - Wireless Light Gate Sensor Practical Investigations The Smart Wireless Light Gate Sensor can be used to investigate a number of scientific experiments such as: · Dynamics experiments involving calculating time, speed, velocity, acceleration using inclinable planes and air track ·... - Page 14 1200 - Wireless Light Gate Sensor Explore Science Practicals See our Smart Wireless Sensors in action with a range of practical experiments. This is the best way to get started with the new Bluetooth sensors! View video playlist 14 / 21 | Version: 0 | DSXXXX...
-
Page 15: Sensor Specifications
1200 - Wireless Light Gate Sensor Sensor Specifications Please read the following table for sensor specifications. Feature Detail Measurement Ranges Timing Data Accuracy 1µs Wavelength 940nm Gate Separation 0.025m Connectivity Wired via USB Wireless via Bluetooth Bluetooth Specifications Bluetooth 4.2 low energy radio, single mode... -
Page 16: Limited Warranty
Postage Charges · In the event of a fault developing, the product must be returned in suitable packaging to Data Harvest for repair or replacement at no expense to the user other than postal charges. · There will be no postal charge for the return of repaired goods to any mainland UK address (for other areas, additional shipping charges may apply). -
Page 17: Compliance
Waste Electrical and Electronic Equipment Legislation Data Harvest Group Ltd is fully compliant with WEEE legislation and is pleased to provide a disposal service for any of our products when their life expires. Simply return them to us clearly identified as ‘life expired’... -
Page 18: Troubleshooting
1200 - Wireless Light Gate Sensor Troubleshooting The wireless Light Gates work using an infra-red beam, natural light is infra-red and can affect the beam of the Light Gate. Use away from direct sunlight. When using two Light Gates with the connection lead, make sure the connection lead is fully inserted. -
Page 19: Notices
2. When the sensor is connected to a computer, the computer should be turned on and not in sleep or standby mode or the battery may drain instead of charge. 3. Data Harvest products are designed for educational use and are not intended for use in industrial, medical or commercial applications. -
Page 20: Contact Information
1200 - Wireless Light Gate Sensor Contact Information To contact Data Harvest directly, please use any of the following channels Traditional Communications Data Harvest Group Ltd. 1 Eden Court, Eden Way, Leighton Buzzard, Bedfordshire, LU7 4FY United Kingdom Tel: +44 (0) 1525 373666... -
Page 21: Pdf Translations
1200 - Wireless Light Gate Sensor PDF Translations The PDF formatted download of this manual is by default provided in the English (United Kingdom) language. If an alternative translation is available, it will be listed here. We have for your convenience included a webpage translation feature to the online documentation which will allow you to translate and print individual pages of this documentation.
