Mercedes-Benz G 500
BATTERY VEHICLE
User's manual
Styles and colors may vary. Made in China.
The owner's manual contains important safety information, as well as instructions
for assembly, use and maintenance.
The car must be assembled by an adult who has read and understood the
instructions in this manual.
Keep the package out of the reach of children and dispose of it properly before use.
Keep this manual for future reference.
THIS PRODUCT HAS A LIMITED 30 DAY WARRANTY
AFTER THE DATE OF PURCHASE
Advertisement
Summary of Contents for ASTM Mercedes-Benz G 500
- Page 1 Mercedes-Benz G 500 BATTERY VEHICLE User's manual Styles and colors may vary. Made in China. The owner's manual contains important safety information, as well as instructions for assembly, use and maintenance. The car must be assembled by an adult who has read and understood the instructions in this manual.
- Page 2 About your new vehicle ÿ On the purchase of your new Ride-On. This vehicle will provide your child with many miles of fun. To help ensure a safe trip for you and your child, we ask that you read this manual carefully and save it for future reference.
- Page 3 Machine Translated by Google Notice to user 2 WARNING! • CHOKING HAZARD - Small parts. Not suitable for children under 36 months. The product contains small parts, keep children away during assembly. • ADULT ASSEMBLY REQUIRED • Always remove protective material and polythene bags and discard prior to assembly.
- Page 4 Parts diagram 3 TIP: Some parts shown are assembled on both sides of the vehicle...
- Page 5 Parts list 4 Quantity (pieces) PART OBSERVATIONS noble part vehicle body rear gearbox 2WD 1 pc labeled "R", the other one labeled "L" rear wheel Front wheel lock nut hubcaps Ø10 washer Mounted on the front axle Ø12 washer Mounted on the front axle Steering wheel Machine screw M5x35 Ø5 placed on the steering wheel...
- Page 6 Position the rear wheels 5 TIP: If your vehicle is a two-wheel drive type, see the next page. rear bottom view Remove all parts from the rear axle. 1. Slide the rear gearbox onto the rear axle from the left side (gearbox labeled "R" should fit the "R"...
- Page 7 Position the rear wheels 6 rear bottom view Remove all parts from the rear axle. 1. Slide the rear gearbox onto the rear axle. gearbox labeled "R" must fit the "R" side of the vehicle body; The gearbox labeled "L" must fit on the "L" side of the bodywork vehicle.
- Page 8 Position the front wheels 7 bottom front view Remove all parts from the front axle. 1. Slide a Ø10 washer onto the front axle. 2. Slide one front wheel onto the front axle. 3. Slide a Ø10 washer onto the front axle. 4.
- Page 9 Place the steering wheel 8 TIP: If your vehicle's steering wheel is equipped with the sound feature, follow steps 1-4 to add batteries (not included) and see battery information on page 2. 1. Using a screwdriver, remove the battery cover screw located in the center of the steering wheel.
- Page 10 Connect the power supply 9 rear top view red battery white vehicle connector connector Fuse Battery White motor red vehicle connector connector 1. Plug the vehicle connector into the battery connector. 2. Plug the vehicle connector into the engine connector on the body as shown above.
- Page 11 Attach the engine hood and seat 10 TIP: Only 1WD product need to assemble the engine hood 1. Place the engine cover over the engine. 2. Insert two Ø4x12 screws and tighten. 1. Place the tabs on the seat back into the slots at the rear of the vehicle. 2.
- Page 12 Attach windshield, side mirrors, tool box 11 1. Place the tabs on the windshield into the slots in the vehicle. Press until you hear it "click" into place. 2. Place the side mirrors into the holes on the side of the doors, push them in until you hear a "click"...
- Page 13 Use your vehicle STYLE II ‹‹ ÿ 1. Power button: Turns the vehicle on and off. 2. Pedal: Supplies power (speed) to the vehicle. • To move the car, step on the pedal. • To brake or slow down, release pressure on the pedal. 3.
- Page 14 Load 13 WARNING! • ONLY an adult can charge and recharge the battery! • • This product with charging protection: during charging, they will be cut off all functions. • The POWER SWITCH must be in the OFF position during the charge.
- Page 15 Troubleshooting Guide 14 Possible cause Solution Problem The vehicle does not work Recharge the battery. low battery Thermal fuse tripped Reset the fuse, see <Fuse> The battery connector or cables Check that the battery connectors are well connected. If there are loose wires around the motor. contact your are loose dealer please.
- Page 16 • Do not tamper with the electrical system. Doing so can create a short circuit and cause the fuse to blow. Our products conform to ASTM F963; GB6675; EN71 standard and EN62115 standard.
