Summary of Contents for Tycon Power Systems TP-MS608
- Page 1 TP-MS608/616 Power Source Equipment (Power over Ethernet Hub) USER’S MANUAL TYCON POWER SYSTEMS...
-
Page 2: Table Of Contents
System Login..................Modify Password…................Edit Station TCP/IP................Edit Remote PoE IP................GUI Connect..................Station and Status Window Select ............Configuration..................Factory Setting…………................ Board Status………………………………………………………………… Port Status…………………………………………………………………... GUI Version…………………………………………………………………. GUI Disconnect…………………………………………………………..File Open and Save………………………………………………………… 5. Technical Specification............31 TYCON POWER SYSTEMS... -
Page 3: Introduction
1. Introduction TYCON’s family of Power over Ethernet PSE (Power Sourcing Equipment), injects power over data-carrying Ethernet cabling. The TP-MS608/616, support 8 and 16 ports respectively in a 10/100/1000BaseTx Ethernet network, over TIA/EIA-568 Category 5/5e/6 cabling. DC operating power, for data terminal units, is fed over data pairs of the cabling (4/5 and 7/8). -
Page 4: Package Contents
Compare the contents of your TP-MS608/616 package with the standard checklist above. IF any item is missing or damaged, please contact your local dealer for service. 2. Hardware Description This Section mainly describes the hardware of the TP-MS608/616 and gives a physical and functional overview. Physical Dimension TP-MS608/616 physical dimension is: 430mm x 290mm x 44mm (Lx W x H) (1U, 19”... -
Page 5: Led Indicators
User’s Manual TP-MS608/616 The Front Panel of the TP-MS608/616 consists of 8/16 x RJ-45 Ethernet ports (data), 8/16 x RJ-45 PoE ports (data + power), 8/16 x LED port indicators, one LED power indicator and one RJ-45 remote control port(include one LED). -
Page 6: Rear Panel
Rear Panel The AC inlet, DC input terminal, and 2 Ventilation fan are located at the rear panel of the TP-MS608/616. The device will work with AC in the range 100-240V AC, 50-60Hz. Or work with DC -48V. (-42~-57VDC) Power On Connect the power cord to the power socket on the rear panel of the PSE. -
Page 7: Remote Control Port
TP-MS608/616 allowed you to use a standard Web-browser such as Microsoft Internet Explorer or Mozila, to set the TCP/IP parameter. Before you use the web interface to set the PoE TCP/IP, verify that TP-MS608/616 is properly installed on your network and PC on the network can access PoE via the web-browser. - Page 8 9. Key in ID (user name) and password to enter PoE TCP/IP parameter setting. Default ID and password is admin and system. 10. TP-MS608/616 TCP/IP parameter has 4 pages interface (administrator setting, TCP Mode, UDP Mode and UART). You must change the administrator & TCP mode to fit your network.
- Page 9 Username: You can assign new user name. The default setting is admin. Password/Confirm: You can type in new password here. The default setting is system. When you have finished the set up, click on Update to update your setting. TYCON POWER SYSTEMS...
- Page 10 Clint mode inactive timeout: Unused. Server mode protect timeout: Set to 0(Disable) for normal operation. When you have finished the set up, click on Update to update your setting. PS: The TP-MSxxx does not support Telnet Terminal Operation. TYCON POWER SYSTEMS...
- Page 11 User’s Manual TP-MS608/616 13. UDP Mode: This mode is not used in the PoE application. TYCON POWER SYSTEMS...
- Page 12 Parity Type: Set to none parity for PoE operation. Stop Bit: Set to 1 stop bit for PoE operation. Hardware Flow Control: Set to none flow control for PoE operation. When you have finished the set up, click on Update to update your setting. TYCON POWER SYSTEMS...
- Page 13 User’s Manual TP-MS608/616 15. When you have configured your set up, you must reset the device to take effect. TYCON POWER SYSTEMS...
