Summary of Contents for UfiSpace N3100-4C
- Page 1 Unifying Cloud & Carrier Networks N3100-4C 5G Timing Adapter Installation Guide Issued Date 17 - July - 2023 Version: 1.1...
- Page 2 5G Timing Adapter Installation Guide Revision History Revision Release Date Summary of Description Author 17 July 2023 First Draft Release. Winston Lai...
- Page 3 5G Timing Adapter Installation Guide Contents 1. Introduction ..........................4 2. Installation ........................... 4 Hardware Compatibility and Requirement ..............5 Installing the Adapter ...................... 5 3. LED indicators ..........................6 Front Panel LED ....................... 6 4. Driver, Firmware and Related Software ..................7 Driver, Firmware Installation ...................
- Page 4 Equipped with Stratum 3E OXCO, high performance FPGA and in-house software stack complied with PTP and SyncE standards, N3100-4C provides Class C timing accuracy for various use cases such as 5G O-RAN fronthaul, data centers, High-Frequency Trading (HFT) and industrial automation.
- Page 5 5G Timing Adapter Installation Guide 1. Make sure the operating system is Linux. 2. Insert the adapter(s) in device. 3. Attach the copper or fiber network cable(s). 4. Install software, firmware and drivers, please refer to section 4 2.1 Hardware Compatibility and Requirement Before installing the adapter, check your system for the following: •...
- Page 6 5G Timing Adapter Installation Guide Figure 2. Figure 3. 3. LED indicators 3.1 Front Panel LED Sync LED LED Condition Equipment Status Sync The timing card is not activated or not fully inserted in the PCI Express slot One of ethernet ports is up and synchronized to timing Solid Green source Solid Amber...
- Page 7 5G Timing Adapter Installation Guide Thermal NMI event is triggered and all Ethernet ports are Blinking Amber(4/sec) disable Ethernet I/O Port(0~3) Cable is not plugged in/No traffic Blinking Green 25G TX/RX activity Blinking Amber 10G or less TX/RX activity 4. Driver, Firmware and Related Software This section describes the driver, firmware and related software installation.
- Page 8 5G Timing Adapter Installation Guide # tar zxvf E810_NVMUpdatePackage_v3_20_Linux.tar.gz # cd E810/Linux_x64 # chmod 755 nvmupdate64e # sudo ./nvmupdate64e 2.3. Follow the prompts to update the NVM image on the desired device. 3. Power cycle the system and check the driver and NVM version: Related Software Installation Follow the below steps to install ufi-sync-tool-1.0.0-0: 1.1.
