KB FL-LED-R2B-140PS-8CSB-ST Quick Start Manual

FL - L ED - R 2 B - 14 0 PS- 8C SB -S T
140W High-Power LED Rectangular Floodlight; 120–277V Input
PRODUCT FEATURES
• High-power LED rectangular floodlight with innovative design
based on established floodlight principles
• Suitable for ground-, pole-, or building-mount applications
• Selectable wattage technology (140/100W)
• Selectable CCT technology (3000/4000/5000K)
• Die-cast aluminum housing with optional glare shield
accessory (sold separately)
• Heavy-duty trunnion- and slipfitter-mount options included
• 3-pin twist lock photocell and shorting cap included with
NEMA/ANSI C136.10 3-pin twist lock receptacle
ELECTRICAL SPECIFICATIONS
Catalog Number Wattage
140W
FL-LED-R2B-140PS-8CSB-ST
100W
Note: Mounting options are universal: 2 3/8" Trunnion or Slipfitter. Photocell included.
FL-LED-R2B-140ps-8CSB-st
high-power led floodlight
HIGH-POWER LED FLOODLIGHT
CCT Lumens Efficacy Input Voltage
3000K 17,500 125 lm/W
4000K 20,300 145 lm/W
5000K 18,900 135 lm/W
3000K 13,500 135 lm/W
4000K 15,500 155 lm/W
5000K 14,500 145 lm/W
• Precision-crafted NEMA 7H × 6V optics lens
• 0–10V dimming driver with 12V AUX power tap and 6kV surge
protection
• Ambient operating temperature: −40°C/-40°F to 50°C/122°F
• UL and DLC 5.1 listed, IP65 rated
• Power factor: >0.95
• THD: <20%
• L70 @ 100,000 hours @ 25°C/77°F ambient fixture temperature
• Meets FCC Part 15, Part B, Class A standards for conducted
and radiated emissions
Optics Type Dimming
120–277V 7H × 6V 0–10V
Housing Color CRI Rated Life
Bronze >80 50,000 hrs
Page 1 of 4
Legacy
Equivalent
400W MH
