- Page 1 ASSEMBLY INSTRUCTIONS TORO 3 DRAWER PEDESTAL JBTORO3PED This design and instruction booklet is subject to copyright. www.officeworks.com.au 1CTN For spare parts or hardware call 1300 OFFICE (1300 633 423) 1/10...
- Page 2 Estimated Assembly Time: 15 minutes Customer Service Contact Details Spare Parts & Hardware (1300 633 423) 1300 OFFICE People Required General Advice 2/10...
- Page 3 Tools Required CAUTION: Do not use tools other than those required, as this can damage your new item NOTE • Please check you have all hardware before assembling. • If you are missing any hardware, please contact 1300 OFFICE(1300 633 423) •...
- Page 4 Parts List x1pc Hardware List x1pc x4pcs x16pcs #4*14mm x2pcs #4*16mm x1pc 6*15mm x1pc x1pc x1pc 4/10...
- Page 5 Hardware Spare Parts number - HWASH3PED 6*15mm x1pc x16pcs #4*14mm x1pc x2pcs #4*16mm x1pc Hardware Spare Parts number - HWCASTORS x1pc x4pcs 5/10...
- Page 6 6/10...
- Page 7 Step 3 Detail #B Detail #B To remove drawer, pull drawer out until stopped, then simultaneously push the left plastic release lever up while pushing the right lever down, then pull the drawer out, as shown. 7/10...
- Page 8 Step 4 To insert drawer, fully extend both ball bearing tracks on each side and align the slide runners on the drawer with the tracks on the unit. Push the drawer into place until closed. If the drawer does not smoothly push into place, please remove and repeat insertion procedure.
- Page 9 9/10...
- Page 10 Furniture Assembly Instructions Style Guide Warranty years Product Warranty – valid for Australian customers only Officeworks Ltd warrants that this product will be free from defects and work as intended for 8 years from the date of purchase by the original customer. If the product has any defects or does not work as intended during the Warranty Period, Officeworks will, at its election and at its expense, repair or replace the product.