-
Page 14: Software Utility Installation
2000, XP,Vista and Window 7. Please follow the below steps to install the software utility. 1. Insert the software utility CD-ROM into your CD-ROM drive. 2. Run the “setup.exe”. 3. You will see the installation screen display. 4. Then, click the “OK” button to go next step. TYCON POWER SYSTEMS... -
Page 15: Gui Management
(Netclient). You will see the main utility interface below. Tools bar PSE station selection & alarm indicator legend tool Display page select PSE port select PSE station TCP/IP setting message window TCP/IP edit/view icon PSE TCP/IP setting TCP/IP connection indicator Change web-browser icon TYCON POWER SYSTEMS... -
Page 16: System Login
User’s Manual TP-MS608/616 System Login Run the management software or click “File”, and select “Login”, the system will show the diagram below. Now enter the password, first enter the default setting which is “0000” TYCON POWER SYSTEMS... -
Page 17: Modify Password
User’s Manual TP-MS608/616 Modify Password Click “File” and select “Modify PSW”, you can modify the password, the system permits 3 sets of password. TYCON POWER SYSTEMS... -
Page 18: Edit Station Tcp/Ip
View icon to display TCP/IP parameter. Station Name: You can assign a name to the PSE device. Address: You can assign the IP address for this PSE station. Port:: You can assign the port number for this PSE station. TYCON POWER SYSTEMS... -
Page 19: Edit Remote Poe Ip
To modify the remote PoE TCP/IP parameter, please reference RJ-45 Remote Control Port of section 2 Hardware Description (page 7). Change Browse icon: You can use this icon to change the web-browser for remote PoE IP edit. The default web-browser is Microsoft Internet Explorer. TYCON POWER SYSTEMS... -
Page 20: Gui Connect
“Connect All” command or click “connect” icon, if the Station Select window shows the name icon and displays power status(green or red) light, it means that the PSE connection is correct. You can then select station to configure you PSE. TYCON POWER SYSTEMS... - Page 21 Orange---this connection is not working.. Gray-------this station is not setting. In the TCP/IP Status window, the LED indicates real time status of TCP/IP. Green-----TCP/IP connection is OK. Red--------TCP/IP connection is not working. Gray-------TCP/IP parameter is not setting. TYCON POWER SYSTEMS...
-
Page 22: Station And Status Window Select
If you want to change the station, also use the mouse to choose the station name icon. Station Select display icon Status display icon TYCON POWER SYSTEMS... -
Page 23: Configuration
In force mode, the port will not detect and classify a PD to connect to, but immediately turn on the power to the port. In shutdown mode, the port is disabled and does not detect or power on a PD. TYCON POWER SYSTEMS... -
Page 24: Factory Setting
User’s Manual TP-MS608/616 Factory Setting Click “Config”, and select “Factory” or click the “Factory” icon. The screen will show the factory setting control panel as below: then click “Y” for the Factory Setting. TYCON POWER SYSTEMS... - Page 25 User’s Manual TP-MS608/616 Factory setting as below: Operation Mode → Auto (Auto, Force & Shutdown) AC Disconnect → On (On & Off) DC Disconnect → Off (On & Off) TYCON POWER SYSTEMS...
-
Page 26: Board Status
User’s Manual TP-MS608/616 Board Status Click “Config”, and select “GetBoardStatus”, or click “Board STATUS” icon, the screen will show current status of each port. TYCON POWER SYSTEMS... -
Page 27: Port Status
If all power modules are working normally, the “Sys. Power” will show a green light, if any module has failed, the light will turn to red. TYCON POWER SYSTEMS... -
Page 28: Gui Version
User’s Manual TP-MS608/616 GUI Version Click “StatusDisp”, and select “GUI Version”, the screen will show the version of the EMS utility TYCON POWER SYSTEMS... -
Page 29: Gui Disconnect
User’s Manual TP-MS608/616 GUI Disconnect Click the “GUI”, and select “Disconnect All”, or click the “GUI disconnect” icon to disconnect the communication between GUI and PSE. TYCON POWER SYSTEMS... -
Page 30: File Open And Save
User’s Manual TP-MS608/616 File Open and Save You may click “File” and select “Open”, or click the ”Open file” icon, to open the previous setting file. Click “Save”, or “Save file” icon, to save the current setting. TYCON POWER SYSTEMS... -
Page 31: Technical Specification
-42~-57VDC DC Input Current require > 6A @ 48V > 12A @ 48V Operating Temperature: 0℃~65℃ Environment Storage Temperature: -20℃~80℃ Humidity: 10%~95%RH (non condense) Dimensions 430mm(L) x 290mm(W) x 44mm(H), 19” Rack-Mount / 1U Weight 3.6kg 4.9kg TYCON POWER SYSTEMS...
